Fairfield 4ft6 Bed Frame Pine
Assembly Instructions -
Dimensions
Width -
149,6
cm
Length -
206,4
cm
Height -
120
cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800
Please keep for future reference
852/5800
Issue
2 21/06/2018
-
Advertisement
Related Manuals for Argos Fairfield 852/5800
Summary of Contents for Argos Fairfield 852/5800
- Page 1 Fairfield 4ft6 Bed Frame Pine Assembly Instructions - 852/5800 Please keep for future reference Dimensions Width - 149,6 Length - 206,4 Height - Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800 Issue 2 21/06/2018...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • This product contain natural •We do not components and tools listed on timber. You may notice some recommend the pages 2 and 3.
- Page 3 Components - Panels Please check you have all the panels listed below 01 Headboard (149,6x120cm) 02 Footboard (149,6x55cm) 03 Side Rail x2 (188x14cm) 04 Central Rail (197x6,5cm) 05 Slats x26 (68,2x6,5cm) 06 Middle Support x2 (30x6,5cm)
- Page 4 Components - Fittings If you have damage or missing components, call the Customer Helpline: 03456 400 800. Please check you have all the fittings listed below. Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Fixing metal brackets Fix metal brackets J into pre drilled holes in the headboard 01 and footboard 02 using screws E. Screw headless bolt L to footboard 02. Step 2 Fitting dowels Insert dowels D into the side rails 03.
- Page 6 Assembly Instructions Step 3 Assembling side rails Attach side rails 03 to the headboard 01. Insert half moon nut B into the side rails as shown. Then fix them to the headboard using bolts A and allen key C. Caution: Assembling of Step 3 and Step 4 will be easier with 2 people.
- Page 7 Assembly Instructions Step 5 Fixing middle support Fix middle support 06 to central rail 04 using bolt G and allen key C as shown. Step 6 Fixing central rail Fix central rail 04 to L shaped brackets in headboard using bolts H and nut I as shown.
- Page 8 Assembly Instructions Step 7 Fixing slats Please fix the first slat 05 at the end of the rail and work towards the middle of the bed using the spacer Q as shown to ensure correct spacing. Fix all the slats to the side rails first using screws F.
