Summary of Contents for Nexans iGigaSwitch 1604 E + SFP-4VI HW5

  • Page 2: Foreword

    For more information on the exact feature set and specifications, see the product’s web page and datasheet. Support If you are not yet a registered user of the Nexans Support Portal, please register at the Nexans support portal http://www.nexans-ans.de/support/ and download the latest version of the firmware and the management tool. Here you will also find the related V5 release notes and the current versions of V5 management manual.
  • Page 3: Ec Declaration Of Conformity

    EN 50581:2012: Technical documentation for the assessment of electrical and electronic products with respect to the restriction of hazardous substances The quality and environmental management system of Nexans Advanced Networking Solutions GmbH according to DIN EN ISO 9001:2000 and DIN EN ISO 14001:2005 ensures compliance with the European Directives and the fulfilment of the relevant standards of the European standards bodies CEN, CENELEC and ETSI.
  • Page 4: Industrial Ethernet Switches

    LAN infrastructures in harsh environments of mission critical applications. Nexans industrial Ethernet switches are targeted to provide highest network availability, security and to make network maintenance much easier. They have a high level of interoperability with other switches manufacturers and different SCADAs.
  • Page 5: Table Of Contents

    Contact Nexans LAN Systems Table of Contents Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com TABLE OF CONTENTS Foreword ................................... 1 EC Declaration of Conformity ............................3 Industrial Ethernet Switches .............................. 4 Table of Contents ................................5 Application/Description ..............................6 Overview of features ................................. 8 Dimensions ..................................
  • Page 6: Application/Description

    12x ports (88301602, 88301604 or 88301606 respectively). IEC 61850 Nexans iGigaSwitch family comply to IEC 61850 requirements (parts 6, 7-1, 7-2, 7-3, 7-4, 8-1, 9-1 and 9-2 Communication networks and systems for power utility automation). This functionality is critical for Smart grid and allows to use standardized equipment to ensure correct and reliable communication of all networked devices of Smart grid infrastructure (including switches, PLCs, different controllers, sensors etc.) with each other and with central...
  • Page 7 • Nexans switches have an extensive diagnostic functionality to provide a wide range of information about their condition, temperature, power level, ports usage, PoE and many others. Alerts can be defined for many parameters to automate IT maintenance processes.
  • Page 8: Overview Of Features

    Contact Nexans LAN Systems Overview of features Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com OVERVIEW OF FEATURES General iGigaSwitch 1604 E+ SFP-4VI HW5 iGigaSwitch 1606 HSR SFP-6VI HW5 Dimensions [WxHxD] 95 x 184 x 125 mm 35mm DIN-Rail Mounting acc. to EN 60715, (EN 50022); Different mounting positions of DIN-rail clip –...
  • Page 9 Contact Nexans LAN Systems Overview of features Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com General iGigaSwitch 1608 E+ SFP-8V HW5 iGigaSwitch 1612 E+ SFP-12VI HW5 Dimensions [WxHxD] 95 x 184 x 125 mm 35mm DIN-Rail Mounting acc. to EN 60715, (EN 50022); Different mounting positions of DIN-rail clip –...
  • Page 10 Contact Nexans LAN Systems Overview of features Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com Diagnostic functions (interfaces) iGigaSwitch 16XX HW5 Series Digital diagnostic monitoring interface Twisted pair cable diagnostic Pending Functional parameters OS type Real time operation system Data throughput >...
  • Page 11: Dimensions

    Contact Nexans LAN Systems Dimensions Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com DIMENSIONS 95mm 125mm 139mm Page 11/49 Generated 2021-11-04...
  • Page 12: Din-Rail Installation - Types Of Mounting

    Contact Nexans LAN Systems DIN-rail installation - Types of mounting Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com DIN-RAIL INSTALLATION - TYPES OF MOUNTING The DIN rail adapter of 16 ports Industrial Ethernet switch is designed for the installation of a switch on DIN-35mm standard rail.
  • Page 13: Describing Switch Functions

    Contact Nexans LAN Systems Describing Switch functions Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com DESCRIBING SWITCH FUNCTIONS iGigaSwitch 16XX HW5 Series DIN rail mounting clip back Power input for PoE+ 2 redundant power inputs (3- (3-pin connector) pin connector) Up to 12 RJ45 ports...
  • Page 14: Product Labels

