Genie Nano-CXP Series
Camera User's Manual
CoaXPress™ Monochrome and Color Area Scan
sensors | cameras | frame grabbers | processors | software | vision solutions
April 7, 2022
Rev: 0004
P/N: G3-CX0M-USR00
www.teledynedalsa.com
™

Advertisement

Table of Contents
loading

Related Manuals for Dalsa Genie Nano-CXP

Summary of Contents for Dalsa Genie Nano-CXP

  • Page 1 ™ Genie Nano-CXP Series Camera User’s Manual CoaXPress™ Monochrome and Color Area Scan sensors | cameras | frame grabbers | processors | software | vision solutions April 7, 2022 Rev: 0004 P/N: G3-CX0M-USR00 www.teledynedalsa.com...
  • Page 2 All information provided in this manual is believed to be accurate and reliable. No responsibility is assumed by Teledyne DALSA for its use. Teledyne DALSA reserves the right to make changes to this information without notice. Reproduction of this manual in whole or in part, by any means, is prohibited without prior permission having been obtained from Teledyne DALSA.

  • Page 3: Table Of Contents

    Contents NANO-CXP SERIES OVERVIEW ESCRIPTION Genie Nano-CXP Overview Camera Firmware ODEL UMBERS Monochrome Cameras Color Cameras Accessories ARDWARE AND OFTWARE NVIRONMENTS Mounting Frame Grabbers and Cabling Software Platforms Development Software for Camera Control NANO-CXP SPECIFICATIONS OMMON PECIFICATIONS Sensor Cosmetic Specifications Dynamic Range &...
  • Page 4 Width and Height Features for Partial Scan Control Using the Multiple ROI Mode Important Usage Details Example: Two Horizontal ROI Areas (2x1) Example: Four ROI Areas (2x2) Example: Actual Sample with Six ROI Areas (3x2) Vertical Cropping (Partial Scan) 2 • Contents Genie Nano-CXP Series™...
  • Page 5 External Outputs: Using External LED Indicators Using Nano-CXP Outputs to drive other Nano-CXP Inputs I/O Mating Connector Specifications & Sources ECLARATIONS OF ONFORMITY FCC Statement of Conformance for Class A EU and UKCA Declaration of Conformity Genie Nano-CXP Series™ Contents • 3...
  • Page 6 SSUES Firmware Updates Power Failure during a Firmware Update–Now What? Cabling and Communication Issues Camera is functional, frame rate is as expected, but image is black REVISION HISTORY CONTACT INFORMATION ALES NFORMATION ECHNICAL UPPORT 4 • Contents Genie Nano-CXP Series™...

  • Page 7: Nano-Cxp Series Overview

    Nano-CXP Series Overview Description The Genie Nano-CXP (CoaXPress) series provides affordable easy to use digital cameras specifically engineered for industrial imaging applications by using the industries’ latest leading sensors such as the On-Semi Python series of global shutter active pixel-type CMOS image sensors. Cameras are available in a number of models implementing different sensors, image resolutions and feature sets, either in monochrome or monochrome NIR.

  • Page 8: Camera Firmware

    Teledyne DALSA website at www.teledynedalsa.com. Firmware updates for Genie Nano are available for download from the Teledyne DALSA web site www.teledynedalsa.com/imaging/support/downloads. Choose Genie Nano-CXP Firmware from the available download sections, then choose the zip file download specific to your camera model.

  • Page 9: Model Part Numbers

    Model Part Numbers This manual covers the released Genie Nano-CXP monochrome and color models summarized in the table below. Nano-CXP common specifications and details follow this section. Model numbers identify GPIO support using G3-Xx0x-xxxxx (yes) or G3-Xx3x-xxxxx (no). Monochrome Cameras...

  • Page 10: Accessories

    All Nano XL casing Heatsink 51mm x 28mm x 15mm (screws included) G3-AHSK-51X28 compatible to All Nano XL models and Falcon4-CLHS Cables are available directly from our preferred source: (see Components Express Right-Angle Cable Assemblies). 8 • Nano-CXP Series Overview Genie Nano-CXP Series™...

  • Page 11: Hardware And Software Environments

    Frame Grabbers and Cabling The Teledyne DALSA Xtium-CXP PX8 and Xtium2-CXP PX8 frame grabbers are recommended for error free acquisitions with the Nano-CXP camera (contact sales for additional information). Cable Manufactures Contact Information for contact information for information on CXP cable suppliers and various I/O solutions for your imaging solution.

  • Page 12: Nano-Cxp Specifications

    Camera (L x H x W) XL Case: Mechanical Specifications 38.3 mm x 59 mm x 59 mm Mass XL Case: ~ 163g CoaXPress Connector Type DIN 1.0/2.3 connector (CXP-6 maximum speed rating) 10 • Nano-CXP Specifications Genie Nano-CXP Series™...

  • Page 13: Sensor Cosmetic Specifications

    • Test conditions • Nominal light = illumination at 50% of saturation • Temperature of camera is 45°C • At exposures lower than 0.25 seconds • At nominal sensor gain (1x) Genie Nano-CXP Series™ Nano-CXP Specifications • 11...

  • Page 14: Dynamic Range & Signal To Noise Ratio Test Conditions

    Max saturated values: up to 10 ms (Gain1.0) for the 16M to 25M • For Sony • Max saturated values: Max Pixel format bit depth - 1DN EMI, Shock and Vibration Certifications Refer to Declarations of Conformity section. 12 • Nano-CXP Specifications Genie Nano-CXP Series™...

