dynarex VS1 User Manual

Vital signs monitor with spo2, blood pressure and temperature modules user manual
Hide thumbs

Advertisement

Quick Links

Download this manual
Manufactured for:
Dynarex Corporation
10 Glenshaw Street
Orangeburg, NY 10962
USA • www.dynarex.com
Made in China
Vital Signs
Monitor
with SpO
and Temperature Modules
, Blood Pressure
2
User Manual
Reorder Nos.
10840-10841
IPX1
CAUTION: Federal (USA) law
prohibits this device to sale by
or on the order of a physician.
Model No. VS1

Advertisement

loading
Need help?

Need help?

Do you have a question about the VS1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for dynarex VS1

Summary of Contents for dynarex VS1

  • Page 1 USA • www.dynarex.com Made in China Vital Signs Monitor with SpO , Blood Pressure and Temperature Modules User Manual IPX1 CAUTION: Federal (USA) law prohibits this device to sale by or on the order of a physician. Model No. VS1...

  • Page 2: Product Information

    Product Model: VSI l Product Name: Vital Signs Monitor l Manufactured for: Dynarex Corporation 10 Glenshaw Street, Orangeburg, NY 10962, USA • www.dynarex.com l Manufacturer name: Guangdong Biolight Meditech Co., Ltd. Address: No.2 Innovation First Road, Technical Innovation Coast, Hi-tech Zone, Zhuhai, P.R.

  • Page 3: Manufacturer's Responsibility

    Manufacturer's Responsibility Only under the following circumstances will manufacturer be responsible for the safety, reliability and performance of the instrument: l All the installation, expansion, readjustment, renovation or repairs are conducted by the personnel certified by manufacturer. l The storage condition, operation condition and electrical status of the instrument conform to the product specification.

  • Page 4: Table Of Contents

    Content Chapter 1 General Introduction ................1-1 1.1 Intended Use ..........................1-1 1.2 Main Unit ..........................1-2 1.3 Work mode ..........................1-7 Chapter 2 Safety ......................2-1 2.1 Safety Information ........................2-1 2.2 Safe Operation Conditions ......................2-4 2.3 Equipment Symbols ........................2-5 2.4 Packaging symbols ........................
  • Page 5 5.7 Silence ............................5-6 5.8 Alarm when power is lost ......................5-7 Chapter 6 SpO ......................6-1 6.1 Introduction ..........................6-1 6.2 Safety Information ........................6-1 6.3 Monitoring Procedure ....................... 6-2 Display ..........................6-3 6.4 SpO ..........................6-5 6.5 Setting SpO 6.6 Masimo Information .........................
  • Page 6 9.6 Calibrating ..........................9-8 9.7 Safety Information ........................9-9 Chapter 10 Reviewing ..................... 10-1 10.1 Entering the Reviewing Menu ..................... 10-1 10.2 Reviewing Details ........................ 10-1 Chapter 11 Recording .................... 11-1 11.1 Recorder ..........................11-1 11.2 Recording Type ........................11-1 11.3 Starting/Stopping Recording ....................
  • Page 7 Appendix B Factory Defaults ..................12 B.1 Patient messages ........................12 B.2 Alarm ............................12 B.3 Interface Setup .......................... 12 ............................12 B.4 SpO B.5 NIBP ............................13 (LoFlo) ..........................14 B.6 CO B.7 Temp ............................14 Appendix C Alarm Messages ..................15 C.1 Physiological alarm Messages ....................

  • Page 8: Chapter 1General Introduction

    Vital Signs Monitor User’s Manual Chapter 1General Introduction 1.1 Intended Use The vital signs monitor is intended to be used for monitoring, displaying, reviewing, storing and alarming of multiple physiological parameters of patients, including Pulse Oxygen Saturation (SpO ), Pulse Rate (PR), Non-invasive Blood Pressure (NIBP), Carbon dioxide (CO2) and Temperature (Temp).

  • Page 9: Main Unit

    Vital Signs Monitor User’s Manual 1.2 Main Unit 1.2.1 Front View Fig.1-1 1. Physiological alarm indicating lamp When a physiological alarm occurs, this lamp will light up as defined below: l High level alarm: the lamp quickly flashes red. l Medium level alarm: the lamp slowly flashes yellow. l Low level alarm: the lamp lights yellow without flashing.
  • Page 10 Vital Signs Monitor User’s Manual 3. Fast temp/Infrared ear temp(optional) 4. Display screen NIBP: press this button to start or stop NIBP measurement. RECORD: press this button to start or stop recording. SUSPEND/SILENCE: l Press this button to pause or reactive the alarms. l Press and hold this button for 1 second to silence the system sound.

  • Page 11: Side View

    Vital Signs Monitor User’s Manual l Orange: When the AC mains is not connected and monitor is powered by battery. l Off: When the AC mains is not connected. Battery charging indicating lamp l Light up: When the battery is being charged. l Off: When the battery is fully charged or no battery in monitor.

  • Page 12: Rear View

    Vital Signs Monitor User’s Manual 1.2.3 Rear View Fig.1-3 1. Temp connector 2. Grounding terminal Base on the requirements of safety and anti-interference, the monitor must be connected with equipotentiality system individual. When connected together, the various parts of an equipment or of a system will be brought to the same potential, not necessarily being the earth (ground) potential.

  • Page 13: Bottom View

    Vital Signs Monitor User’s Manual 6. USB socket 7. Nurse call connector 8. Fan and horn orifice Caution l The VGA ， USB and SD interface can only connected to the equipment with standard interface. l All the simulation and digital equipment connected with this monitor must be the products certified by the designated IEC standards (e.g.

