Saynet-EI-Mountain Gale (RC)-WH21
OWNER'S MANUAL
‫מדריך למשתמש‬
Mountain Gale
Please write model number here for future reference:
:‫אנא כתוב מספר דגם כאן לעיון בעתיד‬
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mountain Gale and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Westinghouse Mountain Gale

Summary of Contents for Westinghouse Mountain Gale

  • Page 1 Saynet-EI-Mountain Gale (RC)-WH21 OWNER'S MANUAL ‫מדריך למשתמש‬ Mountain Gale Please write model number here for future reference: :‫אנא כתוב מספר דגם כאן לעיון בעתיד‬...

  • Page 2: Safety Tips

    Saynet-EI-Mountain Gale (RC)-WH21 SAFETY TIPS READ AND SAVE THESE INSTRUCTIONS WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: 1. Proceed with caution. Read all instructions before beginning the installation. 2. WARNING! This fan may be operated only with a 2-pole switch with a 3mm contact opening each.
  • Page 3 Saynet-EI-Mountain Gale (RC)-WH21 ‫טיפים לבטיחות‬ ‫קרא ושמור את ההוראות‬ :‫אזהרה: להפחתת סיכון לשריפה, התחשמלות או פגיעה באנשים, הקפידו לפעול לפי ההוראות הבאות‬ .‫1. המשך בזהירות. קרא את כל ההוראות לפני שתתחיל בהתקנה‬ .‫2. אזהרה! מאוורר זה יכול להיות מופעל רק עם מתג דו-קוטבי עם פתח מגע 3 מ"מ כל אחד‬...

  • Page 4: Preparing For Installation

    Saynet-EI-Mountain Gale (RC)-WH21 PREPARING FOR INSTALLATION MOUNTING BRACKET INSTALLATION ‫הכנה להתקנה‬ ‫התקנת תושבת תליה‬ Unpack and inspect fan carefully to be certain all contents are included. Turn off power Remove the screws from the two mating holes (1) on the canopy. Loosen (do not remove) the at fuse box to avoid possible electrical shock.
  • Page 5 Saynet-EI-Mountain Gale (RC)-WH21 MOUNTING BRACKET INSTALLATION ‫הילת תבשות תנקתה‬ Note: Proper care must be taken when mounting to concrete ceilings and add Note: This step is for Solid Wood construction ceiling installation, for concrete the expansion anchors installation step for mounting bracket.
  • Page 6 Saynet-EI-Mountain Gale (RC)-WH21 MOUNTING BRACKET INSTALLATION ‫התקנת תושבת תליה‬ Drive the expansion anchors (1) into the holes. (Note: do not detach hex nut (2), spring washer (3) and metal washer (4) for this step). Tighten hex nut until feel the metal expansion anchor is not working loose.
  • Page 7 Saynet-EI-Mountain Gale (RC)-WH21 MOUNTING BRACKET INSTALLATION ‫התקנת תושבת תליה‬ Pull the supply mains (1) through the center of the ceiling, and align the two oval holes in the mounting bracket with the expansion anchors (1), re-install metal washer, spring washer and hex nut, tighten the hex nut until the mounting bracket is fix stably.

  • Page 8: Wiring Options

    Saynet-EI-Mountain Gale (RC)-WH21 WIRING OPTIONS MOUNTING BRACKET INSTALLATION ‫אפשרויות חיווט‬ ‫התקנת תושבת תליה‬ Wiring: From House: TERMINAL BLOCK Connector: Live (L) Neutral (N) Ground Follow diagram above to make wiring connections to the termi- nal block on the mounting bracket.
  • Page 9 Saynet-EI-Mountain Gale (RC)-WH21 DOWNROD MOUNT ‫התקנת מוט תליה‬ Remove clamp pin (2) and cross pin (1) from downrod. Loosen setscrew in downrod ball (3) until ball moves easily up and down the downrod. Do not remove ground wire (4) from downrod.
  • Page 10 Saynet-EI-Mountain Gale (RC)-WH21 DOWNROD MOUNT ‫התקנת מוט תליה‬ Insert the downrod through the canopy and coupling cover. Carefully thread lead wires and plug though the downrod and ball assembly. Re-install cross pin into downrod and slide downrod ball up until cross pin fits firmly into ball.
  • Page 11 Saynet-EI-Mountain Gale (RC)-WH21 DOWNROD MOUNT ‫התקנת מוט תליה‬ Loose (but do not remove) the set screws from the down rod coupling. Insert downrod (1) into downrod coupling (2). Make sure to align hole in downrod with the hole in downrod coupling. Install cross pin (3) through coupling and downrod. Insert clamp pin (4) into cross pin until it snaps into place. Tighten set screws (5) in coupling. Slide coupling cover (6) over the downrod coupling.
  • Page 12 Saynet-EI-Mountain Gale (RC)-WH21 MOUNTING BRACKET INSTALLATION MOUNTING ‫התקנת תושבת תליה‬ ‫התקנה‬ After hanging fan onto the mounting bracket, make sure plug connectors from the ceiling Carefully lift fan assembly onto mounting bracket. Rotate fan until notch on downrod ball (1) fan and terminal block (1) are moved away from the space located above the downrod ball engages the ridge (2) on the mounting bracket.
  • Page 13 Saynet-EI-Mountain Gale (RC)-WH21 WIRING OPTIONS ‫אפשרויות חיווט‬ While fan is hanging on bracket, plug 4-pole connector from the mounting bracket into the 4-pole plug connector from the remote receiver (1). Plug the 4-pole plug connector from the remote receiver into the 4-pole plug connector from the fan (2).
  • Page 14 Saynet-EI-Mountain Gale (RC)-WH21 SECURE TO CEILING ‫קיבוע לתקרה‬ The canopy has two mating slots (1) and two mating holes (2). Position both slots on canopy directly under and in line with two screws in the mounting bracket (3). Lift the canopy, allowing the two screws to slide into the mating slots.