  • Page 15: Mean Time Between Failure (Mtbf)

    Camera Assembly Temperature (°C) MTBF (hours) MTBF (years) Failure Rate (FIT) 15,401,201 1,758 64.93 9,292,817 1,061 107.61 4,770,992 209.6 2,066,329 483.95 812,486 1230.79 315,604 3168.53 127,279 7856.77 54,362 18395.1 MTBF versus temperature shown graphically Genie Nano-CXP Series™ Nano-CXP Specifications • 13...

  • Page 16: Nano-Cxp Specifications: M5100, C5100, M4090, C4090

    Flat Line Correction (Factory and 4 User Defined entries) Lens Shading correction (Factory and 2 User Defined entry) Noise Reduction Image Flip support Multi-ROI Support Output Dynamic Range (dB) 55.3 SNR (dB) 39.5 14 • Nano-CXP Specifications Genie Nano-CXP Series™...

  • Page 17: Quantum Efficiency Curves

    Quantum Efficiency Curves Genie Nano-CXP Series™ Nano-CXP Specifications • 15...

  • Page 18: Defective Pixel Specification For Models 5100/4090

    For Mono devices: A bad row is defined as a row which has a response that deviates 48 0 defective rows allowed LSB10 in a dark image, or a corrected gray or a saturated image, from the local median of 11 neighboring rows (+/- 5 top/bottom rows). continued next page 16 • Nano-CXP Specifications Genie Nano-CXP Series™...

  • Page 19: Firmware Files For These Models

    F5 (max 0): 5 or more defective pixels in the cluster Firmware Files for These Models The latest firmware files for all Nano models are available on the Teledyne DALSA support web site: http://www.teledynedalsa.com/imaging/support/downloads/firmware/ The firmware files for currently available models are listed below. The xx variable denotes the current build number.

  • Page 20: Nano-Cxp Specifications: M6200, C6200

    Binning Support Decimation Support Defective Pixel Replacement Yes, up to 4096 positions Image Correction Flat Line Correction (Factory and 4 User Defined entries) Lens Shading correction (Factory and 2 User Defined entry) Noise Reduction 18 • Nano-CXP Specifications Genie Nano-CXP Series™...
  • Page 21 Image Flip Support Multi-ROI Support In-Sensor Output Dynamic Range (dB) SNR (dB) 37.8 Genie Nano-CXP Series™ Nano-CXP Specifications • 19...

  • Page 22: Nano-Cxp Specifications: M8200, C8200

    Defective Pixel Replacement Yes, up to 4096 positions Flat Line Correction (Factory and 4 User Defined entries) Image Correction Lens Shading correction (Factory and 2 User Defined entry) Noise Reduction Image Flip Support 20 • Nano-CXP Specifications Genie Nano-CXP Series™...
  • Page 23 Multi-ROI Support In-Sensor Output Dynamic Range (dB) SNR (dB) 37.8 Genie Nano-CXP Series™ Nano-CXP Specifications • 21...

  • Page 24: Quantum Efficiency Curves

    Quantum Efficiency Curves For monochrome Teledyne E2V Emerald 37.7M and 67M sensors. 22 • Nano-CXP Specifications Genie Nano-CXP Series™...

  • Page 25: Firmware Files For M6200, M8200, C6200, C8200 Models

    For color Teledyne E2V Emerald 37.7M and 67M sensors. Firmware Files for M6200, M8200, C6200, C8200 Models The latest firmware files for all Nano models are available on the Teledyne DALSA support web site: http://www.teledynedalsa.com/imaging/support/downloads/firmware/ The firmware files for currently available models are listed below. The xx variable denotes the current build number.

  • Page 26: Nano-Cxp Installation

    Nano-CXP Installation If you are familiar with CoaXPress cameras and Teledyne DALSA frame grabbers, follow these steps to quickly install and acquire images with Genie Nano-CXP and the CamExpert tool provided with Sapera LT in a Windows OS system. Quick Start (using a Teledyne DALSA Frame Grabber) •...

  • Page 27: The Camera Works - Now What

    Nano-CXP. See Components Express Contact Information for a variety of CoaXPress cables. The following figure of the Genie Nano-CXP back shows connector and LED locations along with identification labels. See Mechanical Specifications — Nano-CXP for details on the connectors and camera mounting dimensions.

  • Page 28: Led Indicators

    LED Indicators The Genie Nano-CXP has one multicolor LED to provide a simple visible indication of camera state, as described below. The CoaXPress link connectors do not have any status LED indicators. Camera Status LED Indicator The camera is equipped with one LED to display its operational status. When more than one condition is active, the LED color indicates the condition with the highest priority.

  • Page 29: Preventing Operational Faults Due To Esd

    Problems such as random packet loss, random camera resets, and random loss of Ethernet connections, may all be solved by proper ESD management. Teledyne DALSA has performed ESD testing on Nano cameras using an 8 kilovolt ESD generator without any indication of operational faults. The two following methods, either individually or together will prevent ESD problems.

  • Page 30: Operational Reference

    The Sapera CamExpert tool allows a user to test the camera and frame grabber combination and their functions. Additionally CamExpert saves the Teledyne DALSA frame grabber user settings as individual camera parameter files on the host system (*.ccf). The camera settings are saved within the camera as a user set.

  • Page 31: Camexpert View Parameters Option

    This avoids confusion by eliminating parameter choices when they do not apply to the hardware in use. When using a Teledyne DALSA frame grabber and camera, CamExpert groups all frame grabber parameters first and then follows with the supported camera features. Together the user configures the imaging system.

  • Page 32: Feature Descriptions

    Parameters in gray are read only, either always or due to another parameter being disabled. Parameters in black are user set in CamExpert or programmable via an imaging application. Features listed in the description table but tagged as Invisible are usually for Teledyne DALSA or third-party software usage—not typically needed by end user applications.

