- Page 1 Taurus Series Multimedia Players V1.4.1 NS120100610 TB1-4G & TB1-4G (Optional 4G) Specifications...
-
Page 2: Table Of Contents
Taurus Series Multimedia Players Table of Contents TB1-4G & TB1-4G (Optional 4G) Specifications Table of Contents Table of Contents ..........................i 1 Overview ............................1 1.1 Introduction ..............................1 1.2 Application ..............................1 2 Features ............................3 2.1 Powerful Processing Capability ........................3 2.2 Comprehensive Control Plans ........................ -
Page 3: Overview
USB drive importing display 1.2 Application Taurus series products can be widely used in LED commercial display field, such as bar screen, chain store screen, advertising machine, mirror screen, retail store screen, door head screen, on board screen and the screen requiring no PC. - Page 4 Cluster screen: Use the cluster solution developed by NovaStar to realize centralized management and monitor of multiple screens. Connection Wired connection: A PC connects to Taurus through the type Ethernet cable or LAN.
-
Page 5: Features
Taurus Series Multimedia Players 2 Features TB1-4G & TB1-4G (Optional 4G) Specifications Features 2.1 Powerful Processing Capability 1.2 GHz four-core processor Support for 1080P video hardware decoding 1 GB operating memory 8 GB on-board internal storage space with 4 GB available for users 2.2 Comprehensive Control Plans... -
Page 6: Wi-Fi Ap Connection
Taurus Series Multimedia Players 2 Features TB1-4G & TB1-4G (Optional 4G) Specifications More efficient: Use the cloud service mode to process services through a uniform platform. For example, VNNOX is used to edit and publish solutions, and NovaiCare is used to centrally monitor display status. -
Page 7: Connecting To Pc Through Usb
Taurus Series Multimedia Players 2 Features TB1-4G & TB1-4G (Optional 4G) Specifications 2.5 Connecting to PC Through USB The TB1-4G and TB1-4G (Optional 4G) offer one USB Type B port allowing PC to be directly connected without requiring other operations and you can configure screens, publish solutions , etc. -
Page 8: Hardware Structure
Taurus Series Multimedia Players 3 Hardware Structure TB1-4G & TB1-4G (Optional 4G) Specifications Hardware Structure 3.1 Appearance 3.1.1 Front Panel Figure 3-1 Front panel Note: All product pictures shown in this document are for illustration purpose only. Actual product may vary. -
Page 9: Rear Panel
Taurus Series Multimedia Players 3 Hardware Structure TB1-4G & TB1-4G (Optional 4G) Specifications Name Description Flashing once every other second: The system is installing the upgrade package. Flashing once every other 0.5 second: The system is downloading data from the Internet or copying the upgrade package. -
Page 10: Dimensions
Taurus Series Multimedia Players 3 Hardware Structure TB1-4G & TB1-4G (Optional 4G) Specifications Table 3-2 Rear panel description Name Description Power input AUDIO Audio output USB 2 USB Type B port RESET Factory reset button, hold down for 5 seconds to reset to... -
Page 11: Software Structure
Taurus Series Multimedia Players 4 Software Structure TB1-4G & TB1-4G (Optional 4G) Specifications Software Structure 4.1 System Software Android operating system software Android terminal application software FPGA program Note: The third-party applications are not supported. 4.2 Configuration Software... -
Page 12: Product Specifications
Taurus Series Multimedia Players 5 Product Specifications TB1-4G & TB1-4G (Optional 4G) Specifications Product Specifications Specifications Electrical Input voltage 5 V DC Parameters Maximum power 15 W consumption Storage Space Operating memory 1 GB Internal storage space 8 GB on-board with 4 GB available for... - Page 13 Taurus Series Multimedia Players 5 Product Specifications TB1-4G & TB1-4G (Optional 4G) Specifications Wi-Fi Antenna Unit: mm 4G Antenna Unit: mm www.novastar.tech...
-
Page 14: Audio And Video Decoder Specifications
Taurus Series Multimedia Players 6 Audio and Video Decoder Specifications TB1-4G & TB1-4G (Optional 4G) Specifications Audio and Video Decoder Specifications 6.1 Image 6.1.1 Decoder Type Codec Supported Image Size Container Remarks JPEG JFIF file format 48×48 pixels~8176×8176 JPG, JPEG Not Support 1.02... -
Page 15: Audio
Taurus Series Multimedia Players 6 Audio and Video Decoder Specifications TB1-4G & TB1-4G (Optional 4G) Specifications 6.2 Audio 6.2.1 Decoder Type Codec Channel Bit rate Sampling File Format Remarks rate MPEG MPEG1/2/2.5 8kbps~320Kb 8KHZ~48 MP1, MP2, Audio Layer1/2/3 ps, CBR and... -
Page 16: Video
Taurus Series Multimedia Players 6 Audio and Video Decoder Specifications TB1-4G & TB1-4G (Optional 4G) Specifications 6.3 Video 6.3.1 Decoder Type Codec Supported Image Maximum Maximum Bit File Format Remarks Size Frame Rate Rate (Ideal Case) MPEG MPEG 48×48 30fps... -
Page 17: Encoder
Taurus Series Multimedia Players 6 Audio and Video Decoder Specifications TB1-4G & TB1-4G (Optional 4G) Specifications Type Codec Supported Image Maximum Maximum Bit File Format Remarks Size Frame Rate Rate (Ideal Case) MOTI MJPE 48×48 30fps 38.4Mbps pixels~1920×108 JPEG 8 pixels Note: Output data format is YUV420 semi-planar, and YUV400(monochrome) is also supported for H.264.
