ASSEMBLY GUIDE
H36XMS-12, H40XM-12, H44XM-12, H48XM-12
H40XM-12, H44XM-12, H48XM-12, H36XMS-12,
H40XMS-12, H44XMS-12, H48XMS-12
(H800HDS, H900HDS, H970HDS, H1050HDS,
H900HD, H970HD, H1050HD) [C917]
PART NO. 1648460
H40.00-48.00XM-12
(H800-1050HD/HDS) [A917];
(H800HD, H1050HD) [B917];
8000 SRM 1306

Advertisement

loading
Need help?

Need help?

Do you have a question about the H40.00-48.00XM-12 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hyster H40.00-48.00XM-12

  • Page 1 ASSEMBLY GUIDE H40.00-48.00XM-12 (H800-1050HD/HDS) [A917]; H36XMS-12, H40XM-12, H44XM-12, H48XM-12 (H800HD, H1050HD) [B917]; H40XM-12, H44XM-12, H48XM-12, H36XMS-12, H40XMS-12, H44XMS-12, H48XMS-12 (H800HDS, H900HDS, H970HDS, H1050HDS, H900HD, H970HD, H1050HD) [C917] PART NO. 1648460 8000 SRM 1306...
  • Page 2 • Keep the tools clean and in good condition. • Always use HYSTER APPROVED parts when making repairs. Replacement parts must meet or ex- ceed the specifications of the original equipment manufacturer. • Make sure all nuts, bolts, snap rings, and other fastening devices are removed before using force to remove parts.
  • Page 3 Install Tire on the Wheel ..........................31 Tire Installation on the Wheel ........................31 Adding Air Pressure to the Tires ........................34 Install Wheels on Lift Truck ..........................34 Pre-Delivery ................................35 Adjust Timing for Automatic Engine Shut Down ................... 35 ©2015 HYSTER COMPANY...
  • Page 4 Instructions Operating Manual ........................36 Instructions Daily Maintenance ........................36 Handing Over Truck ............................36 This section is for the following models: H40.00-48.00XM-12 (H800-1050HD/HDS) [A917]; H36XMS-12, H40XM-12, H44XM-12, H48XM-12 (H800HD, H1050HD) [B917]; H40XM-12, H44XM-12, H48XM-12, H36XMS-12, H40XMS-12, H44XMS-12, H48XMS-12 (H800HDS, H900HDS, H970HDS, H1050HDS, H900HD, H970HD,...
  • Page 5 8000 SRM 1306 General General This manual contains the information that is WARNING required for transportation and reassembly of truck series A917, B917, and C917. The information Read all the instructions contained in this manual covers each component that may have been before starting any work on the unit.
  • Page 6 Weight and Dimensions 8000 SRM 1306 Weight and Dimensions A. WIDTH C. HEIGHT B. LENGTH Figure 1. Basic Truck A917 Width, Length, and Height Table 1. Basic Truck A917 Model Width Length Height Weight H36.00XM-12/ 4,230 mm 7,180 mm 3,845 mm 36,900 kg 39,750 kg H800HD...
  • Page 7 8000 SRM 1306 Weight and Dimensions A. WIDTH C. HEIGHT B. LENGTH Figure 2. Basic Truck B917 and C917 Width, Length, and Height Table 2. Basic Truck B917 and C917 Model Width Length Height Weight H36XMS-12/ 4,210 mm 7,250 mm 3,890 mm 36,900 kg 39,750 kg...
  • Page 8 Weight and Dimensions 8000 SRM 1306 A. LENGTH C. WIDTH B. HEIGHT Figure 3. Mast Width, Length, and Height...
  • Page 9 8000 SRM 1306 Weight and Dimensions Table 3. Mast Lift Height Length Height Width Weight 4,267 mm 4,760 mm 806 mm 2,800 mm 9,220 kg (167.9 in.) (187.4 in.) (31.7 in.) (110 in.) (20,326 lb) 7,010 mm 6,130 mm 806 mm 2,800 mm 11,110 kg (275.9 in.)
  • Page 10 Weight and Dimensions 8000 SRM 1306 A. WIDTH C. HEIGHT B. LENGTH Figure 5. Container Attachment Width, Length, and Height (optional for A917 and B917) Table 5. Container Attachment (optional for A917 and B917) Width Length Height Weight 2,433 mm 6,042 mm 1,193 mm 7,400 kg...
  • Page 11 8000 SRM 1306 Weight and Dimensions A. WIDTH C. LENGTH B. HEIGHT Figure 6. Forks Width, Length, and Height Table 6. Forks Type Width Height Length Weight QD 5.5X12-96 600 mm 2,240 mm 2,720 mm 2,680 kg (23.6 in.) (88 in.) (107 in.) (5,908 lb) QD 5.5X12-83...
  • Page 12 Loading Procedures 8000 SRM 1306 Loading Procedures LOADING TRUCK ON A TRANSPORT A crane can only be used to load or unload the lift truck if the lift truck is equipped with lifting eyes. Otherwise, the lift truck must be driven on or off WARNING the transport.
  • Page 13 8000 SRM 1306 Loading Procedures 1. TIE DOWN POINT Figure 7. Lift Truck Tie Down Placement 1. SLING OR TIE DOWN POINT Figure 8. Attachment Tie Down Placement...
  • Page 14 Loading Procedures 8000 SRM 1306 1. SLING OR TIE DOWN POINT Figure 9. Mast Tie Down Placement...
  • Page 15 8000 SRM 1306 Loading Procedures 1. SLING OR TIE DOWN POINT Figure 10. Carriage Tie Down Placement 1. SLING OR TIE DOWN POINT Figure 11. Forks Tie Down Placement...
  • Page 16 Unloading Procedures 8000 SRM 1306 Unloading Procedures UNLOADING TRUCK FROM TRANSPORT UNLOADING DISASSEMBLED COMPONENTS Driving On/Off a Trailer To lift the components from a transport either use a When the truck will be driven from a trailer make fork lift or attach hooks and/or slings to the lifting sure to have read and understood the Starting Pro- eyes and slinging points as indicated on Figure 7 cedures as described in the Operating Manual.