  • Page 33: Camera Information Category

    Displays the currently loaded firmware version 1.00 Firmware Version DeviceFirmwareVersion number. Firmware files have a unique number Beginner and have the .cbf file extension. Displays the device’s factory set serial 1.00 Serial Number DeviceSerialNumber number. Expert Genie Nano-CXP Series™ Feature Descriptions • 31...
  • Page 34 Loads the camera configuration set specified 1.00 Load Configuration UserSetLoad by the User Set Selector feature, to the Beginner camera and makes it active. Cannot be updated during a Sapera transfer. (W) 32 • Feature Descriptions Genie Nano-CXP Series™...
  • Page 35 An invalid user set was requested An internal error happened related to the SaveResourceManagerError resource manager DFNC Major Rev deviceDFNCVersionMajor Major revision of Dalsa Feature Naming 1.00 Convention which was used to create the DFNC device’s XML. Invisible Minor revision of Dalsa Feature Naming 1.00...

  • Page 36: Power-Up Configuration Dialog

    (see feature UserSetSelector). To reset the camera to the factory configuration, select Factory Setting and click Load. To save a current camera configuration, select UserSet 1 or 2 and click Save. Select a saved user set and click Load to restore a saved configuration. 34 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 37: Sensor Control Category

    Sensor Control Category The Genie Nano-CXP sensor controls, as shown by CamExpert, groups sensor specific parameters. This group includes controls for frame rate, exposure time, gain, etc. Sensor Control Feature Descriptions Display Name Feature & Values Description Device Version & View...
  • Page 38 User adjusts the Gain feature or Beginner the GainRaw feature. Raw Gain value that is set in camera 1.00 Gain (Raw) GainRaw (model-specific for range and step values). Guru 36 • Feature Descriptions Genie Nano-CXP Series™...
  • Page 39 (over-saturated pixels that revert to DFNC black data) when the strobe lighting extends longer Guru than the exposure period. Black Level Raw BlackLevelRaw Controls the black level as an absolute physical value. 1.00 Invisible Genie Nano-CXP Series™ Feature Descriptions • 37...

  • Page 40: Black Level/Gain Control Details (On-Semi Python Sensors)

    The following sections only apply to camera models using OnSemi sensors (M5100, C5100, M4090, C4090) in Fast Readout mode; camera models with Emerald E2V sensors (M6200, C6200, M8200, C8200) also support Fast Readout mode but without artifacts. 38 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 41: Fast Readout Mode Artifacts Correction

    The feature Exposure Mode selects the controlling method for the exposure. • The start of exposure is initiated by an internal timer signal, an external input trigger signal (Trigger Mode=ON), or a software function call. Genie Nano-CXP Series™ Feature Descriptions • 39...

  • Page 42: Synchronous Exposure Alignment

    Internal Delay (exposureAlignment = Reset or Synchronous With No Overlap) Internal Delay (exposureAlignment = Synchronous With Overlap) << Exposure Active >> Additional triggered exposure mode features and timing specific to OnSemi sensors are described in the I/O Controls Category. 40 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 43: I/O Control Category

    I/O Control Category The Nano-CXP I/O controls, as shown by CamExpert, groups’ features used to configure acquisition actions based on those inputs. Model numbers identify GPIO support: • G3-Xx0x-xxxxx (yes) • G3-Xx3x-xxxxx (no) Genie Nano-CXP Series™ Feature Descriptions • 41...

  • Page 44: I/O Control Feature Descriptions

    The trigger is considered valid on the low level of the line source signal. (OnSemi models only) 1.00 Specifies the delay in microseconds to apply after Trigger Delay TriggerDelay Beginner receiving the trigger and before activating the triggerEvent. 42 • Feature Descriptions Genie Nano-CXP Series™...
  • Page 45 Generate a pulse on the Input signal 2 event Pulse on: Software PulseOnSoftwareCmd Generate a pulse on the input of a Software Command. Command Generate a signal that is active when the Exposure is Exposure Active ExposureActive active. Genie Nano-CXP Series™ Feature Descriptions • 43...
  • Page 46 A signal below 0.8V will be detected as a Logical LOW Threshold for TTL Threshold_for_TTL and a signal greater than 2.4V will be detected as a Logical HIGH on the selected input line. 44 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 47: I/O Module Block Diagram

    Trigger Module Mode Physical Input Trigger Signal Trigger LineStatus Trigger Line Line Source ouput Software Trigger Activation Output Software Driven Pulse inverter generator Event Driven Output Signal Driven Line Output Software Driven Source Genie Nano-CXP Series™ Feature Descriptions • 45...

  • Page 48: Trigger Mode Details

    Trigger Source=Timer1End Event: The Timer1 End Event is used as the internal trigger source. Refer to Counter and Timer Controls for information on those features. • Trigger Source=Counter1End Event: The Counter1 End Event is used as the internal trigger source. 46 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 49: Trigger Overlap: Feature Details

    Minimum Trigger to Exposure start delay: 3.23µs (shown as 4µs) TriggerOverlap=Off Trigger Exclusion Period Trigger Exclusion Period Trigger Input Exposure 1 Exposure 2 Frame Exposure Readout 1 Readout 2 Frame Readout Frame 1 Active period Frame 2 Active period Genie Nano-CXP Series™ Feature Descriptions • 47...
  • Page 50 Exposure 1 Exposure 2 Frame Exposure End of Exposure End of Exposure to Start of Readout to Start of Readout Readout 1 Readout 2 Frame Readout Frame 1 Active period Frame 2 Active period 48 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 51: Output Line Details

    Output signal lines when either in the High or Low state are shown in the following figures with a simplified external circuit. Camera Output LOAD Examples of Logic HI and Logic LO output circuits Genie Nano-CXP Series™ Feature Descriptions • 49...