    PRODUCT LABELS The active Nexans devices are equipped with product labels for the purposes of quality assurance and documentation. The product labels contain unique device-specific information that can be used for your project documentation. This information includes MAC address and serial number. The two identity features are unique and can be assigned to each individual device.
  • Page 15: Safety Instructions And Disclaimer

    Suggestions for improvement are welcomed. Technical changes are reserved, even without notice. Further information can be found at www.nexans.de/LANsystems Nexans Advanced Networking Solutions Bonnenbroicher Str. 2-14 41238 Moenchengladbach Germany...
  • Page 16: Preparation For Operation

    Contact Nexans LAN Systems Preparation for operation Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com PREPARATION FOR OPERATION Opening of the unit Please disconnect the unit from the mains supply and from all other power sources prior to opening the unit. Any subsequent servicing and repair on the open and live unit may only be performed by a qualified person.
  • Page 17: Pin Assignment

    Contact Nexans LAN Systems Pin assignment Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com PIN ASSIGNMENT Wiring to the 3-pin connector and pin assignment of the switch Grounding In any case please check the correct pin assignment and the correct polarity of the wiring at the supply unit.
  • Page 18: Grounding

    Contact Nexans LAN Systems Grounding Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com GROUNDING Guidelines for earthing systems in connection with central power supply concepts and usage of FTTO switches for PoE applications Page 18/49 Generated 2021-11-04...
  • Page 19: Power Over Ethernet (Optional)

    In any case please check the correct pin assignment and the correct polarity of the PoE wiring at the terminal unit. The Nexans GigaSwitch Series is offering PoE (PSE) functionalities. The systems are therefore able to supply devices according to IEEE802.3at - Endpoint PSE mode "Mode A". For external power supply (PSE) of devices an operation voltage of more than 46 VDC for IEEE802.3af and 50V DC for IEEE802.3at is needed.
  • Page 20 The standard defines 3 operating modes for the supply, which is carried out via different wire pairs of the twisted pair data connection. Nexans FTTO Switches Support Endpoint PSE Mode A - Voltage supply as "phantom power" across pairs 1/2 and 3/6. A PoE solution only supplies voltage when a corresponding terminal (PD) is detected.
  • Page 21: Power Supplies

    Power Supplies Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com POWER SUPPLIES Nexans article number: 88645963 Description: iPowerSupply S 110-230VAC/24VDC 100W Dimensions (mm): 90x90x61 Ambient temperature range (operating): -25°C to + 70°C (Derating from + 55°C) Input voltage: 110-240V AC / 50Hz / 60Hz / 1,3A (95-250V DC) Output voltage: 23 - 30V DC, 24V DC / 4.2 A (acc.
  • Page 22 Nexans LAN Systems Power Supplies Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com Nexans article number: 88646250 Description: iPowerSupply S 115-230VAC/48V DC 240W Dimensions (mm): 60x130x152.5 Ambient temperature range (operating): -25°C to + 70°C (Derating from + 55°C) Input voltage: 110-240V AC / 50Hz / 60Hz / 4.6A (95-250V DC) Output voltage: 30 - 56V DC, 48V DC / 10 A (acc.
  • Page 23 Nexans LAN Systems Power Supplies Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com Nexans article number: 88646182 Description: iPowerSupply S 110-230VAC 48VDC 60W Dimensions (mm): 35x90x84 Ambient temperature range (operating): -25°C to + 70°C (Derating from + 55°C) Input voltage: 110-240V AC / 50Hz / 60Hz / 0.67A Output voltage: 48V DC / 1.25 A (acc.
  • Page 24: Product Overview - Power Supplies

    Contact Nexans LAN Systems Product overview - Power supplies Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com PRODUCT OVERVIEW - POWER SUPPLIES Dimensions, Output power and voltage, installation Nexans Dimensions/ Temperature Description art.-nr. Installation depth (mm) range 88645963 iPowerSupply S 110-230VAC/24VDC 100W 90x90x61 -25…70°C...
  • Page 25: Setting Up The Transmission Parameters

    Contact Nexans LAN Systems Setting up the transmission parameters Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com SETTING UP THE TRANSMISSION PARAMETERS Many problems occurring in data networks can be avoided. Based on many years of practical experience we can recommend the following settings for the switch systems:...
  • Page 26: Memory Cards And Console Cables