  • Page 14: Work Mode

    Vital Signs Monitor User’s Manual 1.3 Work mode The monitor has two working modes: Clinic Mode and Monitor Mode. 1.3.1 Clinic Mode Clinic Mode refers to that the monitor is used for monitoring of a number of patients one by one by outpatient doctor. Each patient has his/her own ID number, and the monitoring results of patients are saved according to their ID numbers.
  • Page 15 Vital Signs Monitor User’s Manual Alarm Review With With Parameter Storage With With Alarm Messages Storage With Without Nurse Call With Without Communicating with Center With With Computer Multi-patient Without With...

  • Page 16: Chapter 2 Safety

    Vital Signs Monitor User’s Manual Chapter 2 Safety 2.1 Safety Information Warning l Indicates a potential hazard or unsafe practice that, if not avoided, will result in death or serious injury. Caution l Indicates a potential hazard or unsafe practice that, if not avoided, could result in minor personal injury or product/property damage.
  • Page 17 Vital Signs Monitor User’s Manual not have protective earth conductor, please do not use the socket and use battery to provide power to the monitor. l To avoid explosion hazard, do not use the monitor in the presence of flammable anesthetics, vapors or liquids.
  • Page 18 Vital Signs Monitor User’s Manual 2.1.2 Caution Caution l To ensure patient safety, use only parts and accessories specified in this manual. l At the end of its service life, the monitor, as well as its accessories, must be disposed of in compliance with the guidelines regulating the disposal of such products.

  • Page 19: Safe Operation Conditions

    Vital Signs Monitor User’s Manual l The software was developed in compliance with IEC 62304. The possibility of hazards arising from software errors is minimized. l This manual describes all features and options. Your monitor may not have all of them. l The service life of this monitor is 5 years.

  • Page 20: Equipment Symbols

    Vital Signs Monitor User’s Manual 2.3 Equipment Symbols Symbol Symbol Note Type CF applied part, defibrillation protected The unit displaying this symbol contains an F-Type isolated (floating) applied part providing a high degree of protection against shock, and is defibrillator-proof. Type BF applied part, defibrillation protected The unit displaying this symbol contains an F-Type isolated (floating) applied part providing a high degree of protection against shock, and is...

  • Page 21: Packaging Symbols

    Vital Signs Monitor User’s Manual Symbol Symbol Note Temperature limitation Humidity limitation Pressure limitation IPX1 Degree of protection against ingress of liquid Symbol marked on a tag attached to the supply cord of the monitor to warn that Hospital Only the supply cord should be connected to the sockets which are Hospital Only to achieve grounding reliability.

  • Page 22: Chapter 3 Operations

    Vital Signs Monitor User’s Manual Chapter 3 Operations 3.1 Unpacking and Checking 1. Unpacking Before unpacking, examine the packing case carefully for signs of damage. If any damage is detected, contact the carrier. If the packing case is intact, open the package. 2.

  • Page 23: Getting Started

    Vital Signs Monitor User’s Manual 3.2 Getting Started 3.2.1 Inspecting the Monitor 1. Before you start to make measurements, carry out the following checks on the monitor including all connected modules. ——Check for any mechanical damage; ——Check for any incorrect connection of all the external cables and accessories. 2.

  • Page 24: Shutting Off The Monitor

    Vital Signs Monitor User’s Manual 3.2.3 Starting Monitoring 1. Decide which parameter should be monitored or measured. 2. Install required modules or sensors. 3. Check whether the installation of modules or sensors is correct. 4. Check whether all kinds of settings are correct. 5.

  • Page 25: General Setup

    Vital Signs Monitor User’s Manual Style of other menus is the same as that of the main menu, parts of which are as follows. 1. Menu title: Name of the menu. 2. Main display area: Area to display options, buttons or prompt messages. “ ”...

  • Page 26: Alarm Volume

    Vital Signs Monitor User’s Manual 3.6.4 Adjusting the Volume l Alarm Volume Under the Monitor Mode: 1. Select【Menu】→【Sound Setup】. 2. Select【Alarm Volume】→choose a desired value. l Beep Volume 1. Select【Menu】→【Sound Setup】. 2. Select【Beep Volume】→choose a desired value. 3.7 Default Setups Caution l In case of power failure, after restart, the system will restore the setup before power failure automatically.
  • Page 27 Vital Signs Monitor User’s Manual ——An alarm condition destined occurs. ——The monitor is not in the state of alarm paused or system silence. Warning l The nurse call function should not be used as the primary patient alarm inform source. It is necessary for combining the auditory and visual alarm signal and the patient clinical feature and symptom as the primary information to medical and nursing staff about the physiological condition of the patient.

  • Page 28: Id Name

    Vital Signs Monitor User’s Manual 3.9 ID Name You need to set ID name under the Clinic Mode. 1. 【Menu】→【System Setup】→【ID Name】 to enter ID Name menu. 2. Define the ID Name rule according to your usage. 3.10 Patient ID You can use a barcode scanner to input the Patient ID, please go through the following steps before input the patient ID: 1.

  • Page 29: Chapter 4 User Interface

    Vital Signs Monitor User’s Manual Chapter 4 User Interface 4.1 Display Style Display style of user interface can be set according to your need. Including: ——Screen brightness. ——Display color of wave and parameter. ——Sweep mode of wave. 4.1.1 Adjusting the Screen Brightness 1.

  • Page 30: Screen Layout

    Vital Signs Monitor User’s Manual 4.2 Screen Layout The monitor has configured with a color TFT LCD to display parameters and waves of patient’s SpO , NIBP and CO . The following figures are screens of the monitor. 4.2.1 Standard Screen Parameters displayed under the screen are SpO , CO , SpO...