  • Page 52: Counter And Timer Control Category

    Counter and Timer Control Category The Genie Nano-CXP counter and timer controls, as shown by CamExpert, groups parameters used to configure acquisition counters and timers. 50 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 53: Counter And Timer Control Feature Descriptions

    Starts counting on rising edge of the selected Line. Falling Edge FallingEdge Starts counting on falling edge of the selected Line. Starts counting on the falling or rising edge of the Any Edge AnyEdge selected Line. Genie Nano-CXP Series™ Feature Descriptions • 51...
  • Page 54 Reset counter on rising edge of the selected signal. Falling Edge FallingEdge Reset counter on falling edge of the selected signal. Any Edge AnyEdge Reset counter on the falling or rising edge of the selected signal 52 • Feature Descriptions Genie Nano-CXP Series™...
  • Page 55 Reads the current value (in microseconds) of the Expert selected timer. DFNC 1.00 Resets the timer to 0 while timerStatus=TimerActive. Timer Reset timerReset Expert Timer then waits for the next timerStartSource event. DFNC Genie Nano-CXP Series™ Feature Descriptions • 53...

  • Page 56: Counter And Timer Group Block Diagram

    The counter continues unless a new counterReset Cmd is received, which then restarts the counter at 00. • When Counter Reset Source= ‘Event’ or ‘CounterEnd’ the counter is reset to 00 but does not restart counting, until the next CounterReset Cmd. 54 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 57: Example: Counter Start Source = Counterend (Itself)

    Overflow IDLE Trigger Active Completed Counter is incrementing CounterResetSource = OFF CounterStartSource = EVENT or Signal (Edge Base ) Counter Reset CMD CounterResetSource = Event (Itself) CounterResetSource = Event CounterResetSource = CounterEnd (Itself) Genie Nano-CXP Series™ Feature Descriptions • 55...

  • Page 58: Example: Counterstartsource = Line (Edge Base) Example

    Counter is CounterWait Counter Active Active Active Active IDLE Start Completed Counter Register CounterDuration = 12 CounterStartSource = Line 1 CounterTriggerActivation = Falling Edge any Tick in CounterEventSource The Second StartSource Pulse is ignored 56 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 59: Example: Counting Elapse Time

    • counterValueAtReset: Reads the last counter value before reset. In this example the count value equals time in microseconds since the counter start event. • counterReset: Force a counter value reset when required. Genie Nano-CXP Series™ Feature Descriptions • 57...

  • Page 60: Advanced Processing Control Category

    Advanced Processing Control Category The Genie Nano-CXP Advanced Processing controls, as shown by CamExpert groups parameters used to configure pixel replacement, flat field correction (column based), and lens shading correction controls on monochrome cameras. It is recommended that the user performs a Flat Field Calibration and save the results to the User Set if the camera is normally operated at a high temperature than the 55˚C that the factory...

  • Page 61: Notes About Lens Shading Calibration

    (as little light on the sensor as possible). • Lens Shading Correction Calibration Bright: Perform a bright calibration for lens shading correction. This calibration requires a bright featureless acquisition that is not saturated. (70% illumination is recommended). Genie Nano-CXP Series™ Feature Descriptions • 59...

  • Page 62: Advanced Processing Control Feature Descriptions

    Sets the mode for the pixel noise reduction. Noise Reduction Mode NoiseReduction (monochrome only) 1.00 Expert Noise Reduction is disabled. DFNC Active Active Noise Reduction is enabled. 1.00 processingPathBpp processingPathBpp Processing path bits per pixel Invisible DFNC 60 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 63: Flat Field Correction Group

    DFNC flatfieldCorrectionCalibrationBright operations to the current active set. 1.00 Reset the current calibration coefficients to Reset Calibration flatfieldCorrectionCalibrationResetCoefficients Expert factory defaults. DFNC 1.00 Flat Field Algorithm flatfieldAlgorithmBufferFormat Invisible Buffer Format DFNC Mono8 Mono8 Genie Nano-CXP Series™ Feature Descriptions • 61...

  • Page 64: Lens Shading Correction Group

    Perform a dark calibration for lens shading lensShadingCorrectionCalibrationDark Expert Correction Calibration correction. This is done before the bright DFNC Dark calibration. This calibration requires a dark acquisition (as little light on the sensor as possible). 62 • Feature Descriptions Genie Nano-CXP Series™...
  • Page 65 Invisible Gain Base DFNC 1.00 Lens Shading Algorithm lensShadingCorrectionAlgorithmOffsetMax Invisible Offset Max DFNC 1.00 Lens Shading Algorithm lensShadingCorrectionAlgorithmOffsetMin Invisible Offset Min DFNC 1.00 Lens Shading lensShadingCorrectionAlgorithmOffsetFactor Invisible Correction Algorithm DFNC Offset Factor Genie Nano-CXP Series™ Feature Descriptions • 63...

  • Page 66: Defective Pixel Replacement

    The following XML code sample forms the template for the user to build bad pixel maps for any of their Nano cameras. Note: Identifying bad pixels is left to the user’s discretion, but Teledyne DALSA technical support can provide guidance.

  • Page 67: Monochrome Defective Pixel Replacement Algorithm Description

    Do nothing when the neighboring pixels are also bad. pix0 pix1 pix2 pix3 pix4 pix5 pix6 pix7 Sensor Row “n” pix0 pix1 pix2 pix3 pix4 pix5 pix6 pix7 Sensor Row “n+1” Remains Defective Genie Nano-CXP Series™ Feature Descriptions • 65...

  • Page 68: Color Defective Pixel Replacement Algorithm Description

    Bad pixel in a sensor line with bad adjacent pixels • Do nothing when the neighboring pixels are also bad. pix0 pix1 pix2 pix3 pix4 pix5 pix6 pix7 Sensor Row “n” Remains Defective 66 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 69: Cycling Preset Category

    Cycling Preset Category The Genie Nano-CXP Cycling Preset controls, as shown by CamExpert, has parameters used to configure the camera Cycling features. Cycling controls allow the user to configure a number of camera operational states and then have the camera automatically switch between states in real- time.

