Summary of Contents for dynarex D100
- Page 1 Reorder No. 12001 Manufactured for: Dynarex Corporation 10 Glenshaw Street Orangeburg, NY 10962 USA • www.dynarex.com Made in China Long-Term Care Bed D100 User Manual...
- Page 2 • DO NOT use accessories that are not designed or ap- may be damaged by inappropriate handling, e.g. by kinking, proved for use with the bed. Use only Dynarex approved shearing or other mechanical damages. The cables are only parts and accessories. DO NOT make modifications to the replaceable by authorized Dynarex service personnel.
- Page 3 RF emissions according to CIS- Class B The care bed is designed PR11 for use in all establishments including domestic establish- ments and those determined to be directly connected to a public supply. Long-Term Care Bed • D100 (Reorder No. 12001)
- Page 4 Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m. Long-Term Care Bed • D100 (Reorder No. 12001)
- Page 5 Note 2: These guidelines may not apply in all situations. Propagation of electromagnetic waves is affected by absorption and reflection from structures, objects and persons. Long-Term Care Bed • D100 (Reorder No. 12001)
-
Page 6: Technical Specifications
Yes, optional Operating Temperature 40°F-105°F (5°C-40°C) Storage Temperature 15°F-120°F (-10°C-50°C) Operation & Storage Humidity 20%-80% Operation & Storage Atmospheric Pressure 700-1060 hPa Operation & Storage Altitude ≤ 3000 m Noise Level < 50db(a) Long-Term Care Bed • D100 (Reorder No. 12001) - Page 7 Bed Assembly × 1 Head/footboard Wall Bumper Bar × 1 Insertion Plate × 4 Mattress Retainer × 6 M10 Hex Bolt × 8 Allen Wrench (size 5 mm) Wrench × 1 NOT INCLUDED Long-Term Care Bed • D100 (Reorder No. 12001)
- Page 8 2. Insert the lock pin through the mounting plate into the headboard to secure the headboard in place. Repeat on the other mounting plate. 3. Repeat the same procedure for the footboard installation. Long-Term Care Bed • D100 (Reorder No. 12001)
- Page 9 Slide the 1. Battery Backup Port U-shaped insert into the assist bar bracket. 2. Backrest Motor 3. Knee-break Motor 4. Bed Lift Motor 5. Spare 6. Port for hand pendant or staff control Long-Term Care Bed • D100 (Reorder No. 12001)
- Page 10 4. Disconnect the hand pendant connection to the be an audible click. control box and replace it with a cable splitter. 8. Plug the bed into an appropriate outlet and test functions to ensure all functions work correctly. Long-Term Care Bed • D100 (Reorder No. 12001)
- Page 11 4. Connect the back up battery cord to the control box. The connection port is indicated with a bat- tery symbol above. 5. Close the locking lid, there should be a audible click, switch the power supply back on. Long-Term Care Bed • D100 (Reorder No. 12001)
-
Page 12: Equipment Operation
3. Use button 5 & 6 to adjust the backrest and knee break up or down simultaneously (Auto Contour feature) 4. Use button 7 & 8 to raise or lower the bed platform. Long-Term Care Bed • D100 (Reorder No. 12001) - Page 13 Lower Bed Rail: Press the release button and slowly Lower Assist Bar: Pull the release knob and slowly lower the bed rail to its lowest position. lower the bar to its lowest position. Long-Term Care Bed • D100 (Reorder No. 12001)
-
Page 14: Troubleshooting Guide
Thermal shut down may have Wait at least 20 minutes before occurred. trying the functions again. The bed is intended to be used for 2 min every 20 min. Long-Term Care Bed • D100 (Reorder No. 12001) -
Page 15: Limited Warranty
Refer to Assembly Instructions. not tightly secured. LIMITED WARRANTY Your Dynarex Product is warrantied to be free of defects in • Products where the serial number has been removed or materials and workmanship for Fifteen (15) years on struc- defaced tural Steel, Three (3) years on electrical and mechanical, •... -
Page 16: Service Record
SERVICE RECORD DATE PERFORMED BY CONDITION REPORT Long-Term Care Bed • D100 (Reorder No. 12001) - Page 17 SERVICE RECORD DATE PERFORMED BY CONDITION REPORT Long-Term Care Bed • D100 (Reorder No. 12001)
