Savant WFB LV02 Series Quick Reference Manual

Ascend Style Low Voltage Keypads - Quick Reference Guide
Box Contents
(1) Keypad (The SKU determines the button format)
(1) 5-position plug-in terminal block with wires (028-0948)
(1) 1-Gang Wall Plate Retainer (093-3146)
3/4
(2) 6-32 x inch pan head screw (039-0345)
(1) Product Regulatory Statement (009-1950)
Products
– Five Button Keypad (WFB-xxLV05)
– Four Button Keypad (WFB-xxLV04)
– Two Button Keypad (WFB-xxLV02)
Optional Accessories
– Button Replacement Kit (WFB-xxLVC)
(includes two, four, and five button replacement assemblies)
– Button Engraving Kit (WFB-xxENGV)
– One to Four Gang Wall Plates (FFx-0S0xxM)
(all finishes available)
– Custom Built Multi-Ganged Keypad Assemblies (WFB-XGxxLV)
(built as designed using the Lighting and Keypad Designer Tool)
Specifications
Environmental
Temperature 32° to 104° F (0° to 40° C)
Humidity 10% to 90% Relative Humidity (non-condensing)
Location Indoor Use Only
Finishes
– Brushed Aluminum – Brushed Black
– Brushed Brass – Black
– Brushed Bronze – Snow White
Dimensions and Weights
Length
WFB-xxLV05
4.69 inch
WFB-xxLV04
(11.92 cm)
WFB-xxLV02
6.3 inch
Shipping
(16 cm)
Installation Recommendations
Savant recommends as a minimum:
– An open-backed low voltage bracket installed on the interior
walls and a closed-back electrical box on exterior walls.
– An installation depth of at least 1
Power
Input
Average Power Consumption
Maximum Power Consumption 1.4 watts
Regulatory
FCC Part 15
Safety and
Emissions
RoHS Compliant
Minimum Supported Release
da Vinci 9.4.2
Ascend Style Low Voltage Keypads QRG | 009-2044-02
Copyright© 2022 Savant Systems, Inc. | 220107
– Light Almond
– Space Gray
– Nickel
Width Depth Weight
1.72 inch .97 inch .30 lb.
(7.52 cm) (2.46 cm) (0.13 kg)
4.2 inch 2.3 inch 1.0 lb.
(10.67 cm) (5.84 cm) (0.45 kg)
1/8
inches (2.9 cm).
24V DC
0.5 watts
UKCA
CE
Front Panel
A
B
A
C
WFB-xxLV02
Buttons - Programmable buttons. See the Low Voltage
Deployment Guide for instructions on how to program.
A
This guide and other lighting information are available
on the Keypad Lighting Documentation Portal on the
Savant Customer
Button Back-lights - When configured and bound to a
Savant system, the state of the back-lights is defined by
the selection made in the LED Behavior and LED Color
B
fields in Blueprint's Lighting and Shade Manager.
During the initial discovery and configuration process,
the back-lights indicate the state of the keypad. See the
Button Backlight Sequencing
Ambient Light Sensor - Detects the ambient light level in
the room and adjusts the brightness of the button back-
C
lights. The ambient light sensor is enabled and disabled
using Blueprint's Lighting and Shade Manager.
Rear Panel
E
D
Wires are 5 inch,
#22 AWG stranded.
1 of 3
B
B
A
C
WFB-xxLV04 WFB-xxLV05
Community.
section below.
The rear panel hosts a 5-pin
keypad bus connector that
accepts the supplied 5-inch
keypad pigtail cable. The
connector is keyed and can't
D
be plugged backwards.
Use wire-nuts or an approved
alternative when connecting
to other keypads.
Reset Button
Press and release - Reboots
the keypad.
Press and hold - Press and
E
hold for 5 seconds, then
release to perform a factory
reset. A factory reset erases
the keypad's stored address.
Red 24V DC Input
Black 24V DC Gnd
White A+ (data)
Orange B- (data)
Yellow Contact Closure
45 Perseverance Way, Hyannis MA 02601.
Savant.com
A
C
| 508.683.2500
