- Page 1 ELD-1 OPERATION MANUAL 2019 585.0263.90F...
- Page 2 ELD-1 Product Description The ELD-1 is a networked safety device for use with the Vocia VA-8600, VA-8150CV, VA-4300CV, VA- 2060(e), VA-4030(e) amplifiers and VO-4e Output device. It is an integral part of standards-compliant voice evacuation and paging notification systems.
- Page 3 ELD-1 Setup and Installation Setup and Use The Vocia software provides an intuitive interface for configuration of the ELD-1. The information supplied by this manual relates to physical connections and assignment. For more details on software setup, please consult the Vocia Help File. Installation The ELD-1 may be mounted in a rack or on a wall using four screws at the end of the flanges or two screws in the keyholes on the rear.
- Page 4 ELD-1 Front Speaker Line Connecter A plug-in barrier-strip connector on the ELD-1 connects the device to the end of the speaker line. The device needs to be connected to an appropriate monitoring point on the speaker cable—typically after the last speaker on the run. Connect the speaker line between the Com pin and the appropriate Low or High pin.
- Page 5 Fault Indication When a fault is detected on the speaker line or amplifier channel, the lower left LED on the RJ-45 socket will illuminate Amber and remain on until the fault is resolved. Providing a valid PoE power source and Ethernet connectivity is available the ELD-1 the solid amber indicator can be used to physically identify the ELD-1 that is reporting an issue.