  • Page 31: Setup Menu

    Vital Signs Monitor User’s Manual 5. TEMP Parameter Area It is to display temperature parameter. Select “TEMP” to enter【TEMP Setup】 menu. 6. SpO Wave Area It is to display SpO wave. Select ” SpO Wave” to enter 【 SpO Wave Setup 】 menu.
  • Page 32 Vital Signs Monitor User’s Manual 4.2.2 NIBP Review Under the screen, you can view the measurement of NIBP. 4.2.3 Trend Screen...

  • Page 33: Alarm Screen

    Vital Signs Monitor User’s Manual The screen is called “Trend Screen” under Monitor Mode while called “Clinic Review” under Clinic Mode. Under the screen you can view the measurement of each parameter. l Storage Setup 1. Select【Menu】→【Storage Setup】to enter【Storage Setup】menu. 2.

  • Page 34: Trend Graph

    Vital Signs Monitor User’s Manual 4.2.5 Trend Graph 5. Parameter displaying area 6. The selected parameter 7. Setting interval 4. Scale 3. Time scale 8. Cursor 2. Page down 2. Page up 1. Selecting parameter 9. Setting step You can enter TrendGraph screen through the screen changing button as shown in chapter 1 section 1.2 main unit.

  • Page 35: Patient Information

    Vital Signs Monitor User’s Manual 4. Scale It is to scale the value of parameters. 5. Parameter displaying area It is to display values of all the monitored parameters at the time where the cursor indicates now. 6. The selected parameter It is to display the name of the selected parameter and its value at the time where the cursor is.

  • Page 36: Demo

    Vital Signs Monitor User’s Manual 4.3.2 Admitting a new patient When the patient to be monitored is a new one, please select【New Patient】to enter【New Patient】menu. Input new patient’s ID, Name, Type, Gender and Age. At last，select【OK】to keep the setting of new patient. 4.3.3 Patient ID l Clinic Mode In【Patient Info】menu, when selecting【New Patient】,【Patient ID】will be...

  • Page 37: Machine Maintenance

    Vital Signs Monitor User’s Manual 4.4.2 Turn off Demo 1. Select【Menu】→【System Setup】to enter the system setup menu. 2. Set【Demo】to【Off】. 4.5 Machine Maintenance Select【Menu】→【System Setup】→【Machine Mainte】→input the required passwords to enter 【Machine Mainte】menu. 1. NIBP Test: Select【NIBP Test】to test NIBP. 2. NIBP PR: Select【On】 or 【Off】. 3.

  • Page 38: Chapter 5 Alarm

    Vital Signs Monitor User’s Manual Chapter 5 Alarm Alarm refers to a prompt that is given by the monitor for medical personnel through visual, audible and other means when a vital sign appears abnormal or technical problem occurs. Note l The monitor generates all the audible and visual alarms through speaker, alarm lamp and screen.

  • Page 39: Alarm Category

    Vital Signs Monitor User’s Manual 5.1 Alarm Category According to character of alarm, the monitor’s alarms can be classified into three categories: physiological alarms, technical alarms and prompt messages. l Physiological alarms Physiological alarms are triggered by a monitored parameter value that violates set alarm limits or an abnormal patient condition.

  • Page 40: Alarm Indicators

    Vital Signs Monitor User’s Manual 5.3 Alarm Indicators When an alarm occurs, the monitor will indicate it through the following means: l Alarm tone: According to alarm level, speaker in the monitor gives alarm sound in different tone. l Alarm lamp: According to alarm level, alarm lamp on monitor flashes in different color and speed.
  • Page 41 Vital Signs Monitor User’s Manual When a technical alarm occurs, the alarm levels are indicated in following different visual ways: Alarm level Visual prompt Medium Alarm lamp flashes in blue with 0.5 Hz. Alarm lamp lights on in cyan without flashing. Caution l When multiple alarms of different levels occur at the same time, the monitor will select the alarm of the highest level and give visual and audible...

  • Page 42: Setting Alarm Volume

    Vital Signs Monitor User’s Manual Alarm level symbol background color Medium yellow cyan l Prompt messages Prompt messages are displayed in technical alarm area. Prompt messages have no color and visual and audible alarm indication. 5.4 Setting Alarm Volume You need to set alarm volume only under monitor mode. 1.

  • Page 43: Pausing Alarms

    Vital Signs Monitor User’s Manual 2. Set【High Lim】and【Low Lim】to a desired value. 5.6 Pausing Alarms Press the button on the front panel of monitor, you can suspend all alarm indicators of the monitor: l The visual alarm and audible alarm are all suspended. l The parameters of physiological alarm stop flashing.

  • Page 44: Alarm When Power Is Lost

    Vital Signs Monitor User’s Manual 5.8 Alarm when power is lost After a loss of power, the alarm settings prior to the power loss are restored. After restarting the monitor, if select continuing the current patient, the previous settings will be maintained, and if a new patient is selected, the corresponding factory default settings will be loaded.

  • Page 45: Chapter 6 Spo

    Vital Signs Monitor User’s Manual Chapter 6 SpO 6.1 Introduction The measurement of oxygen saturation of arterial blood (also known as pulse oxygen saturation, usually shortened as SpO ) adopts the principles of light spectra and volume tracing. The LED emits lights with two specific wavelengths, which are selectively absorbed by oxygenated hemoglobin and deoxyhemoglobin.

