- Page 1 MS986500TX “Dynasty” TV/Media Stand Espresso Finishing For assistance with assembly contact: Assembly Instructions Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
- Page 2 “Dynasty” TV/Media Stand Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Hardware shown actual size. Using hardware that is too long will cause damage. Before beginning assembly, separate each type of hardware.
- Page 3 “Dynasty” TV/Media Stand Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Hardware shown actual size. Using hardware that is too long will cause damage. Before beginning assembly, separate each type of hardware.
- Page 4 “Dynasty” TV/Media Stand Assembly Instructions Assembly Instructions: Wood may scratch easily. Be careful when assembling. Do not scratch. Step 1. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated on the front page. Step 2.
- Page 5 “Dynasty” TV/Media Stand Assembly Instructions Step 1. Insert the Wood Dowels(1) into predrilled holes in Bottom Panel(F) and Middle Panels(B,C) as pictured. Step 2. Attach the Bottom Panel(F) to the Right Side Panel(E) and Middle Panels(B,C). Quantity of 6 8mm x 30 mm Figure 3 Wood Dowel Step 1.
- Page 6 “Dynasty” TV/Media Stand Assembly Instructions Step 1. Put the Washer(6) into Allen Bolt (7), attach the Legs(H) into corner block with Allen Bolt (7) by Allen Wrench(8), Then fasten them. Quantity of 8 Washer Quantity of 8 1/4” x 1-1/2” Allen Bolt Quantity of 1 Figure 6...
- Page 7 “Dynasty” TV/Media Stand Assembly Instructions Step 1. Attach Left Middle Door(L) to Left Middle Panel(B) with Screw For Door(10), then fasten them. Step 2. Attach Right Middle Door(M) to Right Middle Panel(C) with Screw For Door(10), then fasten them. Step 3. Attach Handle(11) to Doors(L,M) with Bolt For Handle(12).
- Page 8 9 months. If this product has not been purchased from our retail affiliates (within 9 months), we are under no obligation to provide parts or replacement merchandise. Parts will not be available for items arriving fully assembled. Parts will be sent if available from SEI.
- Page 9 This unit contains a permanent warning sticker located on under side of top shelf or inside drawer. Do not allow children under 16 years to move the cart. Model: MS986500TX “Dynasty” TV/Media Stand Southern Enterprises, Inc 1970 Crown Drive...
