Tenda IT Series Quick Installation Manual
Hide thumbs Also See for IT Series:

Advertisement

Quick Links

Quick Installation Guide
4MP Bullet Security Camera
IT Series
* Please read this guide before you start with the quick setup for this camera upon the first use.
For product or function details, please go to www.tendacn.com to download the user guide.
IT7-LRS-4 is used for illustrations here unless otherwise specified. The actual product prevails.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IT Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Tenda IT Series

  • Page 1 Quick Installation Guide 4MP Bullet Security Camera IT Series * Please read this guide before you start with the quick setup for this camera upon the first use. For product or function details, please go to www.tendacn.com to download the user guide.
  • Page 2: Package Contents

    Quick Installation Guide 4MP Bullet Security Camera IT Series Please read this guide before you start with the quick setup for this camera upon the first use. For product or function details, please go to www.tendacn.com to download the user guide.
  • Page 3: Install The Device

    Install the device Install the camera Tips − Please make sure the wall or the ceiling is strong enough to withstand three times the weight of the camera. − You may need to prepare a hammer drill, a drill bit, a rubber hammer, a screwdriver, and a ladder for the installation.
  • Page 4 ❸ ❺ Reserve the screws for later use ( step ) ❹ Screws provided with the bracket ❺ - 3 -...
  • Page 5 ❻ Install the camera (Running the cable through the wall is taken as an example) Screw Anchor ❼ Adjust the monitoring direction and fix the camera Vertical adjustment Vertically adjust the screw Horizontal adjustment Horizontally adjust the screw - 4 -...
  • Page 6: Ceiling Installation

    Ceiling installation The bracket installation process may vary based on different manufacturers and models. The following figures are for reference only. Please refer to the actual bracket. ❶ Installation template ❷ - 5 -...
  • Page 7 ❸ Anchor Screw ❹ Fix the camera Knob - 6 -...
  • Page 8 ❺ Adjust the monitoring direction Orientation knob Vertical adjustment Horizontal adjustment - 7 -...
  • Page 9 Install the waterproof kit You can install the waterproof kit and wrap the end with waterproof tape for the Ethernet port and power jack as required. When you connect the Ethernet cable to the Ethernet port of the camera, the waterproof kit installation steps are as follows.
  • Page 10 Manage the device through Network Video Recorder(NVR) The series of cameras needs to be used with the NVR. You should add cameras on the NVR's Web UI. For detailed steps, please refer to the user manual of the corresponding NVR. The series of cameras includes ordinary cameras and PoE cameras.
  • Page 11 PoE camera topology • Working with regular NVR Internet PoE Switch Router POWER Uplink port Monitor PoE Camera PoE Camera PoE Camera • Working with regular NVR Internet Router PoE NVR POWER POWER PoE PORTS AUDIO USB1 USB2 Monitor PoE Camera PoE Camera PoE Camera - 10 -...
  • Page 12: Log In To Web Ui

    Log in to web UI You can log in to the web UI of the camera through a browser. 1. Connect the computer to the switch or router that is connected to the camera. 2. Set the IP address of the computer to an unused one belonging to the same network segment of the IP address of the camera but different from the IP address of the camera.
  • Page 13 3. Start a browser and enter the IP address of the camera in the address bar to access the login page. Enter the User Name (default: admin) and Password (default: admin123456), then click Login. English User Name Password Remember me Login After successfully logging in to the web UI of the camera, you can start to configure the camera as required.
  • Page 14 CE Mark Warning This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
  • Page 15 Copyright © 2021 Shenzhen Tenda Technology Co., Ltd. All rights reserved. Tenda is a registered trademark legally held by Shenzhen Tenda Technology Co., Ltd. Other brand and product names mentioned herein are trademarks or registered trademarks of their respective holders.