  • Page 15: Blades Installation

    Saynet-EI-Mountain Gale (RC)-WH21 BLADES INSTALLATION ‫התקנת הלהבים‬ Attach blade brackets to blades using the blade bracket screws (1), rubber washers (2), flat Attach blade assembly to motor using the screws (1), rubber washers (2), metal washers washers (3) and nuts (4). Please screw the screws with a manual scredriver and not with (3) provided.
  • Page 16 Saynet-EI-Mountain Gale (RC)-WH21 BRACKET OF TRANSMITTER INSTALLATION ‫התקנת תושבת לשלט‬ Note: Install two AAA batteries by removing battery cover on back of transmitter, installing batteries, and replacing battery cover. If desired, install the transmitter holder onto the wall with included screws.

  • Page 17: Remote Control

    Saynet-EI-Mountain Gale (RC)-WH21 REMOTE CONTROL ‫שלט רחוק‬ Remote Control Operation 1. Turning fan off (switch symbol) - press and release. 2. Turning on fan speeds button-press and release. The remote control operates the fan speed as below: 3-high; 2-medium; 1-low.

  • Page 18: How To Operate Your Ceiling Fan

    Saynet-EI-Mountain Gale (RC)-WH21 HOW TO OPERATE YOUR CEILING FAN ‫כיצד להפעיל את מאוורר התקרה שלך‬ Restore electrical power to the outlet box by turning on the electricity at the main fuse box. To make the fan operational, open battery door by pressing and sliding down the battery door.
  • Page 19 Saynet-EI-Mountain Gale (RC)-WH21 HOW TO OPERATE YOUR CEILING FAN ‫כיצד להפעיל את מאוורר התקרה שלך‬ .‫בסיום כל שלבי התקנת המאוורר וחיבור המקלט, יש להחזיר את אספקת החשמל‬ .‫ (לא מסופקות) טרם השימוש‬AAAa1.5V ‫יש להכניס לתוך השלט שתי סוללות מסוג‬ ‫אזהרה: במידה ואין שימוש בשלט למשך תקופה ארוכה, יש להוציא את הסוללות בכדי‬...

  • Page 20: Operation And Maintenance

    Saynet-EI-Mountain Gale (RC)-WH21 OPERATION & MAINTENANCE Operation Speed settings for warm or cool weather depend on factors such as room size, ceiling height, number of fans and so on. The slide switch controls direction, forward or reverse. Warm weather/down position - (Forward) Fan turns counterclockwise direction. A downward air flow creates a cooling effect as shown in illustration A.
  • Page 21 Saynet-EI-Mountain Gale (RC)-WH21 ‫תפעול ותחזוקה‬ ‫תפעול‬ .‫הגדרות המהירות למזג אוויר חם או קריר תלויות בגורמים כמו גודל החדר, גובה התקרה, מספר המאווררים וכן הלאה‬ .‫קיים מתג השולט בכיוון הסיבוב, עם או נגד כיוון השעון‬ .A‫מזג אוויר חם / נגד כיוון השעון - המאוורר מסתובב נגד כיוון השעון, זרימת אוויר כלפי מטה יוצרת אפקט קירור כפי שמוצג באיור‬...

  • Page 22: Troubleshooting Guide

    Saynet-EI-Mountain Gale (RC)-WH21 If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be TROUBLESHOOTING GUIDE mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart.
  • Page 23 Saynet-EI-Mountain Gale (RC)-WH21 ‫מדריך פתרון בעיות‬ ‫אם אתה מתקשה להפעיל את מאוורר התקרה החדש שלך, זה עשוי להיות‬ ‫תוצאה של הרכבה, התקנה או חיווט שגויים. במקרים מסוימים, טעויות התקנה‬ ‫אלה עלולות להיחשב לעתים בתור פגמים. אם אתה נתקל בתקלות כלשהן, אנא‬...
  • Page 24 Saynet-EI-Mountain Gale (RC)-WH21 Meaning of crossed-out wheeled dustbin: Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact you local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being.
  • Page 25 Saynet-EI-Mountain Gale (RC)-WH21...
  • Page 26 Saynet-EI-Mountain Gale (RC)-WH21...
  • Page 27 Saynet-EI-Mountain Gale (RC)-WH21...
  • Page 28 Saynet-EI-Mountain Gale (RC)-WH21 Westinghouse Lighting, Philadelphia, PA 19154-1029, U.S.A. www.westinghouselighting.com and Westinghouse are trademarks of Westinghouse Electric Corporation. Used under license by Westinghouse Lighting. All Rights Reserved. Made in China...
