- Page 1 HO731400TX Ranleigh Writing Desk For assistance with assembly, contact. Assembly Instructions Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seifurniturestore.com PO: 13876 Top supports up to 50 lb. Per drawer supports up to 10 lb.
- Page 2 HO731400TX Ranleigh Writing Desk Parts List Please review all parts and hardware before disposing of any packaging. Call SEI Customer Service if missing any hardware. Carefully study the diagrams below. You may receive extra hardware with your unit. 2PCS Right Side Frame...
- Page 3 Wrench Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth. call SEI customer service at 1-800-633-5096. Avoid rubbing or scratching the surface with rough or abrasive objects. Assembly Tool Required No.2 Phillips Screwdriver...
- Page 4 HO731400TX Ranleigh Writing Desk Assembly Instructions Step 1: Drawer Assembly Attach Drawer Side Boards (16) to Drawer Back Boards (15) using Screws (J). Insert Drawer Bottom Boards (17) along the grooves of Drawer Side Boards (16). Attach Drawer Front Boards (14) to Drawer Side Boards (16) using Screws (J).
- Page 5 Step 2: Attach Wood Dowels with Glue and Cam Bolts to Top Board (5) as shown. Figure 2 Step 3: Attach Left Side Panel (7), Right Side Panel (8), Right Middle Panel (9), and Left Middle Panel (10) to Top Board (5) and secure the panels with Top Board (5) using Cam Locks (E) as shown.
- Page 6 Step 5: Attach Bottom Board (6) to Left Side Panel (7), Right Side Panel (8), Right Middle Panel (9), and Left Middle Panel (10) using Screws (I). Figure 5 Step 6: Attach Support Frames (3) to Right Side Frame (1) and Left Side Frame (2) using Bolts (H).
- Page 7 Step 8: Turn the assembled unit upright. Line up the metal glides and insert the assembled Right Drawer Box and Left Drawer Box to the Desk Drawer Frames as shown. 13(L) 12(R) Figure 8 Step 9: Your Ranleigh Writing Desk assembly is now complete.
- Page 8 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