  • Page 46: Monitoring Procedure

    Vital Signs Monitor User’s Manual l Before use, the operator must ensure the compatibilities of the monitor, sensor and extension cables; otherwise, this may lead to the burning of patients; do not use damaged sensor or extension cable. Do not soak the sensor into water or make it wet, otherwise it may be damaged.

  • Page 47: Spo Display

    Vital Signs Monitor User’s Manual 6.4 SpO Display 6.4.1 BLT SpO2 l Waveform Display l Parameter Display Pleth waveform “%” indicates SpO value Pleth bar Pulse Rate (obtained from SpO SpO2 signal intensity Indicator of signal intensity Description “Weak Signal” The signal strength is too weak to measure.

  • Page 48: Masimo Spo2

    Vital Signs Monitor User’s Manual 6.4.2 Masimo SpO2 The Masimo module is intended to monitor the SpO , PR, PI, SpMet, SpHb, PVI, SpCO SpOC of patients. The following figure shows the SpO display screen, the display on your monitor may be looked slightly different. 1.

  • Page 49: Setting Spo

    Vital Signs Monitor User’s Manual e) Carboxyhemoglobin Saturation (SpCO): SpCO is a value that represents the percentage of carboxyhemoglobin saturation within the blood. f) Pleth Variability Index (PVI): PVI is a measure of peripheral perfusion changes secondary to respiration, or the PI amplitude modulation over a respiration, and can be closely related to intrathoracic pressure changes.
  • Page 50 Vital Signs Monitor User’s Manual critical patient is monitored, selecting shorter averaging time will help understanding the patient’s state. Select“SpO ”to ente【 r SpO Setup】 menu, Se【 t Average Time】 to a desired value. 6.5.5 Setting Desat Limit Desat Limit means that when the measuring value is lower than the limit, high alarm will be triggered.
  • Page 51 Vital Signs Monitor User’s Manual l Setting Fast Sat mode The Fast Sat mode is clinically applicable during procedures when detecting rapid changes in oxygen saturation is paramount such as induction, intubation and sleep studies. Selec 【 t Fast Sat Mode 】 in the SpO parameter setting menu, you can selec【...

  • Page 52: Masimo Information

    Vital Signs Monitor User’s Manual l Setting SpHb Unit You can select【SpHbUnit】in the SpO parameter setting menu, and select the unit as required. The options are【g/dL】and【mmol/L】. 6.6 Masimo Information n Masimo Patents: This device is covered under one or more of the following U.S.A. patents: 5,758,644, 5,823,950, 6,011,986, 6,157,850, 6,263,222, 6,501,975 and other applicable patents listed at: www.masimo.com/patents.htm.

  • Page 53: Chapter 7 Nibp

    Vital Signs Monitor User’s Manual Chapter 7 NIBP 7.1 Introduction The monitor uses the oscillometric method for measuring NIBP. It is applicable for adult, pediatric and neonatal patients. The method of oscillometric indirectly estimates the systolic and diastolic pressures within the blood vessels by measuring the change of the pressure within blood pressure cuff along with the volume of the arteries and calculates the average pressure.

  • Page 54: Measurement Limitations

    Vital Signs Monitor User’s Manual The continuous cuff pressure due to connection tubing kinking may cause the effect of blood flow interference and resulting harmful injury to the patient. Do not use the cuff over a wound, as this can cause further injury. The pressurization of the cuff can temporarily cause loss of function of simultaneously used monitoring equipment on the same limb.
  • Page 55 Vital Signs Monitor User’s Manual Note To obtain accurate routine resting blood pressure measurements for the condition hypertension including as following steps: Keep the patient in a suitable position, including 1) Comfortably seated; 2) Legs uncrossed; 3) Feet flat on the floor; 4) Back and arm supported;...

  • Page 56: Auto Measurement

    Vital Signs Monitor User’s Manual under the cuff, ensuring the air pipe outside the cuff does not knot and the white line on the cuff shall be within the range “ ”, otherwise the cuff shall be replaced. The monitor is applicable for standard neonatal cuff, pediatric cuff and adult cuff. (Including arm cuff and thigh cuff).

  • Page 57: Nibp Display

    Vital Signs Monitor User’s Manual Start the Auto measurement manually for the first time, and then enter the Auto mode. The monitor will start the measurement continually repeated in the set interval after the first measurement. If you press the button during the auto measurement, the measuring will be paused.

  • Page 58: Setting Nibp

    Vital Signs Monitor User’s Manual 7.7 Setting NIBP Select ”NIBP” to enter【NIBP Setup】menu. 7.7.1 Setting Unit In【NIBP Setup】menu, set【Unit】to【mmHg】or【kPa】. 7.7.2 Setting Initial Press In【NIBP Setup】menu, set【Init Press】to a desired value. 7.8 Setting Venipuncture Press You can use the NIBP cuff to cause sub-diastolic pressure, and block the venous blood vessel to assist venous puncture.
  • Page 59 Vital Signs Monitor User’s Manual l One adult cuff l One inflate hose l One Cylinder Metal Vessel Procedure of the air leakage test: 1. Enter【Patient Info】menu, set【Type】to【Adult】. 2. Connect the cuff securely with the socket for NIBP air hole. 3.

  • Page 60: Nibp Calibration

    Vital Signs Monitor User’s Manual 7.11 NIBP Calibration The maintenance and calibration of NIBP measurement is necessary for every year. If you need to maintain NIBP, please contact the professional service personnel. Calibration tools: 3 way connector, pipe, roundness pump, metal container(500±25 ml), standard manometer(Calibration already, precision over 1mmHg) 1.

