Thank you for purchasing the Olympus AL120 Series Wafer Loader.
In order to fully utilize its performance and secure safety, please read this manual before operation.
Please also keep it at hand during operation as well as for future reference.
This manual is exclusively for maintenance service engineer.
Please also keep it at hand during operation as well as for future reference.
Maintenance Manual
AL120-12
300mm Semiconductor Wafer Loader
Series
Wafer Loader
AL120-LMB12-LP3
AL120-LMB12-F
Wafer Loader Accessory
AL120-VS12
AL120-RC
AM5060-01
