- Page 1 ASSEMBLY INSTRUCTIONS Description : TRESTLE BENCH Item No. : BE-4312 ITEM NO : BE-4312 Printed in Vietnam REVISED MAR 18, 2015 - 1 -...
- Page 2 Remove all wrapping material, including staples & packing straps before you start to assemble. DO NOT tighten all screws and bolts until completely assembled. Keep all hardware parts out of reach of children. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO : BE-4312 Printed in Vietnam REVISED MAR 18, 2015 - 2 -...
- Page 3 Description Sketch Description Sketch Flat washer Lock washer (6.5x13mm) (6.5x11mm) Short bolt Long bolt (M6x30mm) (M6x40mm) Allen key (4X80mm) ITEM NO : BE-4312 Printed in Vietnam REVISED MAR 18, 2015 - 3 -...
- Page 4 Attach crossbar (C) to the legs (B) with bolts (4), as shown below. Tighten with Allen key (5). STEP 2 Attach legs (B) to the seat (A) with bolts (3), and washers (2) and (1). Tighten with Allen key (5). ITEM NO : BE-4312 Printed in Vietnam REVISED MAR 18, 2015...
