AMPLIFIED LOUDSPEAKER CONTROLLERS
Installation & Operation Guide
MODELS
ALC-404D
ALC-1604D
ALC-3202D
Packing List
The box contains the following:
1x ALC-3202 (D or AN model)
(Phoenix connectors plugged in)
1x Phoenix MC 1,5/4-ST-3,81 - 1803594 plug
3x Phoenix MC 1,5/6-ST-3,81 - 5447900 plug
1x Phoenix PC 5/4-STF1-7,62 - 177859 plug
3x IEC power cord
1x Safety guide
OR
1x ALC-404 or ALC-1604 (D or AN model)
(Phoenix connectors plugged in)
1x Phoenix MC 1,5/4-ST-3,81 - 1803594 plug
3x Phoenix MC 1,5/12-ST-3,81 - 1803675 plug
1x Phoenix PC 5/8-STF1-7,62 - 177891 plug
3x IEC power cord
1x Safety guide
A:
9300 Gemini Drive, Beaverton, OR 97008
ALC-404AN
ALC-1604AN
ALC-3202AN
Connecting people through extraordinary audiovisual experiences™
In an effort to reduce the quantity of printed material while
enhancing the quality of content, we have decided to adopt
a new approach for the production of this quick guide. The
safety and regulatory information is included in the box
along with a QR code directing the installer/user to this
Installation and Operation Guide pdf available on Biamp's
website.
Vital information descriptions have been condensed in two
pages, and all illustrations and tables follow. Each section's
color bar (ex.
) refers to the outlined area on front or rear
panel of the ALC image and the corresponding information
tables. Call-out bubbles
elements of those sections.
Please take time to read and understand all warnings and
safety instructions on the next few pages of this manual.
ArmoníaPlus is a trademarked control software product
from Powersoft S.p.A.
Additional important information regarding ArmoníaPlus
software and networking setup is explained in this
Cornerstone article.
1
/
A
guide you to specific
W:
www.biamp.com
