- Page 1 English Moterra Neo Shimano DU-E7000 Owner’s Manual Supplement READ THIS SUPPLEMENT AND YOUR CANNONDALE BICYCLE OWNER’S MANUAL. Both contain important safety information. Keep both for future reference.
- Page 2 SAFETY MESSAGES: In this supplement, particularly important information is presented in the following ways: Indicates a hazardous situation which, if not avoided, may result in death or serious injury. NOTICE Indicates special precautions that must be taken to avoid damage. SYMBOLS: NGLI-2 synthetic grease Apply NGLI-2 synthetic grease.
-
Page 3: Table Of Contents
Notes ..........28 your bike; obtain and read all of them. Please contact your Authorized Cannondale Dealer immediately if you need a manual or supplement or have a question about your bike. You may also contact us using the appropriate country/region/location information. -
Page 4: Safety Information
Using your bike the wrong way is dangerous. power reduces progressively and cuts off as the bike reaches the maximum allowable Please read your Cannondale Bicycle speed. The drive-assist re-engages when Owner’s Manual for more information about speed drops below the maximum allowable Intended Use and Conditions 1-5. - Page 5 Attachment of a trailer or child seat to this To minimize risk we strongly recommend bicycle can result in a serious accident that owners always have mechanical work leading to serious injury or death. done by an Authorized Cannondale Dealer.
- Page 6 Safety Information Operation Moterra Neo - Shimano DU-E7000 Operation Always wear an approved bicycle helmet and all other protective gear (e.g., gloves, pads, and cycling shoes). Importance of practice & rider training - before you ride this bike, practice riding in a safe area free from hazards.
- Page 7 Safety Information Operation continued from previous page... Wired system control: If the drive system control device is detached from the mount or if the cables are disconnected or damaged, the drive system will automatically shut off. If this happens, you will have to stop the bike, turn the system off, re-attach the computer to the base, and then turn the system back on to resume operation.
- Page 8 Safety Information Batteries & Chargers Moterra Neo - Shimano DU-E7000 Batteries & Chargers REPLACEMENT - Only use the battery pack and charger indicated in the “Specifications” section of this supplement. Do not use other batteries or chargers. Do not use the charger to charge other batteries.
- Page 9 Safety Information Rear Shocks Rear Shocks Minimum Seat Post Insert Select only compatible shocks and forks Make sure at least 100 mm of the seat post for your bike. Do not modify your bike in is inserted into the frame at all times. any way to mount one.
- Page 10 Your retailer MUST follow and observe this specification for your bike. For Maximum Fork Length specifications for Cannondale bicycles, see www.cannondale.com. You can be severely injured, paralyzed or killed in an accident if you ignore this warning.
- Page 11 Safety Information Rear Tire Clearance : Full Suspension Rear Tire Clearance : Full Suspension 10 mm Applies to: • saddles • seat posts • rear racks • Dropper posts • any accessory with possible collision with the moving tire. To check clearance: Release all the air from the rear shock.
-
Page 12: Technical Information
Technical Information Specifications Moterra Neo - Shimano DU-E7000 Technical Information Specifications Item Specification Drive System Shimano DU-E7000 Compatible with Shimano eEP8, E8000, E7000 (and E6100) drive unit and E8036 internal battery Battery Shimano BT-E8035 Drive-Assist Owner's Manuals https://si.shimano.com/ Rear Travel 150mm Head Tube UPR: 1-1/8"... - Page 13 Technical Information Geometry Geometry 75 mm E¹ Dimensions = centimeters Item Size Seat Tube Length Top Tube Horizontal 57.9 60.4 62.9 65.6 Top Tube Actual 53.9 56.2 58.8 61.7 Head Tube Angle Seat Tube Angle Effective E’ Seat Tube Angle Actual Standover 72.7 73.5...
- Page 14 The serial number (8) is located on the bottom To register your bike: bracket. It is a 7-character barcode. See inset. Go to the Product Registration section of our website at www.cannondale.com _____________________________________ Frame Serial Number 138684 Rev 1 (03/22)
- Page 15 Technical Information Tightening Torques Tightening Torques See “Yoke / Shock Eyelet” M10 x 1.0 7.0 N·m 7.0 N·m 15.0 N·m SS-clevis 5.0 N-M CS-clevis shock-yoke bolt shock bolt N·m M5 x 1.5 Hanger N·m N·m ST-pivot-bolts Speed sensor 3.0 N·m See “LOCKR Axle”...
