Summary of Contents for Daikin FWE03D
- Page 1 Installation manual Fan coil units FWE03D FWE04D FWE05D FWE06D FWE07D FWE08D FWE10D Installation manual FWE11D English Fan coil units...
- Page 2 2P491002-4E...
- Page 3 2P491002-5G...
- Page 4 2P491002-6G...
-
Page 5: Table Of Contents
General..................Latest revisions of the supplied documentation may be available on 2 About the box the regional Daikin website or via your dealer. Overview: About the box ............The original documentation is written in English. All other languages To unpack and handle the fan coil unit........ -
Page 6: About The Box
Make sure installation, testing and applied materials comply with applicable legislation (on top of the Overview: About the box instructions described in the Daikin documentation). Keep the following in mind: CAUTION ▪ At delivery, the unit MUST be checked for damage. Any damage Wear adequate personal protective equipment (protective MUST be reported immediately to the claims agent of the carrier. -
Page 7: Identification Label: Fan Coil Unit
4 Preparation 3.2.1 Identification label: Fan coil unit Code Description S: Left side water – Left side electric connection Location L: Left side water – Right side electric connection T: Right side water – Right side electric connection R: Right side water – Left side electric connection Preparation Overview: Preparation This chapter describes what you have to do and know before going... - Page 8 4 Preparation Horizontal installation Wall mounted type (bottom suction) The unit must be installed ≥2.5 m from the floor where the unit is hanging in the ceiling. ≥150 (mm) High floor standing type ≥10 ≥150 (mm) Wall mounted type (front suction) (mm) Floor–standing type Vertical filter maintenance space should be considered as indicated.
-
Page 9: Preparing Water Piping
5 Installation Preparing water piping WARNING All field wiring and components MUST be installed by a The unit is equipped with a water inlet and water outlet for licensed electrician and MUST comply with the applicable connection to the water circuit. The water circuit must be provided by legislation. -
Page 10: Horizontal Installation
5 Installation 5.1.1 Horizontal installation 10≤ 1/100 10≤ (mm) 5 Check if the unit is horizontally levelled. 1 Make the required ceiling opening for installation in an Do not install the unit tilted. If the unit is tilted against the applicable place. - Page 11 5 Installation 4 Check if the unit is horizontally levelled. Do NOT install the unit tilted. If the unit is tilted against the direction of the condensate flow (drain piping side raised), it will cause water to drip. Check if the unit is levelled at all 4 corners with a water level (a) or a water-filled plastic tube (b).
- Page 12 5 Installation Screw (field supply) 9 Adjust the unit to the correct position for installing. 1/100 10 Check if the unit is horizontally levelled. Do NOT install the unit tilted. If the unit is tilted against the direction of the condensate flow (drain piping side raised), it will cause water to drip.
-
Page 13: Wall Mounted Type
5 Installation 5.1.3 Wall mounted type Wall mounted (ESFH02D5) NOTICE The filter can be used as bottom or front suction in the wall mounted type. Please follow the instruction in case of wall mounting installation as Model a (mm) b (mm) c (mm) shown below. -
Page 14: Connecting Water Piping
5 Installation Connecting water piping NOTICE Do not use excessive force when connecting the piping. This could deform the unit piping. Deformation of the piping can cause the unit to malfunction. 3 Hang the unit from the hangers and make sure that the hangers are engaged correctly as shown at picture below. -
Page 15: To Fill The Water Circuit
5 Installation NOTICE ▪ Air in the water circuit can cause malfunctioning. During filling, it may not be possible to remove all the air from the circuit. Remaining air will be removed through the automatic air purge valves during the initial operating hours of the system. - Page 16 5 Installation 4 Wrap the thermal insulation (d) in the kit to prevent condensation and heat loss. 2 Connect the 2-way valve body (b) to the water pipe (a). 5 The kit is ready for main pipes connection. The threads (e) connected to the main pipes of the valve body are DN20.
- Page 17 5 Installation 3 way ON/OFF valve kit NOTICE 3-way valve actuator (a), protrude 5 mm above the top plate (b) of the unit (both vertical or horizontal use). The difference should be taken into account when preparing the installation area. 5 mm Model Option kit...
- Page 18 5 Installation 2 Connect the 3-way valve body (b) to the water pipes (a). 4 Wrap the thermal insulation (d) in the kit to prevent condensation and heat loss. 5 The kit is ready for main pipes connection. The threads (e) 3 Connect the actuator (c) to the valve body.