  • Page 70: Cycling Preset Mode Control Feature Descriptions

    1.02 cyclingPresetCurrentActiveSet preset. Guru DFNC Cycling Preset ROI Source cyclingPresetRoiPositionSource Specifies the source that cycles the ROI position 1.02 (availability is sensor dependent). Expert DFNC In-Sensor Sensor The sensor cycles the ROI position. 68 • Feature Descriptions Genie Nano-CXP Series™...
  • Page 71 Vertical offset from the origin to the region of interest 1.03 Vertical Offset cP_OffsetY (ROI). The value in this feature is only used when the Expert currently selected cycling preset is active. DFNC Genie Nano-CXP Series™ Feature Descriptions • 69...
  • Page 72 OutputLineSource must be SoftwareControlled. If the DFNC outputLineSoftwareLatchControl=Latch, the state of the pin will change with the outputLineSoftwareCmd command. Active Active Sets the Output circuit to closed. Inactive Inactive Sets the Output circuit to open. 70 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 73: Using Cycling Presets-A Simple Example

    • Set the feature ExposureTime to a higher value, increasing the acquisition brightness. • Repeat for index 3 with an exposure a bit longer again, and index 4 with an even longer exposure. Genie Nano-CXP Series™ Feature Descriptions • 71...

  • Page 74: Cycling Reset Timing Details

    Frame Acquisition 1 Frame Acquisition 3 Frame Acquisition 4 Frame Acquisition 2 Preset 1 (cycling status) Preset 2 Preset 3 Preset 1 cyclingPresetCurrentActiveSet Acquisition Asynchronous Cycling Reset Command Reset Applied cyclingPresetResetSource 72 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 75: Case 2: Cycling With External Asynchronous Increment

    Format group of features. Obviously, the defined initial ROI area would be smaller so as to allow it to be moved around via the Cycling Mode OffsetX and OffsetY features set for each Cycling Preset. Genie Nano-CXP Series™ Feature Descriptions • 73...

  • Page 76: Image Format Control Category

    Image Format Control Category The Nano-CXP Image Format controls, as shown by CamExpert, groups parameters used to configure camera pixel format, image cropping, etc. 74 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 77: Image Format Control Feature Descriptions

    DFNC ROI Count multipleROICount Specifies the number of possible ROI (Region of Interest) 1.03 available in an acquired image. One is minimum, while the Expert maximum is device specific. < RO > DFNC Genie Nano-CXP Series™ Feature Descriptions • 75...

  • Page 78: Width And Height Features For Partial Scan Control

    Important: Any reduction of the camera’s acquisition area from its maximum must be matched by the same reduction in the frame grabber’s buffer dimensions. The Teledyne DALSA CXP frame grabber will generate “Buffer Incomplete” errors when the buffer dimensions do not match the Nano-CXP cropped acquisition.

  • Page 79: Using The Multiple Roi Mode

    Using the Multiple ROI Mode Genie Nano-CXP color and monochrome 6200 and 8200 cameras implement the Multiple ROI mode (region of interest) features, which allow having 2 to 32 smaller image ROI areas versus the single ROI area possible with vertical and horizontal crop functions.

  • Page 80: Example: Four Roi Areas (2X2)

    The camera output image frame consists only of the ROI areas, in the same order as the ROI rows and columns. The user must account for the change between ROI data for each output image row. • The output image being smaller, reduces the bandwidth requirements. 78 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 81: Example: Actual Sample With Six Roi Areas (3X2)

    With the ROI areas defined, the camera outputs an image consisting only of data within those ROI areas, as shown below. Such data reduction improves transfer bandwidth and also reduces image processing time for the host system imaging application. Genie Nano-CXP Series™ Feature Descriptions • 79...

  • Page 82: Vertical Cropping (Partial Scan)

    Fast Readout Mode (inc = 16) (fps) (fps) 5120 46.89 80.15 3840 62.45 106.6 2560 93.45 159.3 1280 185.5 315.2 365.8 616.5 711.7 1182 1349 2178 2444 3773 3623 5347 4761 6711 6993 9090 80 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 83: Maximum Frame Rate Examples (Nano-Cxp M/C 4090)

    Fast Readout Mode (inc = 16) (fps) (fps) 8196 6144 5120 32.1 4096 40.1 3072 53.4 79.9 2048 119.6 1024 159.4 238.1 316.4 471.2 622.9 923.2 1208.2 1774.2 2278.5 3290.8 4089.8 5746.9 6787.9 9168.2 Genie Nano-CXP Series™ Feature Descriptions • 81...

  • Page 84: Horizontal Cropping (Partial Scan)

    There are two Horizontal Control features. These features, horizontal offset (OffsetX) and width (Width) have three associated factors — their minimum value, maximum value and the increment (step size) value. Horizontal Crop Horizontal Offset Width 82 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 85: Internal Test Pattern Generator

    Grey Diagonal Ramp Moving: combination of the 2 previous schemes, but first pixel in image is incremented by 1 between successive frames. This is a good pattern to indicate motion when doing a continuous grab. Genie Nano-CXP Series™ Feature Descriptions • 83...

  • Page 86: Metadata Controls Category

    Metadata Controls Category The Genie Nano-CXP Metadata Controls category has features to enable and select inclusion of chunk data with the image payload. Along with each image, the camera can optionally output metadata associated to that image. Metadata is appended to the image data.
  • Page 87 Note that when metadata is enabled using the ChunkModeActive feature, all available metadata is enabled; individual metadata cannot be enabled/disabled. <RO> False Selected metadata Disabled. True Selected metadata Enabled. Genie Nano-CXP Series™ Feature Descriptions • 85...

