Tenda CP3 Pro Quick Installation Manual

Quick Installation Guide
Security Pan/Tilt Camera
CP3 Pro/RP3 Pro
·
Camera x 1
·
Base x 1
·
Power adapter x 1
·
Installation template x 1
·
Screw x 2 (Length: 25 mm, Head diameter:6.0 mm)
·
Anchor x 2 (Height: 6.6 mm, Inner diameter:2.4 mm, Length:26.4 mm)
·
Quick installation guide
Download the TDSEE onto your mobile device by searching for TDSEE in the App Store
or Google Play or by scanning the QR code.
Or
QR code
Run the TDSEE app and follow the instructions to complete user registration. Enter the
十
home page, tap Add a device or in the upper right corner of the homepage.
Scan the QR code on the bottom of the camera, and follow the instructions in the App.
Appearance
LED
Micro SD card slot
indicator
Reset button
Micro SD Reset
Microphone
One-touch call
Solid red: Initializing.
Blinking red slowly: Disconnected from a 2.4 GHz Wi-Fi network.
Blinking red quickly: Connecting to a 2.4 GHz Wi-Fi network.
LED indicator
Solid blue: Connected to a 2.4 GHz Wi-Fi network.
Blinking blue slowly: Upgrading.
Blinking blue quickly: Waiting to connect to a 2.4 GHz Wi-Fi network.
Hold down the Reset button for about 5 seconds and release it when the LED indicator
Reset button
blinks blue quickly or you hear a prompt tone. The camera is reset successfully.
Micro SD card slot
Turn the lens upward, then you can see it.
One-touch call button.
Used to make a video call to the app remotely.
Install the device
The camera supports desktop, ceiling and wall installations. This guide takes ceiling
installation as an example.
Tips:
(1) Ensure that the ceiling is strong enough to withstand three times the weight of the camera and base.
(2) You may need a hammer drill, a drill bit, a screwdriver, and a ladder for the installation.
Ceiling
Installation
template
Anchor
Base
Screw
After finishing the ceiling mounting, you need to adjust the camera installation status to
facilitate monitoring.
Method: Run the TDSEE app. Choose the camera on the homepage, tap Settings (
the upper right corner) > Video Flip-over, and choose Camera UP-side Down.
Add the camera to TDSEE App
Tips:
Before adding your camera, please ensure that the router is connected the internet successfully and the
filter function is disabled.
Power on the camera.
Speaker
The LED indicator lights solid red after the camera is powered on. When the LED indicator
blinks blue quickly, the camera is waiting to connect to a 2.4 GHz Wi-Fi network.
Power port
PWR
Internet
Router
FAQ
Q1. What should I do if I failed to add the camera?
A1. Try the following solutions:
- Ensure that the router is connected to the internet.
- The camera only supports 2.4 GHz Wi-Fi. When adding the camera, you need to connect the
smartphone to a 2.4 GHz Wi-Fi.
- Do not hide the Wi-Fi network of the router when adding the camera (After adding the camera
successfully, you can hide the Wi-Fi network).
- Confirm whether the LED indicator of the camera blinks blue quickly. If not, reset the camera by referring
to Appearance and configure it again.
Drill bit diameter: 6 mm
Q2. What should I do when the video preview is not smooth?
Hole depth: 28-32 mm
A2. Try the following solutions:
- Check if the Wi-Fi network of the router is smooth.
- Take the router closer to the camera.
- When previewing the video with cellular mobile data, ensure that the internet connection of the
Buckle smartphone is smooth.
- Auto, Fluent, and HD are supported for video preview. Auto is used by default. You can adjust the video
Slot
clarity according to the internet status.
Q3. How to view the videos stored in the Micro SD card of the camera on the computer?
A3. If you remove the Micro SD card installed in the camera and view the videos from your computer, it is
recommended to use VLC media player or Potplayer to play the videos.
in
Power outlet
PWR
Camera
