- Page 1 ASSEMBLY INSTRUCTIONS Description : ENTRY BENCH Item No. : BE-150 ITEM NO.: BE-150 Printed in Vietnam REVISED JAN 18, 2017 - 1 -...
-
Page 2: Before Assembly
Protect the surface of the product with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: BE-150 Printed in Vietnam REVISED JAN 18, 2017 - 2 -... -
Page 3: Part List
Sketch Long bolt Lock washer (M6 x 30mm) (6.5 x 11mm) Flat washer Screw (6.5 x 13mm) (M4 x 15mm) Allen key (M4 x 30 x 110mm) ITEM NO.: BE-150 Printed in Vietnam REVISED JAN 18, 2017 - 3 -... - Page 4 Tighten with Allen key (5). STEP 2 Attach side panels (B) to bottom panel (D) with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (5). ITEM NO.: BE-150 Printed in Vietnam REVISED JAN 18, 2017 - 4 -...
- Page 5 Attach top (A) to the unit with bolts (1), and washers (2) and (3) as shown below .Tighten with Allen key (5). STEP 4 Attach back panel (E) to the unit with screws (4) as shown below. Tighten with a screwdriver. ITEM NO.: BE-150 Printed in Vietnam REVISED JAN 18, 2017...