  • Page 61: Chapter 8 Co

    Vital Signs Monitor User’s Manual Chapter 8 CO 8.1 Introduction The monitor adopts infrared absorption technology to measure the carbon dioxide ) concentration in the breathing airway of patient. Because CO molecule can absorb infrared light of special wavelength, and the amount of absorbed infrared light directly relates to the concentration of CO therefore while the infrared light radiated from the infrared light source passing through the gas sample containing CO...
  • Page 62 Vital Signs Monitor User’s Manual Note Inserting the sampling tube into the receptacle automatically starts the sampling pump. Removal of the sampling tube turns the sample pump off. To remove the sampling tube from the sampling tube receptacle, press down on the locking tab and pull the sampling tube from the receptacle. 3.
  • Page 63 Vital Signs Monitor User’s Manual For non-intubated patients: Place the nasal cannula onto the patient. Shown as 3） follows: For patients prone to mouth breathing use an oral-nasal cannula. Trim the oral 4） sampling tip if necessary to fit the patient. It should extend down past the teeth and be positioned in the mouth opening.

  • Page 64: Factors Affecting Co2 Measurement

    Vital Signs Monitor User’s Manual 8.3 Factors affecting CO2 measurement Known adverse effects on CO2 measurement due to the following: 1. Quantitative effects of gas sample humidity or condensate. 2. Leaks or internal venting of sampled gas. 3. Cyclical pressure of up to 10 kPa（100cmH2O） 4.

  • Page 65: Setting Unit

    Vital Signs Monitor User’s Manual 8.5.3 Setting Unit 1. Select “CO ” to enter【CO Setup】menu. 2. Set【Unit】to【mmHg】,【KPa】and【%】. 8.5.4 Setting Scan Speed l CO Scan Speed Select “CO ” to enter【CO Setup】menu. Set【Scan Speed】 to【6.25 mm/s】 , 【 12.5 mm/s】 , 【 25 mm/s】 or【50 mm/s】 . Wave Scan Speed 1.

  • Page 66: Calibrating

    Vital Signs Monitor User’s Manual Caution Always ensure that the sampling tube is properly connected to the microflow CO module before zeroing. Do not attempt zeroing for 20s after removing the adapter or cannula from the patient’s airway. This time allows any CO remaining in the adapter or cannula to dissipate before zeroing.

  • Page 67: Removing Exhaust Gases

    Vital Signs Monitor User’s Manual 8.8 Removing Exhaust Gases Warning When using the microflow CO measurement on patients who are receiving or have recently received anesthetics, connect the outlet to a scavenging system, or to the anesthesia machine/ventilator, to avoid exposing medical staff to anesthetics.

  • Page 68: Chapter 9 Temp

    Vital Signs Monitor User’s Manual Chapter 9 Temp 9.1 Introduction 9.1.1 Principle of Temp measurement The monitor’s temp measurement is divided into the infrared ear temp measurement and fast temp measurement. Infrared ear temp is monitoring the human ear cavity’s infrared launch through the infrared temperature measurement probe.

  • Page 69: Monitoring Procedure

    Vital Signs Monitor User’s Manual The structure of the Fast Temp probe is as follows: Auxiliary button Probe 9.2 Monitoring Procedure 9.2.1 Infrared ear temp measurement 1. Connect the temperature module to the main unit, press the power button of the main unit to turn on the monitor.
  • Page 70 Vital Signs Monitor User’s Manual 3. Pull back the ear cavity gently to make it straight, and fix the head of the patient. 4. Measuring method: When the temperature module is in the off state or the unit sign glints, please carry out the monitoring. Insert the temperature probe into the ear at the ear hole, then press “START”, please don’t read the temperature information until you hear the buzzer sound.
  • Page 71 Vital Signs Monitor User’s Manual 9.2.2 Fast temp measurement Fast Temp: 1. First on the basis of the patient's condition, select the appropriate measurement sites: Oral or Axillary 2. Three modes of measurement: Fast , Cold , Monitor Oral measurement: Fast mode and Cold mode are available; Axillary measurement: Fast mode, Monitor mode and Cold mode are available;...
  • Page 72 Vital Signs Monitor User’s Manual axillary temperature needs about 16 seconds); If the patient is measured in monitor mode, the measurement interface remains in this state, and the real-time measurement data will be displayed all the time.
  • Page 73 Vital Signs Monitor User’s Manual 5. After the measurement is completed, the screen flashes and prompts the operator "Please remove cover!" and "Return probe to sheath!". Plug the probe back into place. Caution l When oral temp measurements and axillary temp measurements are operated ，...

  • Page 74: Temp Display

    Vital Signs Monitor User’s Manual 9.3 Temp Display Unit Unit Temp value Site Temp value Probe indication Mode Infrared ear Temp interface Fast Temp interface 9.4 Setting Temp 9.4.1 Setting Unit 1. Select “TEMP” to enter the temp setup menu. 2.

  • Page 75: Setting Alarm

    Vital Signs Monitor User’s Manual 9.4.3 Setting measuring modes (only for fast temp measurement) 1. Select “TEMP” to enter the temp setup menu. 2. Set【Mode】 to【Fast】 or【Cold】 or 【Monitor】 . The new setup will become effective at the next monitoring. 9.4.4 Setting Alarm Select【menu】→【Alarm Setup】...

  • Page 76: Calibrating

    Vital Signs Monitor User’s Manual l If the ambient temperature is lower than 10.0℃, the LCD will display “AL” and the buzzer sounds “B-B-B-B-B”; l If the ambient temperature is higher than 40.0℃, the LCD will display “AH” and the buzzer sounds “B-B-B-B-B”; l The temperature module has a fever alarm function: While the temperature is higher than 37.5℃, the buzzer sounds “B-B-B”.

