CMe3100 DLMS Plugin User's Manual
The Plugin will automatically restart and start listening on the given port once changes are saved.

5.2.3 System title

The system title identifies the gateway during DLMS communication. This field is read-only and
hold a per product unique string (shown for informational use only). See 7.2.1 for more
information.

5.2.4 Change meter addressing mode

The Product enables two types of addressing modes; Channel selection and Logical device
addressing, see section 7.4 for more information.
This parameter is no longer used. Both Channel selection and Logical device addressing are
supported in parallel.

5.2.5 Value interval for profiles

The Product enables poll/push operation of three different generic profiles; Load profile 1, Load
profile 2 and Billing profile.
Figure 5 Settings page - Value interval for profiles
All three profiles can be configured individually to allow maximum flexibility regarding what value
interval that is of interest.
Please note that the value interval needs to be an even multiple of the meter readout
schedule (Meters > Readout schedule). For example, setting the meter readout schedule to 15
minutes and selecting 1 hour for load profile 1 will return every 4
Selecting "All values" will result in using the same value interval as configured for the meter
readout schedule (see Figure 6 for a complete list of options).
CMe3100 DLMS Plugin User's Manual
th
11 48
page | ( )
value read from the meters.
