Husqvarna AUTOMOWER 305 Operator's Manual page 4

25. Screws to attach the charging station
26. Power supply 6
27. Measurement gauge for installation of the
boundary wire (remove the measurement gauge
from the carton of the product)
1.4 Product overview Automower
3
2
1
6
7
15
13
14
22
21
20
23
1. Product body
2. Top cover
3. Hatch to display and keypad
4. STOP button
5. Rear wheels
6. Front wheels
7. Headlights
8. Blade disc
9. Skid plate
10. Contact plates
11. LED indicator for operation check of the charging
station, boundary wire and guide wire
6
The appearance can be different for different markets.
7
Found below the top cover.
8
Is a part of the installation kit which is purchased separately.
9
Is a part of the installation kit which is purchased separately.
10
Is a part of the installation kit which is purchased separately.
11
Is a part of the installation kit which is purchased separately.
4 - Introduction
28. Operator's Manual and Quick Guide
29. Blade
30. Low-voltage cable
31. Alarm decal
®
405X / 415X
4
8
9
5
16
25
24
26
12. Charging station
13. Display
14. Keypad
15. ON/OFF button
16. Rating plate with product identification code
17. Maintenance tool
18. Cutting system
19. Chassis box with electronics, battery and motors
20. Loop wire for boundary wire and guide wire
21. Connectors for the loop wire
22. Stakes
23. Couplers for the loop wire
10
12
17
28
29
27
7
9
10
11
1508 - 010 - 17.01.2022
11
18
19