  • Page 77: Safety Information

    Vital Signs Monitor User’s Manual 9.7 Safety Information Warning l Please change the earcap after each use to ensure the veracity and avoid cross infecting. l At least every half year or one year carries out a temperature measure calibration, or carries out the calibration according to the hospital regulation.

  • Page 78: Chapter 10 Reviewing

    Vital Signs Monitor User’s Manual Chapter 10 Reviewing Review means reviewing the patients’ relevant data that have been saved by the monitor previously. Review function is available in Clinic Mode only. In Monitor Mode, you may review the trend data, NIBP measurement data and alarm events of the monitored patient by use of screen changing key.
  • Page 79 Vital Signs Monitor User’s Manual Caution l No matter where the current cursor is in the Data Manage dialog box, the successful scanning result by using a barcode scanner will fill in the Lookup ID Record automatically. The ID will be replaced instead of accumulating when repeated scanning occurs.

  • Page 80: Chapter 11 Recording

    Vital Signs Monitor User’s Manual Chapter 11 Recording 11.1 Recorder This monitor uses the thermal recorder which supports various record type. It can output the patient information, measurement data, review data and two waveforms at most. 11.2 Recording Type The records can be divided into the following types according to trigger modes: 1.

  • Page 81: Installing Recording Paper

    Vital Signs Monitor User’s Manual 2. Set【Cycle Record Time】to【5 Sec】,【10 Sec】or【30 Sec】. 11.4.3 Setting Alarm Record 1. Enter【Recorder Setup】menu through the above methods. 2. Set【Alarm Record】to【On】or【Off】. 11.4.4 Setting Alarm Record Time 1. Enter【Recorder Setup】menu through the above methods. 2. Set【Alarm Record Time】to【5 Sec】,【10 Sec】or【30 Sec】. Caution l The contents recorded will be covered by the new one when the contents of the log reach its capacity.

  • Page 82: Clearing Jam Paper

    Vital Signs Monitor User’s Manual Caution Must use the thermo-sensitive record paper; otherwise, it will lead to recording failure, bad-quality record or damage of thermo-sensitive printing head. Do not pull out the recording paper during recorder printing; otherwise, the recording meter may be damaged. Unless for paper replacement or fault remedy, do not keep the recorder door open.

  • Page 83: Chapter 12 Battery

    Vital Signs Monitor User’s Manual Chapter 12 Battery 12.1 Introduction The monitor can be fitted with rechargeable battery to ensure its continuous work after the failure of alternating current power supply, and it needs no special maintenance under the normal condition. While the monitor connecting with alternating current power, no matter whether the monitor is operating or not, the battery always can be charged.

  • Page 84: Installing A Battery

    Vital Signs Monitor User’s Manual 12.2 Installing a Battery The battery compartment is in the bottom part of the monitor, please refer to the following steps when installing or charging the batteries. Turn off power of the monitor, and disconnect the power wire and other connected wires.

  • Page 85: Disposing Batteries

    Vital Signs Monitor User’s Manual Place the monitor in the charger stand and connect the AC mains. Allow the battery to be charged uninterruptedly for above 6 hours. Disconnect AC mains and allow the monitor to run on the battery until it shuts off.

  • Page 86: Chapter 13 Maintenance And Cleaning

    Vital Signs Monitor User’s Manual Chapter 13 Maintenance and Cleaning 13.1 Introduction Keep your equipment and accessories free of dust and dirt. To avoid damage to the equipment, follow these rules: Always dilute according the manufacturer’s instructions or use lowest possible concentration.

  • Page 87: Cleaning And Sterilizing Of Accessories

    Vital Signs Monitor User’s Manual wiped with lint-free soft cloth or sponge soaked in detergent. While cleaning, be careful and do not spill liquid onto the instrument and keep any liquid out of it. When wiping the side panel of monitor, you must be especially careful to keep water out of all kinds of cable and outlet on the panel.

  • Page 88: Temp Probe

    Vital Signs Monitor User’s Manual Attention Excessive or frequent cleaning may damage airbag, so don’t clean airbag unless necessary. Do not dry airbag and sheath in high temperature. If higher sterilization level is required, please choose disposal cuff. One disposal cuff can only be used for one patient. Carefully keep water and cleaning solution out of the connecting parts of cuff and monitor.
  • Page 89 Vital Signs Monitor User’s Manual Attention Do not sterilize sensor by ray, steam or epoxy ethane. Do not directly submerge sensor in liquid. To avoid long-time harm to sensor, it is suggested that sterilization to the product be conducted only when necessary according to the regulation of your hospital.

  • Page 90: Chapter 14 Accessories

    Vital Signs Monitor User’s Manual Chapter 14 Accessories Warning Use only accessories specified in this manual. Using other accessories may cause damage to the monitor. Disposable accessories are designed for single-patient use only. Reuse of them may cause a risk of contamination and affect the measurement accuracy.

  • Page 91: Nibp

    Vital Signs Monitor User’s Manual Extension cable Accessories Extension cable 15-031-0016 3. Masimo SpO Sensor Type Model / PN Patient category DCI / 2501 Adult finger Reusable DCIP / 2502 Pediatric finger Disposable Neo / 2514 Infant foot/hand Masimo SpO2 Extension cable Accessories Model / PN Extension cable...

  • Page 92: Co (Loflo)

    Vital Signs Monitor User’s Manual 14.3 CO (LoFlo) Accessories LoFlo CO sensor 16-100-0016 Airway adapter (adult) 15-100-0045 nasal cannula (adult) 15-100-0044 nasal cannule (pediatric) 15-100-0048 nasal cannule (infant) 15-100-0049 Extension cable 15-031-0010 14.4 Temp Accessories Model Earcap (Disposable) Probe Cover - 038 Fast temp electronic thermometer F3000-2 Fast temp probe cover...

