NovaStar Taurus Series Instructions Manual
Multimedia players: how to implement synchronous playback
Hide thumbs
Also See for Taurus Series:
- Manual (28 pages) ,
- Application solution (27 pages) ,
- Application solutions (23 pages)
Related Manuals for NovaStar Taurus Series
Summary of Contents for NovaStar Taurus Series
- Page 1 Taurus Series Multimedia Players V1.6.5 Instructions on How to Implement Synchronous Playback...
-
Page 2: Table Of Contents
Taurus Series Multimedia Players Instructions on How to Implement Synchronous Playback Contents Contents ....................................i 1 Overview ..................................1 About this Document ..............................1 Requirements of Synchronous Playback ........................1 Time Synchronization ..............................1 RF Time Synchronization ............................2 Required Software ..............................2 Required Hardware .............................. -
Page 3: Overview
Feature the same playing plan without random transition or media Playing plans sent to multiple Taurus series products must be the same without random transition or media. Time Synchronization When NTP time synchronization is used, time synchronization of the Taurus series products will be performed with NTP server as the time standard in LAN or Internet. -
Page 4: Rf Time Synchronization
RF Time Synchronization When NTP time synchronization is used, master and slave devices are required to be set for Taurus series products. The time of the slave device is synchronized with that of the master device through an RF signal. -
Page 5: How To Implement Ntp Synchronization
2.1.2 Taurus Configuration Taurus series products can be configured with ViPlex only in the LAN. ViPlex includes ViPlex Handy and ViPlex Express. The user can choose one as required. 2.1.2.1 Configuration with ViPlex Handy (Android and iOS) -
Page 6: Ntp Time Synchronization In The Public Network
NTP Server Configuration. 4. Click Apply. Step 5 Repeat the above steps to configure other Taurus series products requiring synchronous playback till all Taurus series products have been configured. NTP Time Synchronization in the Public Network Configure each Taurus series product respectively when the synchronous playback and settings are enabled with ViPlex. - Page 7 4. Select an NTP server, and click OK. 5. Click Add in the Players tab of the time synchronization task attribute page. 6. Select asynchronous players corresponding to all Taurus series products requiring enabling the synchronous playback function, and click OK.
-
Page 8: How To Implement Rf Synchronization
NTP server is configured for the master devices of different RF networks and the networks are normal, large-scale time synchronization can be enabled. One Taurus series product requires one RF device. The Taurus and RF devices of E32-433T30D-NW model should be purchased before the project implementation. -
Page 9: Taurus Configuration
− Group ID: Use the same organization ID for the Taurus required enabling the time synchronization function to make such Taurus series products divide into the same RF network. − Device Type: Set the current Taurus as the master or slave device, and only one master device can exist in one organization. - Page 10 NTP server should be set. 4. Click Done after the configuration. Step 6 Repeat the above steps to configure other Taurus series products requiring synchronous playback till all Taurus series products have been configured. 3.2.2 Configuration with ViPlex Express (Windows)
- Page 11 1. Choose > Players Management > Players. 2. Select asynchronous players corresponding to all Taurus series products requiring enabling the synchronous play function which is not required for the master device. 3. Choose Real-time control > Synchronous playback > Turn on sync play.
-
Page 12: General Operations
Instructions on How to Implement Synchronous Playback General Operations The Taurus series products are designed with permanent Wi-Fi AP. This chapter introduces how to log in to the Taurus via Wi-Fi AP. Other connection methods require hardware or software configuration. Refer to Taurus Series Multimedia Players Quick Start Guide for specific operations. - Page 13 Taurus Series Multimedia Players Implementation Instruction of the Synchronous Playing Solution After detecting the Taurus, ViPlex Express will try to log in to the Taurus with the default account or the account used for the last login. : Denotes that the Taurus is online and you can log in to it. Go to Step ...
