Summary of Contents for Pulsar R1612T
- Page 1 R1612T v.1.0 R 12V/16x1,5A/TOPIC RACK mounted power supply for up to 16 analog cameras. EN** Edition: 1 from 28.01.2016 Supercedes the edition: ------...
- Page 2 RACK POWER www.pulsar.pl R1612T Features: • • the ALARM technical output of collective failure –relay DC 12V/16x0,87A uninterruptible power supply for powering analog cameras (Σ Ι =14A max.) type, activated by: • 230V AC power loss • the adjustment of output voltage in the range •...
- Page 3 1. Technical description. 1.1. General description. The R1612T power supply unit is designed for uninterrupted power supply of up to 16 analog cameras requiring stabilized voltage of 12V DC with the total current efficiency of 14A. The output voltage adjustment range is adjusted via a potentiometer within the range of 12V÷15V DC.
- Page 4 RACK POWER www.pulsar.pl R1612T Fig. 2. The front power of the power supply unit. Fig.3. The view of the PSU. 1.4. Specifications. - electrical parameters (tab.2) - mechanical parameters (tab.3) - operation safety (tab.4) - operating parameters (tab.5) Electrical parameters (tab. 2).
- Page 5 RACK POWER www.pulsar.pl R1612T The ALARM technical output of collective failure Relay type: 1A@ 30VDC/50VAC The F fuse in the 230V power supply circuit T 3,15A MAINS F1÷F16 fuses in the camera power supply F 1,5A circuits AUX(+) Mechanical parameters (tab. 3).
- Page 6 RACK POWER www.pulsar.pl R1612T 2.2. Installation procedure. 1. Before installation, cut off the voltage in the 230V power-supply circuit. 2. Mount the power supply in a RACK 19" cabinet as shown below: - Mount M6 cage nuts - Secure the enclosure with 4xM6 screws 3.
- Page 7 RACK POWER www.pulsar.pl R1612T 3.2. Technical output. The power supply is fitted with the ALARM output of collective failure (relay type). A collective failure can be triggered by the following events: - 230V AC mains power failure - Melting fuse activation F1÷F16 - Failure of the switch mode power supply -Too high temperature of the switch mode power supply (>70°...
- Page 8 GENERAL WARRANTY CONDITIONS 1. Pulsar (manufacturer) grants a two-year quality warranty for the equipment, starting from the production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (selected by the manufacturer) if the malfunction is due to the manufacturer.
