- Page 1 2450 Carriage Fogger SERIAL NO. When ordering parts or when consulting the Terex Bid-Well Service Department ALWAYS KNOW your MACHINE SERIAL NUMBER CANTON, SD 57013 TEL: 605-987-2603 • FAX: 605-987-2605 2450 CARRIAGE FOGGER (1/2012) PAGE 1.1...
-
Page 2: Warranty
Terex Bid-Well but are warranted by the engine manufacturer. See the engine Owner’s Manual. Terex Bid-Well shall have no liability for loss of use or for any incidental or consequential damages, such as, but not limited to, loss of profits, loss of use of other equipment, improper... -
Page 3: Operator Qualification
6. Understand the operating procedures as outlined do not fully understand. If you require any additional by the manufacturer. information or service do not hesitate to call the Terex Bid-Well Service Department. (Tel: 605-987-2603 - Fax: OPERATOR CONDUCT 605-987-2605) 1. -
Page 4: Safety Alert Symbol
YOU are responsible for the safe operation and main- clamps or cements. The hydraulic system operates tenance of your Terex Bid-Well Paver. You must ensure under extremely high pressure and such repairs that you and anyone else who is going to operate, main- could cause serious injury. -
Page 5: Transport Precautions
4. Obtain Safety Decals or signs from the Terex Bid- for any damage. Use ropes tied to the ends of the Well Parts and Service Department. - Page 6 Terex Bid-Well LOW PRESSURE CARRIAGE FOGGER SYSTEM PURPOSE OF CARRIAGE FOGGING SYSTEM The Terex Bid-Well low pressure carriage fogging system provides a means to add humidity and lower temperatures to the surface of concrete and/or the surrounding area. The fog helps to eliminate shrinkage cracks due to abnormal surface drying or dehydration. (Works exceptionally well with flyash, silica fume additives and overlays).
- Page 7 © 2010 Terex Corporation All Rights Reserved Terex® is a registered trademark of Terex Corporation in the United States of America and many other countries. Products and services listed may be trademarks, service marks, or trade names of Terex Corporation and/or its subsidiaries in the United States of America and other countries, and all rights are reserved.
- Page 8 ITEM PART NUMBER QTY DESCRIPTION 122290 2450 SINGLE CARRIAGE FOGGER 2010 105506 CARRIAGE FOGGER FRAME 101222 MOUNTING CLIP 41-60632 BOLT, 1/2-13 UNC X 4 41-11008 LOCKWASHER, 1/2 41-22008 HEX NUT, 1/2-13 UNC 117257 PUMP MOUNTING PLATE 41-60408 BOLT, 3/8-16 UNC X 1 41-10006 FLAT WASHER, 3/8 41-11006 LOCKWASHER, 3/8 41-22006...
- Page 9 2450 CARRIAGE FOGGER (1/2012) PAGE 1.9...
- Page 10 ITEM PART NUMBER QTY DESCRIPTION 122290 2450 SINGLE CARRIAGE FOGGER 2010 111216 50 GALLON POLY TANK RF-15018 HOLDING STRAP 41-10006 FLAT WASHER, 3/8 (NOT SHOWN) 41-24006 LOCK NUT, 3/8-16 UNC (NOT SHOWN) 11-46479 BUNG, 3/4 PVC PLASTIC 11-77404 GALV NIPPLE, 3/4 X 2 11-76404 90 DEGREE GALV ELBOW, 3/4 31-57214 BRASS BALL VALVE, 3/4 11-40014...
- Page 11 50 GALLON POLY TANK HOSE REEL 2450 CARRIAGE FOGGER (1/2012) PAGE 1.11...
- Page 12 ITEM PART NUMBER QTY DESCRIPTION 122290 2450 SINGLE CARRIAGE FOGGER 2010 31-19944 HYPRO TWIN PISTON PUMP ASSEMBLY 11-20810 STRAIGHT ADAPTER, 8MJ-10MB 110602 HOSE ASSY, 1/2 X 18 11-55533 QUICK DISCONNECT, FEMALE, 1/2 11-55501 QUICK DISCONNECT, DUST PLUG 11-55535 QUICK DISCONNECT, MALE, 1/2 11-55506 QUICK DISCONNECT DUST CAP 107701 HOSE ASSY, 1/2 x 576 11-20803...
- Page 13 PUMP TO MANIFOLD TO HYD TANK CONTROL VALVE FOGGER PUMP ON/OFF VALVE 2450 CARRIAGE FOGGER (1/2012) PAGE 1.13...
- Page 14 ITEM PART NUMBER QTY DESCRIPTION 122290 2450 SINGLE CARRIAGE FOGGER 2010 28-00305 HOSE CLAMP 11-50041 1/4 MP X 3/8 BRASS HOSE BARB 31-57206 BALL VALVE, 1/4 FEMALE NPT 11-55490 BRASS MALE PLUG 1/4 NPT 11-55491 BRASS SOC. FEMALE 1/4 NPT 11-77100 NIPPLE, 1/4 NPT CLOSE 116768 DISCONNECT PLATE 11-55480...
- Page 15 SINGLE FOGGER FROM TANK DRAG PAN DRAG PAN BURLAP DRAG BURLAP DRAG 2450 CARRIAGE FOGGER (1/2012) PAGE 1.15...
- Page 16 ITEM PART NUMBER QTY DESCRIPTION 122290 2450 SINGLE CARRIAGE FOGGER 2010 105718 FOGGER BAR MOUNTING BRACKET 105659 FOGGER BAR BRACKET MOUNT 41-60410 BOLT, 3/8-16 UNC X 1-1/4 41-11006 LOCKWASHER, 3/8 41-22006 HEX NUT, 3/8-16 UNC 41-60408 BOLT, 3/8-16 UNC X 1 41-11006 LOCKWASHER, 3/8 41-22006 HEX NUT, 3/8-16 UNC 105660 SPRAY BAR PIPE, 4 FT, 3-HOLE...
- Page 17 2450 CARRIAGE FOGGER (1/2012) PAGE 1.17...
- Page 18 PAGE 1.18 2450 CARRIAGE FOGGER (1/2012)
- Page 19 2450 CARRIAGE FOGGER (1/2012) PAGE 1.19...
- Page 20 PAGE 1.20 2450 CARRIAGE FOGGER (1/2012)
- Page 21 2450 CARRIAGE FOGGER (1/2012) PAGE 1.21...
- Page 22 NOTES...
