H3C LSXM1SFF08B1 Installing And Removing

Manual version: 6PW101-20170601
LSXM1SFF08B1 switching fabric module

1 Card identifier

The card identifier LSXM1SFF08B1 is at the upper right corner of the front panel.

2 Specifications

CAUTION:
This card can be used only with Type F interface cards, which have an F in their card identifiers (for
example, LSXM1CGP12FX1). Card damage will occur if this card is used with an interface card that
is not Type F.
Table 1 Card specifications
Item
Processor
SDRAM
Power consumption
Compatible device models
Compatible interface cards
IMPORTANT:
• To verify compatibility of the card with the software release you are using, see the release notes.
• Only switching fabric modules of the same model can be installed on the same switch.

3 Installing and removing the card

CAUTION:
• Remove the protection box from the card before you install the card.
• You must install the cards before you install the fan tray, and remove the fan tray before you
remove the cards.
• The smart speed adjustment feature increases the fan speed when only one fan tray is operating.
Take noise protection measures such as wearing an earmuff or earplug. In addition, make good
preparation before hot swapping a switching fabric module to minimize the operation time.
• Long-time exposure to strong air flow might cause discomfort. To avoid this hazard, do not stand
close to the air outlet vents while the switch is operating. If you must be next to the switch on the
air outlet vent side for an extended period, avoid the air flow or take other protective measures.
Specification
MIPS64 (Dual Core) @ 1 GHz
4GB DDR3 SDRAM
129 W to 165 W
S12508X-AF
Type F interface cards
i
BOM: 3123A0YC
