Savant Echo Quick Reference Manual

Echo Wireless Keypads
Quick Reference Guide
The Echo wireless dimmers are specifically designed to function within a Savant Control system to switch most lighting loads. This
includes incandescent, magnetic and electronic low voltage, dimmable CFL, and dimmable LED lamps.
The Savant Echo wireless dimmers replace any standard 120V AV light switch or dimmer and can be wired into either a standard
or no neutral configuration. With the addition of the Savant WP3-xx002 Auxiliary Control, these dimmers can accommodate most
3-way wiring designs for multi-location control,
Finally, the dimmers communicates with 802.11 b/g/n wireless network which allow it to be added to the Savant Control system for
complete control of all lighting requirements over the local wireless network.

Box Contents

(1) Dimmer without faceplate
(2) Mounting Screws
(5) Wire Nuts
(1) Quick Reference Guide (this document)

Products

Adaptive Dimming

Echo Wireless Configurable Keypad (WPB-xxA106-00)
Echo Wireless Dimmer (WPD-xxA102-00)
Echo Wireless Dial Keypad (WPK-xxA105-00)

Supported Load Types

Standard Incandescent, Electronic/Magnetic Low
Configuration Voltage, Dimmable CFL, Dimmable LED
No Neutral Incandescent only
Configuration (minimum load = 25Watts)
MLV Dimming
Echo Wireless Configurable Keypad (WPB-xxT106-00)
Echo Wireless Dimmer (WPD-xxT102-00)
Echo Wireless Dial Keypad (WPK-xxT105-00)
Supported Load Types
Standard Incandescent, Magnetic Low Voltage,
Configuration Dimmable CFL, Dimmable LED
No Neutral Incandescent only
Configuration (minimum load = 25Watts)
WARNING! Using a keypad in No Neutral configuration
with loads other than incandescent is not supported.

Regulatory

The following statements are applicable to the Echo Wireless Dimmers, Switches, and
Keypads.
FCC Regulations
15.19. These devices comply with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) These devices may not cause harmful interference, and
(2) these devices must accept any interference received, including interferences that
may cause undesired operation. 15.21. The changes or modifications not expressly
approved by the party responsible for compliance could void the user's authority to
operate the equipment. 15.105. This equipment has been tested and found to comply
with the limits for CLASS B digital device, pursuant to Part 15 of FCC Rules. These
limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a residential environment. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications, However there is no guarantee that interference will not occur in
a particular installation, If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
– Reorient or relocate the receiving circuit different from that to which receiver
is connected.
– Increase the separation between the equipment and the receiver.
– Consult the dealer or experienced radio/TV technician for help.
IC Regulations:
RSS-Gen 7.1.3. These devices comply with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions: (1) These devices
may not cause interference, and (2) These devices must accept any interference,
including interference that may cause undesired operation of the device. RSS-
21- Annexe 9: A 9.4. Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
Echo Wireless Dimmers
009-1757-02 | 190603

Specifications

Environmental

Temperature 32° to 104° F (0° to 40° C)
10% to 90% Relative Humidity
Humidity
(non-condensing)
Location Indoor Use Only
Pollution Degree 2
Dimensions
Height 4.13in (10.50cm) Shipping 7.0in (17.78cm)
Width 2.36in (6.00cm) Shipping 4.5in (11.43cm)
WPB-xxS106 - 1.57in (3.99cm)
WPS-xxS102 - 1.57in (3.99cm)
Depth
WPK-xxS105 - 1.80in (4.60cm)
Shipping 3.0in (7.62cm)
Weight Shipping 0.60lb (0.272kg)

Recommended Back Box Depth

All Echo Dimmers and switches require a standard U.S.
electrical back box.
– Recommended - 3.5 in (8.89 cm) deep
– Minimum 2.25 in (5.72 cm) deep
– Type 1 enclosure for control

Mounting

Independently mounted (vertical position only)

Installation

Operating
Type 1.B action
Control
Software Class A
Power
Input 120V AC at 60 Hz
Power:
550W 5A @ 120V AC (See
Load (Max)
Rated impulse
2500V
voltage
Standards
Wireless 802.11 b/g/n 2.4 GHz (only)
Security WPA™, WPA2™, WPA1™ +WPA2™, WEP
Regulatory
FCC Part 15 | UL
Safety and
For more details, see the Regulatory and
Emissions
Safety insert.
Contains FCC
TLZ-CU277B
ID:
Contains IC: 6100A-CU277B
RoHS Compliant
Minimum Supported Release
da Vinci Blueprint 9.0
1 of 4
Derating
Copyright © 2018 Savant Systems, LLC
Table)