  • Page 93: Appendix A Product Specifications

    Vital Signs Monitor User’s Manual Appendix A Product Specifications A.1 Safety Specifications A.1.1Classification Classification of Protection against electric shock Degree of protection against electric , NIBP, Temp :CF shock Degree of protection against hazards Not suitable of explosion Degree of protection against ingress IPX1 of liquid Mode of operation...

  • Page 94: Power Specifications

    Vital Signs Monitor User’s Manual Power Specifications A.1.3 Input voltage AC (100-240) V，(50/60) Hz Input power 70VA Fuse T1.6AL/250V，2-Φ5×20mm A.2 Physical Specifications Part Weight （ kg ） Size （ W×H×D ）（ mm ） About 2.5 (Including a lithium battery) Mainframe <160×130×260 About 0.16（Including the connecting wire）...

  • Page 95: Audio Indicating

    Vital Signs Monitor User’s Manual A.3.3 Battery Type Rechargeable lithium ion battery Model LB-08 Size 105mm×78mm×20mm Weight <360 g Quantity 11.1 VDC Rated voltage 4000 mAh Capability 8 hours Using a new and fully charged battery at 25℃ ambient Operating time temperature, connecting SpO sensor and NIBP work on AUTO mode for 15 minutes interval.

  • Page 96: Input Device

    Vital Signs Monitor User’s Manual A.3.6 Input device 5, NIBP, record, suspend/silence, screen switch and power switch Function button Knob With Barcode scanner Optional Temp module Button 1, START A.3.7 Connectors Center computer connector RJ-45, 10M/100M, TCP/IP Serial port RS232 serial port Nurse call Nurse call connector Equipotential grounding...

  • Page 97: Measurement Specifications

    Vital Signs Monitor User’s Manual Monitor Mode Patient quantity Trend data 3 kinds of resolution: 1Min, 5Min, 10Min. 1Min: can store 96 hours 5 Min: can store 480 hours 10 Min: can store 960 hours Alarm events 1000 5000 NIBP measurement record A.4 Measurement Specifications...
  • Page 98 Vital Signs Monitor User’s Manual Nellcor SpO2 module Measurement technic Nellcor SpO technic Monitoring parameters and PR (0～100)% Measurement range Resolution ± 2% ((70～100)% SpO ) (adult) Accuracy ± 3% ((70～100)% SpO )（neonate） unspecified (0～69)% (20～300) bpm Measurement range 1 bpm Resolution ±1% or ±...
  • Page 99 Vital Signs Monitor User’s Manual SpCO Measurement range 0% to 100% 0% to 40%：±3%（non-motion conditions） Accuracy ＞40%，unspecified SpMet Measurement range 0% to 100% 0% to 15%：±1%（non-motion conditions） Accuracy ＞15%，unspecified Measurement range 0.05% to 20% SpHb Measurement range 0 g/dl to 25 g/dl 8 g/dl to 17 g/dl：±1 g/dl（non-motion conditions）...
  • Page 100 Vital Signs Monitor User’s Manual Resolution 1 mmHg Static: ±3 mmHg Pressure accuracy Clinic: Average error: ±5 mmHg, standard deviation: ≤8 mmHg Unit mmHg, kPa PR range (40～240) bpm Recovery time after ≤10 s. defibrillation PR Resolution 1bpm The cuff will deflate automatically when power is off or time of measurement is beyond 120 seconds (90 seconds for neonate) or the Cuff auto deflation cuff pressure is beyond the overpressure protection set by software...
  • Page 101 Vital Signs Monitor User’s Manual Unit %, mmHg, kPa Recovery time after ≤10 s. defibrillation 0 mmHg to 40 mmHg, ±2 mmHg 41 mmHg to 70 mmHg, ±5% of reading 71 mmHg to 100 mmHg, ±8% of reading Accuracy ( 760mmHg， temperature is 25℃) 101 mmHg to 150 mmHg, ±10% of reading (when RR ＞80 rpm, all the range is ±12% of...
  • Page 102 Vital Signs Monitor User’s Manual Test GAS LEVEL shall be ±20% of the specified level. If intended for use with inhalation halogenated agents. If intended for use with Xenon. If intended for use with Helium l awRR Measurement range 0 rpm~150 rpm 0 rpm～70 rpm: ±1 rpm;...
  • Page 103 Vital Signs Monitor User’s Manual A.4.4.2 Fast Temp Sensor type Thermosensitive sensor Measurement range 30.0°C~43.0°C （86℉～109.4℉） Measurement part Oral, Axillary Measurement modes Fast modes, Monitor modes and Cold modes Unit ℃, ℉ 0.1℃/℉ Resolution Oral Fast mode: ±0.2℃ Axillary Fast mode: ±0.1℃ Accuracy Monitor mode ,Cold mode: ±0.1℃...

  • Page 104: Appendix B Factory Defaults

    Vital Signs Monitor User’s Manual Appendix B Factory Defaults B.1 Patient messages Patient messages Factory Defaults Type Adult B.2 Alarm Alarm setup Factory defaults ALM Volume Alarm paused time 2min B.3 Interface Setup Interface setup Factory defaults Brightness B.4 SpO B.4.1 General Setups setup Adult...

