- Page 1 Taurus Series Multimedia Player T30 Specifications...
-
Page 2: Change History
First release Introduction The T30 is a new generation of multimedia player created by NovaStar for full-color LED displays. This multimedia player integrates playback and sending capabilities, allowing users to publish content and control LED displays with a computer, mobile phone, or tablet. Working with our superior cloud-based publishing and monitoring platforms, the T30 enables users to manage LED displays from an Internet-connected device anywhere, anytime. - Page 3 Taurus Series Multimedia Player T30 Specifications Connects to the control computer, a LAN or − Allows users to monitor screens from public network for content publishing and screen anywhere, anytime. control. Switching between Wi-Fi AP and Wi-Fi STA Performance −...
- Page 4 Taurus Series Multimedia Player T30 Specifications Name Description RESET 1 Reset button Press and hold this button for 5 seconds to reset the product to its factory settings. RS232 External expansion connector USB 1 USB (Type B) port Connects to the control computer for content publishing and screen control.
- Page 5 Taurus Series Multimedia Player T30 Specifications Name Description 4G module slot Indicators Name Color Status Description Staying on The power supply is working properly. Green Flashing once every 2s The T30 is functioning normally. Flashing once every second The T30 is installing the upgrade package.
-
Page 6: Specifications
Taurus Series Multimedia Player T30 Specifications Dimensions Tolerance: ± 0.3 Unit: mm If you want to make molds or trepan mounting holes, please contact NovaStar for structural drawings with higher precision. Specifications Electrical Parameters Input voltage DC 5 V~12 V... - Page 7 Taurus Series Multimedia Player T30 Specifications Packing Information Dimensions 278.0 mm × 63.0 mm × 221.0 mm 1x T30 List 1x Wi-Fi omnidirectional antenna 1x Power connector 2x IPex cables 1x Quick Start Guide System Software ...
-
Page 8: Fcc Caution
Taurus Series Multimedia Player T30 Specifications Category Codec Resolution Maximum Maximum File Format Remarks Frame Rate Bit Rate (Ideal Case) 1920×1088 pixels GOOGLE 64×64 pixels to 60fps 80Mbps WEBM, MKV 4096×2304 pixels H.263 H.263 SQCIF (128×96) 30fps 38.4Mbps 3GP, MOV, No support for H.263+... - Page 9 Taurus Series Multimedia Player T30 Specifications product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling: The final end product must be labeled in a visible area with the following “Contains FCC ID:2AG8JT60”...
- Page 10 Taurus Series Multimedia Player T30 Specifications Tant que les 1 condition ci-dessus sont remplies, des essais supplémentaires sur l'é metteur ne seront pas nécessaires. Toutefois, l'intégrateur OEM est toujours responsable des essais sur son produit final pour toutes exigences de conformité supplémentaires requis pour ce module installé.
- Page 11 Taurus Series Multimedia Player T30 Specifications Not applicable. The module is a Single module and complies with the requirement of FCC Part 15.212. Trace antenna designs Not applicable. The module has its own antenna, and doesn’t need a host’s printed board micro strip trace antenna etc.
