- Page 1 Taurus Series Multimedia Players TB6 Specifications Product Version: V1.2.0 Document Number: NS120100212...
- Page 2 Xi’an NovaStar Tech Co., Ltd. Statement You are welcome to use the product of Xi’an NovaStar Tech Co., Ltd. (hereinafter referred to as NovaStar). This document is intended to help you understand and use the product. For accuracy and reliability, NovaStar may make improvements and/or changes to this document at any time and without notice.
-
Page 3: Table Of Contents
Table of Contents Table of Contents................ii 1 Safety..................1 1.1 Storage and Transport Safety........................1 1.2 Installation and Use Safety......................... 1 2 Overview..................3 2.1 Introduction..............................3 2.2 Application..............................3 3 Features..................5 3.1 Synchronization mechanism for multi-screen playing.................5 3.2 Powerful Processing Capability........................ -
Page 4: Safety
6 Specifications TB6 Specifications Safety This chapter illustrates Taurus series products safety to ensure storage, transportation, installation and usage safety of the products. Safety description is applicable to all personnel that contact or use the products. First, pay attention to following points: Read throughout the description. - Page 5 Do not maintain the products without authorization but contact NovaStar as soon as possible. Replace spare parts only with the same parts supplied by NovaStar. www.novastar.tech...
-
Page 6: Overview
Taurus series products are the second generation of multimedia players dedicated to small and media size LED full color display developed by NovaStar. TB6 of the Taurus series products (herein after referred to as “TB6”) feature following advantages, better satisfying users’ requirements: Loading capacity up to 1,300,000 pixels ... - Page 7 Cluster screen: Use the cluster solution developed by NovaStar to realize centralized management and monitor of multiple screens. Connection Wired connection: A PC connects to Taurus ...
-
Page 8: Features
Features 3.1 Synchronization mechanism for multi-screen playing The TB6 support switching on/off function of synchronous display. When synchronous display is enabled, the same content can be played on different displays synchronously if the time of different TB6 units are synchronous with one another and the same program is being played. -
Page 9: Synchronous And Asynchronous Dual-Mode
Control Plan Connecting Mode Client Terminal Related Software Program Connection via Wi-Fi Mobile phone and ViPlex Handy publishing and screen control through mobile phone Cluster remote Wi-Fi Mobile phone, Pad VNNOX program AP+Sta/wired/4G and PC ViPlex Handy publishing and ViPlex Express screen control Cluster remote Wi-Fi... -
Page 10: Wi-Fi Ap Mode
Completely cover client terminals. Mobile phone, Pad and PC can be used to log in TB6 through wireless network. Require no wiring. Display management can be managed at any time, having improvements in efficiency. TB6’s Wi-Fi AP signal strength is related to the transmit distance and environment. Users can change the Wi-Fi antenna as required. -
Page 11: Module
NovaiCare can realize remote program publishing and remote monitoring respectively through the Internet. 3.6 4G Module The TB6 supports 4G module, allowing complete covering of the internet connection. From high to low, the priority includes: Wired network Wi-Fi Sta ... -
Page 12: Hardware Structure
Hardware Structure 4.1 Appearance 4.1.1 Front Panel Figure 4.1.1.1.1.1.1 Front panel of the TB6 Note: Product images provided in this document are for reference only, and the actual products shall prevail. Table 4.1.1.1.1.1.1.1 Description of TB6 front panel Name Description Power status indicator Always on: Power input is normal. -
Page 13: Rear Panel
Name Description Same as the signal indicator status of the sending card: FPGA is operating normally. SIM CARD SIM card tray SWITCH Button switching between synchronous asynchronous modes Always on: Synchronous mode Off: Asynchronous mode 4.1.2 Rear Panel Figure 4.1.2.1.1.1.1 Rear panel of the TB6 Note: Product images provided in this document are for reference only, and the... -
Page 14: Dimensions
Name Description AUDIO OUT Audio output RESET Factory reset button Press and hold the button for 5 seconds to reset the unit to factory settings. LED OUT Output Ethernet port ON/OFF Power switch 100-240V~,50/60Hz Power input 4.2 Dimensions Unit of the dimension chart is “mm”. Ground connection is enabled for location hole (GND). -
Page 15: Software Structure
Software Structure 5.1 System Software Android operating system software Android terminal application software FPGA program Note: The third-party applications are not supported. 5.2 Related Configuration Software Table 5.2.1.1.1.1.1.1 Related configuration software Software Description ViPlex Handy Mobile phone client software of the TB6 includes Android and iOS which are mainly used for screen management, editing, and program publishing. -
Page 16: Specifications
Specifications Item Sub-Item Specifications Physical Dimensions (W x D x H) 278.5 mm x 148.5 mm x 45.0 mm specifications Weight 1352.1 g Input power supply 100 V–240 V AC Rated power consumption 15 W Storage temperature 0°C–50°C Storage humidity 0% RH–80% RH Operating temperature -40°C–80°C... - Page 17 Support Gigabit wired network. Support stereo audio output. Support HDMI Loop. Support HDMI input mode. Support HDMI input full-screen self-adaptive display. Support manual and timing switching between synchronous and asynchronous modes. 2-Way USB Host interface supports USB drive ...
