Pulsar RUPS1612RT Quick Start Manual

8v/12v/20a/topic rack mounted buffer power supply for up to 16 cameras and recorder.

Advertisement

Quick Links

RUPS1612RT
v.1.0
RUPS 13,8V/12V/20A/TOPIC
RACK mounted buffer power supply for up to 16 cameras and
recorder.
EN
Edition: 2 from 30.03.2017
Supercedes the edition: 1 from 15.03.2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RUPS1612RT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pulsar RUPS1612RT

  • Page 1 RUPS1612RT v.1.0 RUPS 13,8V/12V/20A/TOPIC RACK mounted buffer power supply for up to 16 cameras and recorder. Edition: 2 from 30.03.2017 Supercedes the edition: 1 from 15.03.2016...
  • Page 2 RACK POWER CCTV www.pulsar.pl RUPS1612RT Features:   LED optical indication: AC, DC, TEMP, LoB, ALARM, DC 13,8V/16x0,75A uninterruptible power supply AUX1 ÷ AUX16, DVR for powering HD cameras (12A max.)  the ALARM technical output of collective failure –relay ...
  • Page 3 1.1. General description. The RUPS1612RT buffer power supply unit is designed for uninterrupted power supply of up to 16 HD cameras requiring stabilized voltage of 12V DC (+/- 15%). The PSU has two circuits: 1x4A/12V DC for supplying the recorder and 16x0,75A/13,8V DC for both cameras.
  • Page 4 RACK POWER CCTV www.pulsar.pl RUPS1612RT LoB – red LED, indicating too low battery voltage (<11,5V) LED ALARM – red LED failure indication Green LED AUX1 ÷ AUX16 – voltage indication at the AUX outputs LED DVR – Green LED voltage indication at the DVR outputs AUX1 ÷...
  • Page 5 RACK POWER CCTV www.pulsar.pl RUPS1612RT 1.4. Specifications. - electrical parameters (tab.2) - mechanical parameters (tab.3) - operation safety (tab.4) - operating parameters (tab.5) Electrical parameters (tab. 2). 176÷264V AC Mains supply Current up to 1,3A@230V AC max. Supply power 241W max.
  • Page 6 RACK POWER CCTV www.pulsar.pl RUPS1612RT Operating parameters (tab.5). Environmental class Operating temperature -10ºC...+45ºC Storage temperature -20ºC...+60ºC Relative humidity 20%...90%, without condensation Vibrations during operation unacceptable Impulse waves during operation unacceptable Direct insulation unacceptable Vibrations and impulse waves during transport According to PN-83/T-42106 2.
  • Page 7 RACK POWER CCTV www.pulsar.pl RUPS1612RT 3. Operating status indication. 3.1. LED indication. The PSU has 22 LED lights at the front panel: GREEN LED:  on – the PSU is supplied with 230V AC  off – no 230V AC supply GREEN LED: ...
  • Page 8 RACK POWER CCTV www.pulsar.pl RUPS1612RT 3.3. Acoustic indication. A collective failure is indicated by the piezoelectric indicator, 1 beep every second. The acoustic indication can be turned off by changing the ON / OFF position of the switch switch in the up position, indication ON switch in the down position, indication OFF 4.
