H3C LSPM6QP2PS User Manual

H3C LSPM6QP2PS interface card user

Introduction

Overview

The LSPM6QP2PS interface card provides two 20G QSFP+ ports.
Figure 1 LSPM6QP2PS interface card
(1) QSFP+ port LED
(3) Captive screw
NOTE:
The switch models that the interface card is applicable to may change
over time. For the most recent list of applicable switch models, contact
H3C Support or marketing staff.

QSFP+ ports

You can install QSFP+ DAC cables in
interface card.
manual-6PW101
1
(2) QSFP+ port
(4) Ejector lever
Table 1 in the QSFP+ ports on the