  • Page 105: Nibp

    Vital Signs Monitor User’s Manual B.4.2 Special Setups (Masimo) setup Factory defaults Sensitivity Mode Normal Fast Sat Mode Smart Tone Mode Waveform Mode Resp.out Alarm Delay SpHb Mode Arterial SpHb Average Time Long SpHb Precision SpHb Unit g/dL B.5 NIBP NIBP setup Adult Pediatric...

  • Page 106: Co (Loflo)

    Vital Signs Monitor User’s Manual B.6 CO (LoFlo) setup Adult Pediatric Neonatal Alarm switch Alarm Level Medium Alarm Print Limit Display Unit mmHg High alarm limit of EtCO 50 mmHg 50 mmHg 45 mmHg 20 mmHg 20 mmHg 30 mmHg Low alarm limit of EtCO 4 mmHg 4 mmHg...

  • Page 107: Appendix C Alarm Messages

    Vital Signs Monitor User’s Manual Appendix C Alarm Messages C.1 Physiological alarm Messages The third line in the cable is “Alarm level” of factory default, the ones with “*” mean that the level can be changed by users. Alarm messages Cause Level measuring value is above the high...

  • Page 108: Technical Alarm Messages

    Vital Signs Monitor User’s Manual Alarm messages Cause Level EtCO High EtCO measuring value is above high alarm limit. EtCO EtCO measuring value is below low alarm limit. FiCO High FiCO measuring value is above high alarm Medium * limit. awRR High awRR measuring value is above high alarm limit.

  • Page 109: Masimo Spo

    Vital Signs Monitor User’s Manual Alarm messages Cause Level sensor may be disconnected from the SpO2 Sensor off Medium patient or the monitor sensor error sensor failure signal weak signal is weak. Masimo SpO module Alarm messages Cause Level SpO2 No cable No cable connected SpO2 Replace cable Cable life expired;...
  • Page 110 Vital Signs Monitor User’s Manual SpO2 Low PVI SIQ PVI Signal IQ is low SpO2 Board Failure SpO2 board is failure SpO2 Failure SpO2 module is failure SpO2 Communication Error SpO2 communication is error SpO2 Enter Programming SpO2 is entering programming mode Mode SpO2 Weak signal SpO2 signal is weak...
  • Page 111 Vital Signs Monitor User’s Manual Alarm messages Cause Level sensor is off patient or off the sensor off monitor. airway adapter is disconnected with Check airway adapter sensor. measurement over measurement is over range and need range verify zero. Zero Required Sensor or module is not initialized.

  • Page 112: Prompt Messages

    Vital Signs Monitor User’s Manual Temp over range Up The ambient temp is higher than 43℃. Temp over range Down The ambient temp is lower than 30℃. C.3 Prompt Messages System Messages Cause Level Recording Recorder is in printing operation. No level Messages Cause...

  • Page 113: Appendix D Instructions On Environmental

    Vital Signs Monitor User’s Manual Appendix D Instructions on Environmental Aspects D.1 Instructions for minimizing environmental impact during normal use. Ø Instructions on how to install the monitor in order to minimize the ENVIRONMENTALIMPACT during its EXPECTED SERVICE LIFE; Try to keep the integrity of the non-disposable packing material and put away the packing materials for future use or put into the specified location where complying with the rules and regulations of the local and the hospital.

  • Page 114: Information For End Of Life Management

    Vital Signs Monitor User’s Manual Ø Emissions during NORMAL USE (e.g. WASTE water, WASTE consumable materials, acoustic, energy, heat, gasses, vapours, particulates, HAZARDOUS SUBSTANCES and other WASTE); During normal use, it is expected there will be some consumption of the medical device.
  • Page 115 Vital Signs Monitor User’s Manual °F ) to 60 (140 °F ) environment. Use the specified changer only. Read ℃ ℃ instructions for use. Maximum recommended ambient is 45 (125 °F ) dispose of ℃ used batteries promptly and in an environmentally-responsible manner. Do not dispose of the battery in normal waste containers.

  • Page 116: Appendix E Guidance And Manufacturer's Declaration Of Emc

    Vital Signs Monitor User’s Manual Appendix E Guidance and Manufacturer’s Declaration of EMC Guidance and manufacturer’s declaration – electromagnetic emissions -for all EQUIPMENT and SYSTEMS Guidance and manufacture’s declaration – electromagnetic emission The monitor is intended for use in the electromagnetic environment specified below. The customer or the user of the monitor should assure that it is used in such and environment.
  • Page 117 Vital Signs Monitor User’s Manual voltage variations on environment. If the user of the for 0.5 cycle for 0.5 cycle power supply input 40% U 40% U monitor requires continued lines (60% dip in U (60% dip in U operation during power mains IEC 61000-4-11 for 5 cycles for 5 cycles...

  • Page 118: Compliance Level

    Vital Signs Monitor User’s Manual Guidance and manufacturer’s declaration – electromagnetic immunity –for EQUIPMENT and SYSTEMS that are not LIFE-SUPPORTING Guidance and manufacture’s declaration – electromagnetic immunity The monitor is intended for use in the electromagnetic environment specified below. The customer or the user of monitor should assure that it is used in such an environment.
  • Page 119 Vital Signs Monitor User’s Manual Recommended separation distances between portable and mobile RF communications equipment and the EQUIPMENT or SYSTEM – for EQUIPMENT or SYSTEM that are not LIFE-SUPPORTING Recommended separation distances between portable and mobile RF communications equipment and the V6monitor The monitor is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled.

  • Page 120: Limited Warranty

    LIMITED WARRANTY Your Dynarex Product is warrantied to be free of defects in • Products where the serial number has been removed or materials and workmanship for two (2) years on the unit, and defaced six (6) months on the connected accessories included with •...