- Page 19 5 Installation 3 Connect the actuator (f) to the valve body. 3 way proportional valve kit Model Proportional valve kit value Actuator Control input power supply 2 pipe 3 pipe FWE03~05D E4V2PN04V3DA E4V4PN04V3DA 24 V AC (+10 0-10 V (2-10) to -15%), =200 kΩ] FWE06~08D E4V2PN06V3DA E4V4PN06V3DA 0.63...
-
Page 20: Connecting The Electrical Wiring
5 Installation 2 Insert the field wiring through the terminal cover rubber (c). Connecting the electrical wiring 5.3.1 About connecting the electrical wiring Typical workflow Connecting the electrical wiring typically consists of the following stages: Making sure the power supply system complies with the electrical specifications of the units. -
Page 21: To Change The Electrical Wiring Direction
5 Installation 5.3.4 To change the electrical wiring direction NOTICE The electrical wiring direction can be changed to the opposite side in the field. NOTICE When attaching the terminal cover, make sure not to pinch any wires. 1 Remove the terminal cover, terminal, cable holder, earth wire and fan motor cables. -
Page 22: Connecting The Drain Piping
5 Installation 4 Fix the cables to the partition plate. Make sure that long reminder cables are fixed tightly with a cable clamp in the new position. Connecting the drain piping 5.4.1 To install the drain piping to the unit Horizontal installation 5 Fix the removed parts to the unit. -
Page 23: Commissioning
This data can be found in the installer reference guide ▪ Between the local supply panel and the indoor unit or via the Daikin website. ▪ Between the indoor unit and the valves (if applicable) NOTICE ▪ Between the indoor unit and the room thermostat ALWAYS operate the unit with thermistors and/or pressure sensors/switches. - Page 24 7 Maintenance and service Vertical installation Push the tabs at the filter and pull it back. 1 Switch off the power supply. 2 The air filter can be installed in 1 of 2 locations on this product (side and bottom). Remove the filter by sliding as shown below. Horizontal installation Remove the filter by sliding.
- Page 25 7 Maintenance and service High floor standing Pull the filter and remove from the unit. 3 Use a vacuum cleaner or wash air filter with water. When the air filter is very dirty, use a soft brush and neutral detergent. 4 Set the air filter back to its original position.
-
Page 26: Disposal
8 Disposal ▪ The full set of latest technical data is available on the Daikin Disposal Business Portal (authentication required). ▪ Units are marked with the following symbol: Information requirements for fan coil units Follow the steps below to consult the Energy Label – Lot 21 data of the unit and outdoor/indoor combinations. - Page 27 9 Technical data (mm) Units: mm (mm) FWE03~05D FWE06D 1109 In case of high floor standing kit (ESFH03D5 ) usage FWE07~11D 1119 1157 1199 1309 Floor standing outlook Vertical outlook High-floor standing type FWE03~11D Installation manual Fan coil units 3P443944-5P – 2021.12...
- Page 28 9 Technical data Horizontal installation (mm) In case of floor standing kit (ESFH01D5 ) usage Additional drain pan Drain socket rubber Drain socket (mm) Unit: mm FWE03~05D FWE06 1109 FWE07~11D 1119 1157 1147 1309 Additional drain pan (ESFD01D6) CAUTION Make sure to attach the drain socket rubber after installing the additional drain pan.
- Page 29 9 Technical data Vertical installation Drain socket rubber Drain socket Additional drain pan FWE03~11D Installation manual Fan coil units 3P443944-5P – 2021.12...
-
Page 30: Wiring Diagram
9 Technical data Wiring diagram On terminal English Translation Connection Main terminal Field supply Protective earth Earth Field wire Fan motor cable White Green Orange Brown Yellow Blue GRN/YLW Green/yellow Capacitor Fuse Terminal strip Fan motor Installation manual FWE03~11D Fan coil units 3P443944-5P –... - Page 32 DAIKIN ISITMA VE SOĞUTMA SİSTEMLERİ SAN.TİC. A.Ş. Gülsuyu Mahallesi, Fevzi Çakmak Caddesi, Burçak Sokak, No:20, 34848 Maltepe İSTANBUL / TÜRKİYE Tel: 0216 453 27 00 Faks: 0216 671 06 00 Çağrı Merkezi: 444 999 0 Web: www.daikin.com.tr 3P443944-5P 2021.12 Verantwortung für Energie und Umwelt...
