- Page 1 Quick Start Guide Version B - November 2021 www.logtagrecorders.com...
-
Page 2: Table Of Contents
Quick Start Guide Contents What’s included Battery Installation Downloading LogTag Analyzer Confi guring your UTREL30-16 Starting your UTREL30-16 During Recording Downloading Results... -
Page 3: What's Included
What’s included Please check you have each of the items shown below before continuing with setting up your UTREL30-16. AC Adapter (Not included) USB Cable UTREL30-16 ST10 External Wall mount 2x AAA Battery Probe (Not included) (Not included) (Not included) -
Page 4: Battery Installation
A USB cable is another power backup source if you wish to power the unit permanently via the USB socket. 1. You will need a small phillips (cross-shaped) screwdriver to remove the cover on the back of the UTREL30-16 case. Page 4... - Page 5 3. Once both batteries are securely installed, replace the battery cover and secure via the screw you used to open the cover. Warning: Please note the UTREL30-16 will not start if AAA batteries are low and there is no USB power. Page 5...
-
Page 6: Downloading Logtag Analyzer
Downloading LogTag Analyzer To download the latest LogTag Analyzer, open your browser and navigate to: https://logtagrecorders.com/software/LTA3/ 1. Click ‘Go To Downloads Page’ button 2. Click ‘Download Now’ to start the download 3. Click ‘Run’ or ‘Save File’ then double-click the downloaded file to open Analyzer Setup Wizard 4. -
Page 7: Confi Guring Your Utrel30-16
1. Open LogTag Analyzer. 2. Click ‘Configure’ from the ‘LogTag’ menu or click the ‘Wizard’ icon. 3. Adjust your logger configuration settings as required. For more information on configuration... -
Page 8: Starting Your Utrel30-16
Starting your UTREL30-16 Before starting, please ensure you have connected Before starting, please ensure you have connected the ST10X external probe(s) into the correct Channel the ST10X external probe(s) into the correct Channel sensor port(s) you have configured to record from. - Page 9 Starting your UTREL30-16 (continued...) • You keep holding the button for more than 2 seconds after READY disappears. • The backup battery is critically low and the logger is not connected to power. Press the CHANNEL button to change the channel on screen.
-
Page 10: During Recording
During Recording To view more information about clearing alarms and resetting and reviewing trip statistics, please refer to Product User Guide. E n d o f p a g e Page 10... -
Page 11: Downloading Results
Alternatively, you can follow the steps below: 1. Open LogTag Analyzer 2. Click ‘LogTag’ from the ‘Download’ menu or press ‘F4’ 3. Click ‘Close’ to exit the download page By default, auto-download is enabled in LogTag Analyzer so when you open the program, data results will be...