    SD Memory Card with MAC integrated Console configuration cables The V.24 console port on Nexans switches allows the configuration of the switch on site and/or retrieve its status without an Ethernet network connection. Configuration via the V.24 console port provides the same functionality as configuration via Telnet or SSH.
  • Page 27: I/O Modules

    I/O MODULES The Nexans I/O module for the iGigaSwitch series is equipped with a removable I/O connector. The outputs, digital inputs and 24V DC output are electrically isolated against each other. The status and fault diagnostics of the I/O module are monitored by the switch management.
  • Page 28 Contact Nexans LAN Systems I/O modules Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com Terminal No. Signal Digital Input 1 Contact No 1 Digital Input 1 Contact No 2 Digital Input 2 Contact No 1 Digital Input 2 Contact No 2...
  • Page 29: Led Indicators

    Contact Nexans LAN Systems LED indicators Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com LED INDICATORS Page 29/49 Generated 2021-11-04...
  • Page 30: Start-Up - Booting

    Nexans default configuration comes with DHCP for addressing the switch. The switch sends a DHCP request as soon as the Status-LED lights up permanently on the management module. If it receives a valid response from a DHCP server, the IP parameters are accepted, and the management module can be immediately accessed via the assigned IP address.
  • Page 31: Configuration Mode

    Contact Nexans LAN Systems Configuration mode Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com CONFIGURATION MODE The pushbutton can be operated using a thin pin, such as a bent-open paper clip. Configuration button Management LED IMPORTANT NOTE: The boot functions ‘Booting with fixed IP Address’ and ‘Booting with Factory Default Settings’ can be individually disabled via the management feature to prevent an accidental or deliberate manipulation by the user.
  • Page 32: Port Status Leds

    Contact Nexans LAN Systems Port status LEDs Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com PORT STATUS LEDS TP Links Lights green Link signal is received at the TP interface Flashes periodically Data packets are received or sent at the TP port...
  • Page 33: Lanactive Managerdescription

    Using the time scheduled firmware update function, chosen switches can be provided with a new firmware by LANactive Manager or by itself. Free of charge Test evaluation Nexans LANactive Manager can be downloaded free of charge for evaluation purposes. Compared to the license- based version, the following restrictions apply: •...
  • Page 34 Contact Nexans LAN Systems LANactive Managerdescription Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com Page 34/49 Generated 2021-11-04...
  • Page 35: Firmware Features

    Modular respectively On-Board high-performance management for Nexans switches • Configuration management and archiving via Nexans LANactive Manager • Manual and automatic firmware update via Nexans LANactive Manager • Automatic loading of a switch configuration via DHCP/BootP option • Automatic loading of a new firmware via DHCP/BootP and command file •...
  • Page 36: Product List

    PRODUCT LIST iGigaSwitch 1604 E+ SFP-4VI HW5 Nexans article number: 88306504 iGigaSwitch 1604 E+ SFP-4VI; 18 - 60V DC, 46 - 57V DC for PoE; WxHxD [mm]: 95 x 184 x 125; 35mm DIN-Rail Mounting acc. to EN 60715, wall mounting; User Ports: 4x 100/1000 SFP, 12x 10/100/1000 TP;...
  • Page 37 Product list Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com iPowerSupply S 110-230VAC/24VDC 100W Nexans article number: 88645963 iPowerSupply S; Out: 100W; 23 - 30V DC; In: 110-240V AC; WxHxD [mm]: 90x90x61; temp.r: -25…70°C; DIN rail mounting; grey iPowerSupply S 110-230VAC/48VDC 100W Nexans article number: 88645960 iPowerSupply S;...
  • Page 38 Nexans SFP 100 Transceiver SM(LC)E L80; Fast Ethernet; Singlemode; TX/RX: 1550/1550; 88646013 80 km; LC-duplex; DDM Support; temp.r: -40°C/+85°C; Dual fibre; Budget: 30 dB Nexans SFP 100 Transceiver SF3(LC)E L10; Fast Ethernet / Single fiber BiDi Modules; 88645914 Singlemode; TX/RX: 1310/1550; 10 km; LC-simplex; DDM Support; temp.r: -40°C/+85°C;...
  • Page 39 Nexans LANmark-OF Duplex LC Snap-In Adaptor Singlemode APC N420.555 Nexans LANmark-5 Evo Snap-In Connector Cat 5e Screened N420.556 Nexans LANmark-5 Evo Snap-In Connector Cat 5e Screened Stranded Wire N420.666 Nexans LANmark-6 Evo Snap-In Connector Cat 6 Screened N420.667 Nexans LANmark-6 Evo Snap-In Connector Cat 6 Screened Stranded Wire N420.66A...
  • Page 40 88646260 Starter Kit Case LANactive Industry N42i.101 Nexans LANmark Industry Modular iConnect Box DIN Rail Mount 6 Snap-In Black Nexans extension for LANmark Industry Modular iConnect Box DIN Rail Mount 6 Snap-In N42i.105 Black N42i.106 Nexans LANmark Industry iConnect Splice Cassette 12x heat shrink protection N42i.102...
  • Page 41: Support Portal

