CHARGING PROGRAMS
Settings are made by pressing the MODE-button. After about two seconds the charger
activates the selected program. The selected program will be restarted next time the
charger is connected.
The table explains the different Charging Programs:
Battery
Program
Size (Ah)
Normal battery program 14.4V/7A.
14–225Ah Use for WET batteries,
NORMAL
Ca/Ca, MF and for most GEL batteries
AGM AGM battery program 14.7V/7A
Use for AGM batteries.
14–225Ah
Recond program 15.8V/1.5A
Use to return energy to the empty WET
and Ca/Ca batteries. Recond your battery
once per year and after deep dischare
to maximise lifetime and capacity. The
Recond program adds the Recond step
RECOND 14–225Ah
to the normal battery program.
Frequent use of the Recond program
may cause water loss in the batteries and
reduce service life of electronics. Contact
your vehicle and battery supplier for
advice.
Supply program 13.6V/7A
Use as 12V power supply or use for
float maintenance charging when 100%
14–225Ah
capacity of the battery is required. Supply
program activates Float step without time
or voltage limitation.
WARNING!
The spark protection on the battery charger
is disabled during SUPPLY program.
EN
20016109A MXS 7.0, Manual EAST 8, print file 002.indd 4
Explanation Temp range
+5°C–+50°C
(41ºF–122ºF)
-20°C–+5°C
(-4ºF–41ºF)
-20°C–+50°C
(-4ºF–122ºF)
-20°C–+50°C
(-4ºF–122ºF)

ERROR LAMP

If the error lamp is lit, check the following:
1. Is the chargers positive lead connected to the batterys
positive pole?
2. Is the charger connected to a 12V battery?
3. The clamps are short circuited?
4. Has charging been interrupted in
Restart the charger by pressing the MODE-button. If charging is still
being interrupted, the battery...
...is seriosly sulphated and may need to be replaced.
...can not accept charge and may need to be replaced.
...can not keep charge and may need to be replaced.

READY TO USE

The table shows the estimated time for empty battery to 80% charge
BATTERY SIZE (Ah) TIME TO 80% CHARGED
20Ah
50Ah
100Ah
150Ah
or ?
2h
6h
12h
17h
