SEI Mission HO880900TX Assembly Instruction Manual

Mission computer desk-mahogany

Advertisement

Quick Links

HO8808R0TX—Mahogany finish
HO880900TX –Cherry finish
For assistance with assembly contact:
Mission Computer Desk-Mahogany
Southern Enterprises Inc.
Customer Service 1-800-633-5096
Assembly Instruction
service@seidal.com
www.seidal.com
PO#11693

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mission HO880900TX and is the answer not in the manual?

Questions and answers

Summary of Contents for SEI Mission HO880900TX

  • Page 1 HO8808R0TX—Mahogany finish HO880900TX –Cherry finish For assistance with assembly contact: Mission Computer Desk-Mahogany Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instruction service@seidal.com www.seidal.com PO#11693...
  • Page 2 HO8808R0TX—Mahogany finish / HO880900TX –Cherry finish Mission Computer Desk-Mahogany Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below.
  • Page 3 4pcs 2pcs Keypad Board Drawer Side Panel Drawer Back Panel 2pcs 3pcs 2pcs Drawer Front Panel Drawer Shelf Drawer Side Panel Drawer Back Panel Drawer Front Panel Drawer Front Panel Drawer Left Side Panel Drawer Right Side Panel Drawer Back Panel Drawer Shelf 40pcs 14pcs...
  • Page 4 5pcs 12pcs Knob Knob Bolts 5/32”x 3/4” 4pcs 3pcs Screw 1/8”x1/2” Magnet Plastic Drawer Stopper 3pcs 2pcs 32pcs Screw 1/8”x1/2” Aluminum Screw 5/32”x1” 10pcs 16pcs Wood Cap Wrench 1/4” Spring washer 1/4” 16pcs Flat washer1/4”x1/2” Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth.
  • Page 5 Mission HO8808R0TX—Mahogany finish / HO880900TX –Cherry finish Computer Desk-Mahogany Assembly Instructions Step 1: PLEASE DO NOT OVER-TIGHTEN CAMBOLTS. PLEASE STOP WHEN YOU FEEL TIGHT Attach 3pcs Plastic Drawer Stopper (9) to the Across Panel/ Front frame (H/L) with 3pcs Wood Screw (10) , Step 2: Connect the Decor Panel (F)with the left side panel(B)by...
  • Page 6 Step 3: Connect the Decor Panel (F)with the Right side panel(E)by using 1pcs wood Dowel(2) and 1pcs bolt (1), tighten by using the Wrench(14) Connect the Right /Middle side panel(D/E)with the Across Panel (H/I/J)by using 6pcs wood Dowel(2) and 6pcs bolt (1),tighten by using the Wrench(14) as shown.
  • Page 7 Step 5: Attach the unit assembled at step2/step3 to the unit assembled at step4 with16pcs bolt (1) and 16pcs Spring washer (15) 16pcs Flat washer (16) by using the Wrench(14) as shown. Step6: Connect the Decor Panel (F)with the left /Right side panel(B/E)by using 2pcs wood Dowel(2) and 2pcs bolt (1), tighten by using the Wrench(14)
  • Page 8 Connect the 1pc Right Back Panel (M1) and 1pc Left Back panel (M2) to the unit with 20pcs Wood Screw (3). Connect the Back Frame (K) with the Right/Left Partition Board (B/E) by using 2pcs Bolt (1), tighten by using the Wrench(14) Step8: Assemble the Medium drawer...
  • Page 9 Step9: Assemble the Medium drawer (P/Q/R/S) by using 8pcs Wood Screws (12). Fix the Handle (5) to the Drawer Front Panel (R) with 2pcs Bolt (6) by using the Screwdriver. Step10: Assemble the Medium drawer (T/V/U/S) by using 8pcs Wood Screws (12).
  • Page 10 Step11: Fix the Magnet (8) to the Left Partition Board (C) with 2pcs Wood Screw (3) by using the Screwdriver. Fix the Handle (4/5) to the Door/ Keypad Board (N/O) with 4pcs Bolt (6) by using the Screwdriver. Connect the Door (N) with the Left Side Panel (B) by using 4pcs Wood Screw (7), tighten the screws with screwdriver.
  • Page 11 Parts Replacement Form Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
  • Page 12 provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts. Please ask for technical assistance representative for any issues with product and assembly/construction.

This manual is also suitable for:

Mission ho8808r0tx