    V6.xx. This ensures that you get all the new features and bug fixes. In addition to the new firmware, the current V5 version of the Nexans LANactive Manager must be installed to manage switches with Management Hardware HW5. This manager version is also backward compatible with switches using Management Hardware HW3, HW2 and HW1.
  • Page 42: Lanactive Starter Kits

    All required components: GigaSwitch V5, SFP modules, installation material and connection cables are in the scope of delivery. The LANactive Industry Starter Kit includes one managed Industrial Ethernet switch from Nexans iGigaSwitch family with PoE+ and I/O functionality as well as several accessories: industrial power supply, SFP transceivers, memory card and serial cable.
  • Page 43 88353910 54VDC 1m 230VAC 1.5m WLND; 1x88645985 Cable Schuko + Wieland 2m GST18I3K1BD 15; 1x88646030 Cover set 45x90 incl. MR, WH/9010, 80x150; 1x88646016 Nexans SFP 1000 Transceiver SM(LC)E, singlemode 1310nm, 10km; 1x88646015 Nexans SFP 1000 Transceiver GI(LC)E, Gbit, multimode 850nm, 550m; 1x88646029 FO adaption kit LC-DX to ST, 0,5m, incl.
  • Page 44 KKM Type III - GST18i3; 1x88645985 Cable Schuko + Wieland 2m GST18I3K1BD 15; 88353658 1x88646030 Cover set 45x90 incl. MR, WH/9010, 80x150; 1x88646016 Nexans SFP 1000 Transceiver SM(LC)E, singlemode 1310nm, 10km; 1x88646015 Nexans SFP 1000 Transceiver GI(LC)E, Gbit, multimode 850nm, 550m; 1x88646029 FO adaption kit LC-DX to ST, 0,5m, incl.
  • Page 45: Frequently Asked Questions (Faq)

    Investment Protection The Nexans Systems are offering a very high level of investment protection. The SFP uplink interface of the GigaSwitch system can be equipped with a Fast Ethernet SFP or a Gigabit SFP module. In case of a data rate change from 100 Mbps to 1000 Mbps you only must change the SFP transceiver module.
  • Page 46 In connection with a central authentication server, e.g. RADIUS, security in enterprise networks is considerably improved. Maximum security is achieved by access control directly at the user port of the Nexans switch system. Thus, the identity of the client is verified directly at the connection point and not only at the bundled port of the central switch.
  • Page 47: Abbreviations

    Contact Nexans LAN Systems Abbreviations Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com ABBREVIATIONS IGMP Internet Group Management Ampere Protocol Access Control List International Electrotechnical Auto-Negotiation Commission Address Resolution Protocol IEEE Institute of Electrical and Electronics Engineers BiDi Bidirectional International Protection...
  • Page 48 Contact Nexans LAN Systems Abbreviations Tel.: +49 (0) 2166 27 2220 sales.ans@nexans.com Receiver Second Secure Copy Protocol SELV Safety Extra Low Voltage Small Form-factor Pluggable Singlemode SNMP Simple Network Management Protocol SNTP Simple Network Time Protocol Structured Query Language Secure Shell...
  • Page 49 Alsembergsesteenweg 2, b3 B-1501 Buizingen Belgium Tel: +32 (0)2 363 38 00 Fax: +32 (0)2 365 09 99 Bonnenbroicher Str. 2-14 41238 Monchengladbach Germany Tel: +49 2166 27-2220 Fax: +49 2166 27-2499...
