Summary of Contents for Lionel Playtime Playground
- Page 1 72-4138-250 7/08 Lionel Playtime Playground Owner’s Manual...
- Page 2 Powering the accessory Controlling the accessory Controlling the accessory in the Command Control environment Limited Warranty/Lionel Service The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel , TrainMaster , Odyssey...
- Page 3 Powering the accessory ou may choose to connect your Playtime Playground to the accessory terminals on your transformer, to an Accessory Power Wire (available separately 6-12053), or a Lionel Lockon (available separately, 6-62900). If connecting to your transformer or a Lionel Lockon, make sure that the two wires included with this accessory are stripped back 1/4”...
- Page 4 Controlling the accessory otate the trash can to turn the accessory on and off. Refer to Figure 2. Within a few moments, the magnets that operate the swings will become properly Note! aligned, drawing the swings back and forth smoothly. Figure 2.
- Page 5 Controlling the accessory in the Command Control environment or operation in the TrainMaster Command Control environment, you may choose to wire this accessory with an SC-2 Switch and Accessory Controller (available separately, 6-22980) or the Accessory Switch Controller (available separately, 6-14182). Refer to these manuals for additional information.
- Page 6 Controlling the accessory in the Command Control environment (continued) SC-2 wiring and operation hree wires are needed to connect the accessory to the SC-2 Switch and Accessory Controller and a separate accessory transformer. Refer to Figure 3. 1. Attach one wire to the transformer Common/Ground/U terminal and connect it to the accessory COMM (common) position on the SC-2.
- Page 7 Controlling the accessory in the Command Control environment (continued) Accessory Switch Controller wiring and operation hree wires are needed to connect the accessory to the Accessory Switch Controller (ASC) and a separate accessory transformer. Refer to Figure 4. 1. Attach one wire to the transformer Power/A terminal and connect it to the COMM terminal on the ASC.
- Page 8 Lionel L.L.C. or an authorized Lionel L.L.C. Service Center, together with proof of original purchase will, at the option of Lionel L.L.C., be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a replacement is not available, a refund of the original purchase price will be granted.
