- Page 1 ONYX Battery Charger For lead-acid batteries 14–225Ah User’s manual and guide to professional battery charging for starter and deep cycle batteries.
- Page 2 Pulse Maintenance, Float and Analysis. ONYX is a member of a family of professional chargers from CTEK Sweden AB. It represents the state-of-the-art technology for battery charging. A ONYX will prolong the lifetime of your battery. Read this user manual and follow the instructions carefully before using the charger.
- Page 3 CHARGING Charging batteries mounted in a vehicle: 1. The power cord should be disconnected before connecting or disconnecting the battery leads. 2. Identify the pole that is grounded (attached to the chassis). Ground is normally connected to the negative terminal. 3.
- Page 4 ONYX is protected from being overheated. The power will be reduced if the ambient tempera- ture is raised. EQUIPMENT ONYX is delivered with a set of battery leads with battery pole clamps and a set of battery leads with eyelet terminals.
-
Page 5: Technical Specification
**) Quality of the current and voltage are very important. High current ripple heats up the battery and makes the positive electrode age prematurely. High voltage ripple could harm other equipment connected to the battery. ONYX produces a high quality current and voltage with very low ripple. - Page 6 EN55014-2 according to the terms of directive 89/336/EEC with the addition of 92/31/EEC and 93/68/EEC. VIKMANSHYTTAN, SWEDEN 2006-01-23 Börje Maleus, VP CTEK SWEDEN AB, Rostugnsvägen 3 SE-776 70 VIKMANSHYTTAN, SWEDEN Fax: +46 225 30793 www.ctek.com CHARGING TIME The table shows the length of time for bulk charging.