- Page 16 Technical Information Moterra Neo - Shimano DU-E7000 NOTICE Don’t ride with the key in the battery lock. Always remove the key from the lock after using it. Keys may be stolen or break off accidentally in the lock. Keep your spare key in a safe place.
- Page 17 Technical Information Battery Charging Port To connect to the charger cable to the port Battery Charging Port connector: Place the bike and charger in a secure area where both will remain undisturbed while the battery is charging. 2. Lift up the battery port cover. 3.
- Page 18 Technical Information Downtube Battery Moterra Neo - Shimano DU-E7000 Downtube Battery 4. Press in on the top of the battery causing The drive system battery (3) is housed within the bicycle downtube. The battery can be the ramp and lock to engage fully. removed for charging or charged via the battery charge port.
- Page 19 Technical Information Downtube Battery Identification Couvercle de batterie 2. Bouton du couvercle 3. Batterie Connecteur de la batterie sur le cadre 5. Rampe 6. Loquet de retenue 7. Clé 8. Cache-verrou...
- Page 20 If damaged or missing, have them replaced by your Cannondale Dealer. See Replacement Parts. N·m Identification Rear derailleur hanger 2.
- Page 21 Technical Information Rear Shock Rear Shock Identification Rear shock 3. Link 5. Wiper 2. Yoke 4. Seat stay 6. O-ring Set Up 4. Measure the SAG. Adjust the air pressure in the shock to achieve the correct SAG Set the air pressure according to the shock measurement.
- Page 22 Technical Information Yoke / Shock Eyelet Moterra Neo - Shimano DU-E7000 Yoke / Shock Eyelet Loctite 242 (blue) 15 N·m Identification Yoke 3. Bolt (female) 2. Shock 4. Bolt (male) The following is standard maintenance and 3. Clean the smaller (male) yoke bolt and apply should be repeated as often as necessary to a 3 mm wide band of Loctite 242 (blue) at the ensure a quiet bike:...
- Page 23 Technical Information Seatstay / Link / Yoke Seatstay / Link / Yoke 5.0 N·m 7.0 N·m 7.0 N·m 7.0 N·m Identification Seatstay bolt (4X) 3. Link-to-Yoke bolt (2X) 5. Link-to-Frame bolt (2X) 2. Bearing spacers (8X) 4. Spacer (4)
- Page 24 Technical Information LockR Axle Moterra Neo - Shimano DU-E7000 LockR Axle Be sure to support the bike or swingarm to prevent personal injury or bike damage when removing/ disconnecting linkages of an axle. To remove the LockR : Loosen the screw 4-6 turns using a T25 Torx key. 2.
- Page 25 Technical Information LockR Axle DO NOT INSTALL ASSEMBLED N·m N·m Insert 5mm & Unthread Unthread & dislodge & turn to free Remove tap mallet remove Remove...
-
Page 26: Replacement Parts
Replacement Parts Rear Moterra Neo - Shimano DU-E7000 Replacement Parts Rear Part Part Description Description Number Number Derailleur Hanger TA ST Neo FS Shock Mount K33051 K36021 SS 081 Hardware K91051 Neo FS Suspension Link E-Full Suspension Link K36031 CS MP Bearings K91061 Neo FS Yoke E-Full Suspension CS... - Page 27 Replacement Parts Front SHIMANO SHIMANO Front Part Part Description Description Number Number Battery Cover DT Bottom Remote Charging Port K3418010 K76090 Exit BLK Threaded Plate K34190 E8000 Skid Plate Neo FS Shock Mount K36021 Hardware K34200 E7000 Skid Plate Motor Mounting Bolts K34210 E5000 Skid Plate K76100...
-
Page 28: Maintenance
CHECK : Tightening torques for compoents found in this Every few ride or after supplement. Torque values are identified on the “Replacement each hard ride. Parts” page. Please have these procedures perfromed by your Cannondale In wet, muddy, sandy Dealer: conditions every 25 hrs. - Page 29 Record Maintenance Cleaning Your Bike Cleaning Your Bike When cleaning your bike: USE ONLY A MILD SOAP AND WATER SOLUTION. Clean water and a common dish washing liquid will work best. COVER SENSITIVE AREAS WITH A CLEAN PLASTIC BAG. Secured temporarily with a rubber band or masking tape, a bag can prevent water damage to various bike components (bearings, electrical controls, connections and sensors, seals, fork / shock adjustment features).
-
Page 30: Notes