  • Page 88: Extracting Metadata Stored In A Sapera Buffer

    Size in Pixels 56 58 60 64 66 68 144 148 152 Pixel Number The Chunk ID, Chunk Size and Chunk Availability fields are always present in the metadata, all the other fields are optional. 86 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 89: Metadata Availability

    Offset Y Image Size Timestamp 1000 Frame ID 2000 Binning 4000 Exposure Delay 8000 Counter Value at Reset 10000 Test Image Selector 10000000 Serial Number 20000000 Device User ID 40000000 Pixel Format 80000000 Genie Nano-CXP Series™ Feature Descriptions • 87...

  • Page 90: Metadata Structure

    5: Purity 6: GreyDiagonalRamp 8: ColorBar 9: GreyDiagonalRampMoving 0x80: UserDefined unsigned char [16] Serial Number ASCII codes for device serial number. unsigned char [16] Device User ID ASCII codes for Device User ID. 88 • Feature Descriptions Genie Nano-CXP Series™...
  • Page 91 } Metadata; #pragma pack(pop) Genie Nano-CXP Series™ Feature Descriptions • 89...

  • Page 92: Acquisition Control Category

    Acquisition Control Category The Acquisition and Transfer controls as shown by CamExpert, has parameters used to configure the optional acquisition modes of the device. 90 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 93: Acquisition Control Feature Descriptions

    Streaming End activating them. 1.00 Performs an explicit register set validation for Register Check DeviceRegistersCheck Invisible consistency. 1.00 Registers Valid DeviceRegistersValid States if the current register set is valid and Invisible consistent. Genie Nano-CXP Series™ Feature Descriptions • 91...

  • Page 94: Acquisition Buffering

    IMAGE FORMAT CONTROL PixelFormat OffsetX (except within the Cycling Mode) OffsetY (except within the Cycling Mode) Binning (except within the Cycling Mode) Width, Height Multi-ROI functions, TestImageSelector DeviceRegistersStreamingStart ACQUISITION CONTROL DeviceRegistersStreamingEnd FILE ACCESS CORNTOL 92 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 95: Event Control Category

    Specifies the activation mode to latch the timestamp timestampLineActivation Expert Activation counter on the selected line of the TimestampSource DFNC feature. Latch the timestamp counter on the falling edge of the Falling Edge FallingEdge source signal. Genie Nano-CXP Series™ Feature Descriptions • 93...
  • Page 96 Reset the timestamp counter on the rising edge of the Rising Edge RisingEdge source signal. Reset the timestamp counter on the falling or rising edge Any Edge AnyEdge of the source signal. 94 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 97: Coaxpress Transport Layer Category

    CoaXPress Transport Layer Category The Nano-CoaXPress Transport Layer category, as shown by CamExpert, groups parameters used to manage the CXP data interface. Genie Nano-CXP Series™ Feature Descriptions • 95...

  • Page 98: Coaxpress Transport Layer Feature Descriptions

    Host Link ID of the Host link connected to the Device 1.00 Master Host Link ID CxpMasterHostLinkID Master connection. Invisible Control Packet Size CxpControlPacketDataSize Feature to read the control packet data size in bytes. 1.00 Invisible 96 • Feature Descriptions Genie Nano-CXP Series™...
  • Page 99 Read test error counter. 1.00 Invisible 1.00 Pixel Size cxpPixelSize Total size in bits of an image pixel. Invisible 8 Bits/Pixel Bpp8 Bpp8: 8 bits per pixel 10 Bits/Pixel Bpp10 Bpp10: 8 bits per pixel Genie Nano-CXP Series™ Feature Descriptions • 97...

  • Page 100: File Access Control Category

    Off and sensor Gain is 1.26. Select factory Flat Line coefficients 3. These are Factory Flat Line coefficients 3 FlatFieldCoefficients03 the factory values used when the camera fastReadoutMode is Off and sensor Gain is 1.87. 98 • Feature Descriptions Genie Nano-CXP Series™...
  • Page 101 Guru Controls the mapping length between the device 1.00 File Access Length FileAccessLength file storage and the file access buffer. Guru File Operation Status FileOperationStatus Displays the file operation execution status. 1.00 Genie Nano-CXP Series™ Feature Descriptions • 99...
  • Page 102 Invisible Save Last Image to Flash saveLastImageToFlash Command that saves the last acquired image to 1.00 camera flash memory. Use the file transfer DFNC feature to read the image from camera. Invisible 100 • Feature Descriptions Genie Nano-CXP Series™...

  • Page 103: Updating Firmware Via File Access In Camexpert

    Genie Nano. This memory is available to store any data required, such as licensing codes, system configuration codes, etc. as per the needs of the system supplier. No Nano firmware operation will overwrite this memory block thus allowing and simplifying product tracking and control. Genie Nano-CXP Series™ Feature Descriptions • 101...

  • Page 104: Implementing Trigger-To-Image Reliability

    In a complex imaging system a lot can go wrong at all points – from initial acquisition, to camera processing, to data transmission. Teledyne DALSA provides features, events, and I/O signals that provide the system designer with the tools to qualify the system in real time.

  • Page 105: Nano Features For T2Ir Monitoring

    Device Temperature Selector DeviceTemperatureSelector Device Version DeviceVersion Firmware Version DeviceFirmwareVersion Last firmware update failed FirmwareUpdateFailure Manufacturer Part Number deviceManufacturerPartNumber Manufacturer Info DeviceManufacturerInfo Acquisition and Triggers Valid Frame Trigger ValidFrameTrigger Invalid Frame Trigger InvalidFrameTrigger Genie Nano-CXP Series™ Implementing Trigger-to-Image Reliability • 103...

