Summary of Contents for Bartscher 700835
- Page 1 235L 700835...
- Page 2 Bartscher GmbH Phone: +49 5258 971-0 Franz-Kleine-Str. 28 Fax: +49 5258 971-120 Technical Support Hotline: +49 5258 971-197 D-33154 Salzkotten Germany www.bartscher.com Version: 1.0 Date of preparation: 2021-10-25...
-
Page 3: Table Of Contents
Functions of the Appliance ..............12 Installation and operation ................12 Installation ....................12 Operation ....................16 Cleaning and Maintenance ................22 Safety Instructions for Cleaning ............. 22 Cleaning ....................22 Possible Malfunctions .................. 24 Disposal ....................... 26 700835 1 / 28... -
Page 4: Safety
You must strictly follow the instructions, to prevent accidents, personal injuries and property damages. DANGER! The signal word DANGER warns against hazards that lead to severe injuries or death if the hazards are not avoided. 2 / 28 700835... -
Page 5: Safety Instructions
Do not transport the appliance, holding it by the power cord. • Do not allow the power cord to come into contact with heat sources or sharp edges. • Do not bend, pinch nor knot the power cord. 700835 3 / 28... - Page 6 This appliance is not intended to be used by persons (including children) with limited physical, sensory or mental capabilities, nor by persons with limited experience and/or limited knowledge. • Children should be supervised to ensure that they are not playing with or switching the appliance on. Improper Use 4 / 28 700835...
- Page 7 • Do not introduce any changes in the appliance nor modify it. • Do not drill hole in the appliance nor install any objects on it. • Do not place any heavy objects on the appliance. 700835 5 / 28...
-
Page 8: Intended Use
The following is an unintended use: – Storing flammable or explosive objects and liquids, such as ether, petroleum or adhesives; – Storing explosive materials, like sprays filled with flammable propellants; – Storing pharmaceutical products or preserved blood. 6 / 28 700835... -
Page 9: General Information
Declaration of Conformity The appliance meets the currently applicable standards and guidelines of the European Union. We confirm the above in the EC Declaration of Conformity. We may provide relevant Declaration of Conformity upon request. 700835 7 / 28... -
Page 10: Transport, Packaging And Storage
– in a location protected against mechanical shocks. In the case of extended storage (over three months), make sure you check the condition of the packaging and the parts regularly. If needed, replace the packaging with a new one. 8 / 28 700835... -
Page 11: Technical Data
Technical Data Technical Data Technical Specifications Name: Bakery freezer 235L 700835 Art. No.: Material: stainless steel Inner material: stainless steel Volume, in l: Temperature range, min.–max., in °C: -18 - -22 Amount of coolant, in kg: R290a / 0,132 Climate class:... - Page 12 More information on the appliance is available in our website www.bartscher.com or, pursuant to the Regulation (EU) 2015/1095, in our product data base at https://energy-label.ec.europa.eu/. Enter article number for a given model. 10 / 28 700835...
-
Page 13: List Of Components Of The Appliance
4. Digital temperature controller 5. Housing 6. Door with flush handle 7. Door seal 8. Fan 9. Internal LED lighting 10. Rack with guide rails 11. Oven sheet (4 pcs) 12. Feet (4x) 13. Bottom working surface 700835 11 / 28... -
Page 14: Functions Of The Appliance
– sufficiently large, and thus enabling usage of the appliance with no problems; – easily accessible; – well ventilated. • To install the appliance, perform the following steps: – Remove the packaging of the appliance, except for the pallet. 12 / 28 700835... - Page 15 The el ectric soc ket s hould be easil y accessibl e s o it is pos sibl e to quic kl y disconnect the power c ord when nec ess ar y. HINWEIS IMPORTANT! The appliance is not suitable for built-in installation. 700835 13 / 28...
- Page 16 The following tools are required: flat spanner No. 8 and 10, Phillips screwdriver. ATTENTION! Pull the mains plug out before you attempt to change the door hinge side. Do not place the appliance in horizontal position in order to change the door hinge side. 14 / 28 700835...
- Page 17 Installation and operation 700835 15 / 28...
-
Page 18: Operation
If possible, in the event of a sudden power failure, avoid opening doors in order to avoid loss of cool air. • If the appliance is switched off for a longer period of time, the appliance door should remain open. 16 / 28 700835... - Page 19 5. Prior to the first use of the appliance or after a break in operation, but before you place suitable food products in the appliance, leave the appliance on to reach the right temperature. 6. When operating the appliance, follow instructions in section 'Settings'. 700835 17 / 28...
- Page 20 Displaying the minimum stored temperature, selection of parameter code in programming mode, decreasing the displayed value Switching the appliance on or off Switching the internal LED lighting of the appliance on or off 18 / 28 700835...
- Page 21 (wiring or components) illuminates alarm is activated illuminates continuous cycle active illuminates Energy-saving mode active illuminates degrees Celsius temperature unit indicator flashes in programming mode illuminates degrees Fahrenheit temperature unit indicator flashes in programming mode 700835 19 / 28...
- Page 22 5 seconds, to return to the previous message. Changing the Set Value (i.e. the Required Temperature) 1. Press the key and hold it for over 2 seconds. The set value is displayed and the LED indicator flashes on the digital display. 20 / 28 700835...
- Page 23 3 seconds; the digital display shows 'Pof' – in order to unlock, press again both keys concurrently and hold them pressed for more than 3 seconds; until the digital display shows 'Pon' Moving to the programming mode: 700835 21 / 28...
-
Page 24: Cleaning And Maintenance
• For cleaning, do not use any scouring agents that contain solvents nor corrosive cleaning agents. They may damage the surface. Cleaning 1. Wash the appliance regularly. 22 / 28 700835... - Page 25 The following operations should be regularly performed by a qualified specialist: – cleaning the condenser with suitable tools (vacuum cleaner or soft brush); – checking of electrical connections; – checking of the thermostat and the sensor; – checking of door and door seal. 700835 23 / 28...
-
Page 26: Possible Malfunctions
Door is not closed properly Close the door tightly; limit the or it has been opened for door opening time to too long minimum Damaged or deformed door Contact the service company seal 24 / 28 700835... - Page 27 Clogged condensed water Clear the condensed water drain opening drain opening Condensed water drip tray Contact the service company damaged (if applicable) Condensed water overflows Empty the condensed water the drip tray (if applicable) drip tray regularly 700835 25 / 28...
-
Page 28: Disposal
Electrical appliances should be returned to designated collection points. Coolant The propellant used in the appliance is flammable. It should be utilised pursuant to national regulations in force. 26 / 28 700835...
