- Page 1 TORRES DESK HO270500TX-BLACK For assistance with assembly contact: Assembly Instructions Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com PO#11906...
-
Page 2: Parts List
TORRES DESK Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below . - Page 3 Quantity of 45 COVER（￠16mm） TORRES DESK Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
-
Page 4: Phillips Screwdriver
Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth. Call Customer Service at 1-800-633-5096 Periodically apply furniture wax to renew Do not return product to store, please call the finish . Avoid rubbing or scratching the Manufacturer for assistance, questions or surface with rough or abrasive objects. - Page 5 INSERT CAM LOCKS(C) INTO PREDRILLED HOLES ON ASSEMBLED UNIT IN THE STEP 2. SCREW CAM BOLT(A) INTO PREDRILLED HOLES ON UPPER SHELF PANEL (8). ATTACH ASSEMBLED UNIT IN THE STEP 2 TO UPPER SHELF PANEL (8) BY SLIPPING WOOD DOWEL(B) & CAM BOLT(A) INTO CORRESPONDING PREDRILLED HOLES UNTIL UPPER SHELF PANEL (8)) &...
- Page 6 INSERT CAM LOCKS(C) INTO PREDRILLED HOLES ON ASSEMBLED UNIT IN THE STEP 4. SCREW CAM BOLT(A) INTO PREDRILLED HOLES ON BACK PANEL (7). ATTACH BACK PANEL (7) TO ASSEMBLED UNIT IN THE STEP 4 BY SLIPPING WOOD DOWEL(B) & CAM BOLT(A) INTO CORRESPONDING PREDRILLED HOLES UNTIL BACK PANEL (7) &...
- Page 7 UNIT & MIDDLE VERTICAL PANEL (3) MEET. SECURE BY ROTATING CAM LOCK (C) COUNTERCLOCKWISE WITH PHILLIPS SCREWDRIVER. Figure 6 INSERT CAM LOCKS(C) INTO PREDRILLED HOLES ON ASSEMBLED UNIT IN THE STEP 6. SCREW CAM BOLT(A) INTO PREDRILLED HOLES ON BACK BASE (10).
- Page 8 WITH PHILLIPS SCREWDRIVER. ATTACH LEFT SIDE PANEL (2) TO ASSEMBLED UNIT BY SLIPPING WOOD DOWEL(B) INTO CORRESPONDING PREDRILLED HOLES UNTIL LEFT SIDE PANEL(2) & ASSEMBLED UNIT MEET. USE ALLEN WRENCH (G) & HEXAGON SOCKET BOLT (D) & SPRING WASHER (E) & FLAT WASHER (F) CONNECT LEFT SIDE PANEL (2) &...
- Page 9 Figure 10 Stick covers (K) to the cam locks (C) surface. PUSH DRAWER INTO ASSEMBLED UNIT IN THE STEP 10. Figure 11 NOW YOUR NEW DESK IS READY TO USE. Figure 12...
-
Page 10: Parts Replacement Form
Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product. - Page 11 CAUTION Max weight capacity for the desk is 60 lb. Each center shelf should not be loaded with more than 20 lb. Each side shelf should not be loaded with more than 20 lb. DO NOT EXCEED RECOMMENDED LOAD. Use with products heavier than the weights indicated may result in instability causing possible injury.