  • Page 106: Technical Specifications

    Technical Specifications Both 2D and 3D design drawings are available for download from the Teledyne DALSA web site http://www.teledynedalsa.com/genie-nano Notes on Genie Nano Identification and Mechanical Identification Label Genie Nano cameras have an identification label applied to the bottom side, with the following information: •...

  • Page 107: Mechanical Specifications With M42 Mount

    Mechanical Specifications with M42 Mount: Note: Genie Nano-CXP with M42 Mount Genie Nano-CXP Series™ Technical Specifications • 105...

  • Page 108: Sensor Alignment Specification

    Theta specifies the sensor rotation relative to the sensor’s center and Nano mechanical. X variance +/- 250 microns Y variance +/- 250 microns Z variance +/- 300 microns Theta variance +/- 1 degree 106 • Technical Specifications Genie Nano-CXP Series™...

  • Page 109: Connectors

    Model numbers identify GPIO support: • G3-Xx0x-xxxxx (yes) • G3-Xx3x-xxxxx (no) Teledyne DALSA makes available optional I/O cables as described in Ruggedized Cable Accessories. Contact Sales for availability and pricing. Pin Number Genie Nano-CXP...

  • Page 110: Camera Dc Power Characteristics

    Input Voltage +12 Volts minimum Input Power Consumption @ +24 Volt Supply 12 Watts typical Absolute Maximum DC Power Supply Range before Possible Device Failure Input Voltage Range +26 Volt to –26 Volt DC 108 • Technical Specifications Genie Nano-CXP Series™...

  • Page 111: I/O Signals Electrical Specifications

    Input Current 7 mA 11.8 mA Input logic Low 0.8 V Input logic High 2.5 V Absolute Maximum Range before Possible Device Failure Absolute Ratings Minimum Maximum Input Voltage –26 Volts +26 Volts Genie Nano-CXP Series™ Technical Specifications • 109...

  • Page 112: External Input Ac Timing Characteristics

    LVTTL / TTL Interface User IO Push-Pull Power Buffer ( Input 2 ) Imax = 10mA External Signal 2 ( Input 1 ) Imax = 10mA External Signal 1 (Common Ground) User IO Ground 110 • Technical Specifications Genie Nano-CXP Series™...

  • Page 113: External Inputs: Using Common Collector Npn Drivers

    User IO Power (3V-28V) Only one Input can be used ( Input 2 ) in this configuration. ( Input 1 ) ( Common Ground ) Imax = External Signal 10mA User IO Ground Genie Nano-CXP Series™ Technical Specifications • 111...

  • Page 114: External Inputs: Using A Balanced Driver

    No output signal glitch on power-up or polarity reversal • Typical Operating Common Power Voltage Range: +3V to 24Vdc at 24mA • Maximum Common Power Voltage Range : ±28Vdc • Maximum Output Current: 36mA 112 • Technical Specifications Genie Nano-CXP Series™...

  • Page 115: External Output Ac Timing Characteristics

    16 mA 0.514 3.03 15.13 13.86 9.61 24 mA 0.531 3.76 9.91 8.72 8 mA 2907 0.541 1.63 50.75 34.39 23.31 16 mA 1346 0.556 21.74 18.32 21.58 24 mA 0.567 14.61 12.93 20.72 Genie Nano-CXP Series™ Technical Specifications • 113...
  • Page 116 1.759 0.369 11.41 24 mA 0.952 0.2739 1.481 0.224 11.33 8 mA 2930 0.81 0.2079 3.542 1.639 23.57 16 mA 1464 0.803 0.2244 2.908 0.981 23.47 24 mA 0.82 0.2222 2.331 0.616 23.39 114 • Technical Specifications Genie Nano-CXP Series™...

  • Page 117: External Outputs: Using External Ttl/Lvttl Drivers

    Camera IO User IO Interface Power ( Output 2 ) ( Output 1 ) ( User IO Power ) Set resistor (R) value to not exceed output current of = 30mA. User IO Ground Genie Nano-CXP Series™ Technical Specifications • 115...
  • Page 118 Set resistor (R) value to not ( Output 2 ) exceed output current of = 30mA. ( Output 1 ) Only one Output (1 or 2) can be used in this configuration. User IO Ground 116 • Technical Specifications Genie Nano-CXP Series™...

  • Page 119: Using Nano-Cxp Outputs To Drive Other Nano-Cxp Inputs

    Camera (Slave 5) Camera (Slave 6) Camera IO Camera IO Camera IO Interface Interface Interface (GPI_P1) (GPI_P1) (GPI_P1) (GPI_P0) (GPI_P0) (GPI_P0) (GPI_CMD_GND) (GPI_CMD_GND) (GPI_CMD_GND) User IO User IO User IO Ground Ground Ground Genie Nano-CXP Series™ Technical Specifications • 117...

  • Page 120: I/O Mating Connector Specifications & Sources

    Asia-Pacific (specific country can be selected) crimp-10way/dp/2308547?ost=ISDF-05-D-M Important: Samtec ISDF-05-D-S is not compatible with Genie Nano Samtec ISDF-05-D-M mating connector for customer built cables w/retention clips “.050” Tiger Eye™ Discrete Wire Socket Housing” 118 • Technical Specifications Genie Nano-CXP Series™...
  • Page 121 Samtec connector-cable assembly SFSD-05-28-H-03.00-SR w/retention clips “.050” Tiger Eye™ Double Row Discrete Wire Cable Assembly, Socket” Genie Nano-CXP Series™ Technical Specifications • 119...

