- Page 1 °C Quickstart Guide Version A www.logtag-recorders.com...
-
Page 2: Table Of Contents
Quickstart Guide Contents What’s Included Downloading LogTag Analyzer Confi guring your USRID-16 Starting your USRID-16 During Recording Downloading Results... -
Page 3: What's Included
What’s Included Please check you have the item shown below before continuing with setting up your USRID-16. °C USRID-16 Page 3... -
Page 4: Downloading Logtag Analyzer
Downloading LogTag Analyzer To download the latest LogTag Analyzer, open your browser and navigate to: https://www.cik-solutions.com/datenlogger-monitoringsysteme/logtag-support/ 1. Click ‘Go to downloads page’ to take you to the download page. 2. Click ‘Download Now’ to start the download. You can fill in your details beneath and click ‘subscribe’ if you wish to receive email updates from us. - Page 5 Downloading LogTag Analyzer continued... 4. Follow the on-screen prompts to install LogTag Analyzer. 5. Click ‘Finish’ to exit the LogTag Analyzer Setup Wizard. Note: If you already have the LogTag Analyzer installed, please see whether you need to update to the latest version by clicking ‘Check Internet for updates’...
-
Page 6: Confi Guring Your Usrid-16
1. Open LogTag Analyzer. 2. Click ‘Configure’ from the ‘LogTag’ menu or click the ‘Wizard’ icon. 3. Adjust your logger configuration settings as required. For more information on configuration settings, please refer to Configuring USRID-16 in the Product User Guide or press ‘F1’... -
Page 7: Starting Your Usrid-16
Battery Low °C Symbol °F READY Above/Below Threshold Arrows Recording Temperature Temperature Indicators units Press and hold the START/MARK button. REC symbol will appear. READY Release the button once REC stops flashing. The USRID-16 now records temperature data. °C Page 7... -
Page 8: During Recording
During Recording To view more information about clearing alarms and reviewing Min/Max trip temperatures, please refer to Product User Guide. • E N D O F P A G E Page 8... -
Page 9: Downloading Results
2. Click ‘Download’ from the ‘LogTag’ menu or press F4. 3. Click ‘Close’ to exit the download page. By default, auto-download is enabled in LogTag Analyzer so when you open the program, data results will be displayed after connecting your USRID-16 to the computer. Page 9...
