9. APPENDIX C. REFERENCE

Specifications

Specification
Electrical
Connections
Conformance Tested, OPC Self-tested for Compliance, RoHS Compliant, CSA 205 Approved
Approvals
Power
Requirements
Physical
Dimensions
Weight
Operating
Temperature
Surge
Suppression
Humidity

Compliance with UL Regulations

For UL compliance, the following instructions must be met
when operating the ProtoNode.
• The units shall be powered by listed LPS or Class
2 power supply suited to the expected operating
temperature range.
• The interconnecting power connector and power
cable shall:
• Comply with local electrical code.
• Be suited to the expected operating temperature
range.
• Meet the current and voltage rating for the
ProtoNode/Net.
26
ProtoNode RER
One 6-pin Phoenix connector,
one RS-485 +/- ground port,
power +/- frame ground port,
One 3-pin RS-485 Phoenix connector,
one RS-485 +/- ground port,
One Ethernet-10/100 Ethernet port
Pending CE (EN55022; EN55024; EN60950), UL916, Pending FCC Class A Part 15, DNP3
BTL Marked
Multi-mode power adapter: 9-30VDC or 12 - 24VAC 2.5 W
11.5 cm L x 8.3 cm W x 4.1 cm H (4.5 x 3.2 x 1.6 in.)
EN61000-4-2 ESD EN61000-4-3 EMC EN61000-4-4 EFT
(Specifications subject to change without notice)
UNCONTROLLED DOCUMENT IF PRINTED
APPROVED
One 6-pin Phoenix connector,
One Ethernet 10/100 BaseT port,
0.2 kg (0.4 lbs)
-40°C to 75°C (-40°F to 167°F)
5 - 90% RH (non-condensing)
• Furthermore, the interconnecting power cable shall:
• Be of length not exceeding 3.05 m (118.3").
• Be constructed of materials rated VW-1 or FT-1
or better.
• If the unit is to be installed in an operating environment
with a temperature above 65 °C, it should be installed
in a Restricted Access Area requiring a key or a
special tool to gain access.
• This device must not be connected to a LAN segment
with outdoor wiring.
ProtoNode LER
one RS-485 +/- ground port,
power +/- frame ground port,
One FTT-10 LonWorks port
LonMark Certified