  • Page 122: Declarations Of Conformity

    This equipment is intended to be a component of a larger industrial system. EU and UKCA Declaration of Conformity Teledyne DALSA declares that this product complies with applicable standards and regulations. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

  • Page 123: Additional Reference Information

    These Nano-CXP models have a M42 screw mount where M42 lens or F-mount lens (via an adapter) need to have image circles exceeding the diameter of either of these larger sensors. The following figure shows the lens image circles relative to Genie Nano-CXP models using the OnSemi Python 25K and Python 16K sensors.

  • Page 124: Additional Lens Parameters (Application-Specific)

    The following figure shows the lens image circles relative to Genie Nano-CXP models using the Teledyne E2V Emerald 37.7M (Four Thirds image sensor format) and 67.1M (APS-C image sensor format) sensors. Model 8200 28.96mm minimum Model 6200 Image Circle 21.72mm minimum...

  • Page 125: Optical Considerations

    Factors include the nature, speed, and spectral characteristics of objects being imaged, exposure times, light source characteristics, environmental and acquisition system specifics, and more. The Teledyne DALSA Web site provides an introduction to this potentially complicated issue. Click on Knowledge Center and then select Application Notes and Technology Primers. Review the sections of interest.

  • Page 126: Ir Cut-Off Filters For Color Cameras

    Nano Models with Built-in IR Cut-off Filters Choose Nano color cameras with built-in IR Cut-off Filters for a simple generalized solution. The following graphic shows these models having an IR filter with a specified cut-off of about 646nm. 124 • Additional Reference Information Genie Nano-CXP Series™...

  • Page 127: Guidelines For Choosing Ir Cut-Off Filters

    CMOS sensor cameras. When selecting an IR cut-off filter, choose a near infrared blocking specification of ~650nm. Filters that block at 700nm or longer wavelengths, designed for CCD cameras, are not recommended for Genie Nano color cameras. Genie Nano-CXP Series™ Additional Reference Information • 125...

  • Page 128: Back Focal Variance When Using Any Filter

    1/3mm C-mount shim (spacer) added to move the lens focal point back to the sensor surface. Such shims are available from filter and lens suppliers. Alternatively, use a variable focus lens and secure its focus ring after adjustment. 126 • Additional Reference Information Genie Nano-CXP Series™...

  • Page 129: Lens Modeling

    45mm, and requires that 100m in the object space correspond to each pixel in the image sensor. Using the preceding equation, the object distance must be 450mm (0.450m).  OD = 450mm  Genie Nano-CXP Series™ Additional Reference Information • 127...

  • Page 130: Sensor Handling Instructions

    When exposed to uniform illumination, a sensor with a scratched window will normally have brighter pixels adjacent to darker pixels. The location of these pixels changes with the angle of illumination. 128 • Additional Reference Information Genie Nano-CXP Series™...

  • Page 131: Cleaning The Sensor Window

    Wipe the window carefully and slowly when using these products. Ruggedized I/O Cable Accessories Teledyne DALSA provides optional I/O cable assemblies for Genie Nano. Users wishing to build their I/O cabling by starting from available cable packages should consider these popular assemblies described below.

  • Page 132: Cable Assembly G3-Aioc-Blunt1M

    Cable Assembly G3-AIOC-BLUNT1M 130 • Additional Reference Information Genie Nano-CXP Series™...

  • Page 133: Cable Assembly G3-Aioc-Blunt2M

    Cable Assembly G3-AIOC-BLUNT2M Genie Nano-CXP Series™ Additional Reference Information • 131...
  • Page 134 132 • Additional Reference Information Genie Nano-CXP Series™...

  • Page 135: Cable Assembly G3-Aioc-Brkout2M

    Cable Assembly G3-AIOC-BRKOUT2M Genie Nano-CXP Series™ Additional Reference Information • 133...
  • Page 136 134 • Additional Reference Information Genie Nano-CXP Series™...

  • Page 137: Nano Generic Power Supply With No I/O

    Nano Generic Power Supply with no I/O Genie Nano-CXP Series™ Additional Reference Information • 135...

  • Page 138: Components Express Right-Angle Cable Assemblies

    These cable assemblies can be acquired directly from our partner Components Express. In such cases use the manufacturer’s part number shown on the cable assembly engineering drawing. Cable Assembly: Right-Angle I/O Bunt End 136 • Additional Reference Information Genie Nano-CXP Series™...

  • Page 139: Cable Assembly: Right-Angle I/O To Euro Block

    Cable Assembly: Right-Angle I/O to Euro Block Genie Nano-CXP Series™ Additional Reference Information • 137...

  • Page 140: Troubleshooting

    • From the Start menu, go to Programs • Dalsa • Sapera LT • Tools and run the Log Viewer program. From its File menu click on Save Messages to generate a log text file.

  • Page 141: Power Failure During A Firmware Update-Now What

    • Use the Log Viewer tool (see point below) for error conditions. • Run the Sapera Log Viewer: Start•Programs•Teledyne DALSA•Sapera LT•Tools•Log Viewer. Start the Nano-CXP acquisition program, such as CamExpert. Review the log output for error messages. Camera is functional, frame rate is as expected, but image is black •...

  • Page 142: Revision History

    October 4, 2019 Initial release R: 0002 February 14, 2020 Various updates R: 0002 March 3, 2020 Additional updates R: 0003 September 10, 2020 Minor error corrections R: 0004 April 7, 2022 Added new models 140 • Revision History Genie Nano-CXP Series™...

  • Page 143: Contact Information

    Sales Information Visit our web site: www.teledynedalsa.com/mv Email: mailto:info@teledynedalsa.com Canadian Sales Teledyne DALSA — Head office Teledyne DALSA — Montreal office 605 McMurray Road 880 Rue McCaffrey Waterloo, Ontario, Canada, N2V 2E9 Saint-Laurent, Quebec, Canada, H4T 2C7 Tel: 519 886 6000...

Table of Contents
