  • Page 1 XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved ® ® Carrier ©2022 · Catalog No. 11-808-826-01 · 1/11/2022...
  • Page 2 Verify that you have the most current version of this document from www.hvacpartners.com, the Carrier Partner Community website, or your local Carrier office. Important changes are listed in Document revision history at the end of this document. Carrier ©2022. All rights reserved.

  • Page 3: Table Of Contents

    Contents What is the i-Vu® XT Router? ............................. 1 Specifications ................................ 2 To mount the i-Vu® XT Router ............................ 5 Wiring for power ................................7 To wire for power ..............................7 Connecting to the router through the Service Port ....................8 Connecting to the router through the Gig-E Port .......................

  • Page 4: What Is The I-Vu® Xt Router

    Supports DHCP IP addressing • Can serve as a BACnet Broadcast Management Device (BBMD) • Supports Foreign Device Registration (FDR) • Works with the i-Vu® v8.0 or later system i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 5: Specifications

    90 seconds, and when the firmware is deliberately restarted. Real-time clock Real-time clock keeps track of time in the event of a power failure for up to 3 days. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...
  • Page 6 1 lb. 1 oz. (0.482 kg) BACnet Support Conforms to the BACnet Router (B-R-TR) Standard Device Profile as defined in ANSI/ASHRAE Standard 135-2012 (BACnet) Annex L, Protocol Revision 14 i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...
  • Page 7 EN50491-5-2:2009; Part 5-2: EMC requirements for HBES/BACS used in residential, commercial and light industry environment RoHS Compliant: 2015/863/EU REACH Compliant Australia and New Zealand: C-Tick Mark, AS/NZS 61000-6-3 i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 8: To Mount The I-Vu® Xt Router

    Place the router on the DIN rail so that the rail is in the trough on the back of the router. Push the center tabs towards the router until you hear them click. Pull gently on the router to verify that it is locked in place. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...
  • Page 9 Insert #6 screws through the mounting holes. Use no more than 8 in.lbs. torque to secure plastic tab to mounting surface. 7.1 in. (18.03 cm) 6.95 in. (17.65 cm) 6.45 in. (16.38 cm) 4.1 in. (10.4 cm) Depth: 2.09 in (5.31 cm) i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 10: Wiring For Power

    The i-Vu® XT Router is powered by a Class 2 power source. Take appropriate isolation measures when mounting it in a control panel where non-Class 2 circuits are present. • Carrier® controllers can share a power supply as long as you: • Maintain the same polarity.

  • Page 11: Connecting To The Router Through The Service Port

    Service Port, be sure to upload the changes to the system database. This will preserve those settings when you download memory or parameters to the router. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 12: Connecting To The Router Through The Gig-E Port

    Service Port, be sure to upload the changes to the system database. This will preserve those settings when you download memory or parameters to the router. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 13: Addressing The I-Vu® Xt Router

    If it uses a DHCP address, leave the address as it is. Open a web browser on the computer. Navigate to http://local.access or http://169.254.1.1 to see the Service Port controller setup pages. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 14: To Set The Ip Address

    On the Connections page, under the Gig-E Port tab > Primary BACnet/IP, select Custom Static in the drop- down list for Address Mode. Enter the IP Address, Subnet Mask, and Default Gateway addresses that the network administrator gave you. Click i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...
  • Page 15 Content. See the i-Vu® Help for more information. NOTE The default address is an intranet address. Data packets from this address are not routable to the Internet. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 16: To Set An Ipv6 Address

    On the Connections page, under the Gig-E Port tab > BACnet/IPv6, select Custom Static in the drop-down list for Address Mode. Enter the IP Address, Prefix Length, and Default Gateway addresses that the network administrator gave you. Click i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...
  • Page 17 You will then need to correct the IP address in SiteBuilder. NOTE The default address is an intranet address. Data packets from this address are not routable to the Internet. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 18: To Set The Port S1 Address And Baud Rate

    0 to 127. Select the MSTP Baud Rate. The default is 76,800 bps. NOTE Enter the same baud rate for all devices on the MS/TP network. Click i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 19: Wiring For Communications

    2000 feet (610 meters) shielded copper wire * See the Open Controller Network Wiring Guide. WARNING Do not apply line voltage (mains voltage) to the router's ports and terminals. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 20: To Connect The I-Vu® Xt Router To The Ethernet

    To verify communication with the network, get a Module Status report in the i-Vu® interface for a router on the ARCNET network. NOTE This step requires that you have discovered and uploaded the router in the i-Vu® application. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 21: To Wire To A Bacnet Ms/Tp Network

    To verify communication with the network, get a Module Status report in the i-Vu® interface for a router on the MS/TP network. NOTE This step requires that you have discovered and uploaded the router in the i-Vu® application. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 22: Find And Upload In The I-Vu® Interface

    If you change any of the above items or the i-Vu® XT Router's address after the initial download, you must download again. The first download takes longer than subsequent downloads. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 23: Adjusting Driver Properties And Controller Setup Through The Service Port Or The I-Vu® Interface

    The Device > Home Network tab is autopopulated based on what is set for the home network. Refer to the Network Parameters listed in the appropriate section based on the home network you selected. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...
  • Page 24 How many milliseconds the device will wait before resending a message segment if no response is received. Number of APDU Retries The number of times the device will resend a message. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 25: Gig-E Port Using Bacnet/Ipv4

    If the i-Vu® XT Router has two BACnet/IP networks communicating on the Gig-E port, confirm that the home network interface has the port number set to what the i-Vu® application will use for BACnet communication. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...
  • Page 26 BACnet Broadcast Management Devices (BBMDs)" in SiteBuilder or i-Vu® Help. • Export BBMD—Export the BBMD table that is in the controller to use for storage, viewing, or troubleshooting. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 27: Gig-E Port Using Bacnet/Ipv6 Or Bacnet/Ethernet

    To add a server, click Add and then enter the Name Server Address field below. • To delete a server in the table, select it in the list and click Delete. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 28: Bacnet/Sc Port Tab

    BACnet/SC network. Connection State The status of the router’s connection as a client on the BACnet/SC network. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...
  • Page 29 See "To create or replace a BACnet/SC device’s operational certificate" in the BACnet/SC Setup Guide for instructions on how to create the router’s operational certificate, signed by the BACnet/SC network’s Certificate Authority. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 30: Port S1 And Port S2

    You set the address for Port S1, which must be unique for the system. End of Network Indicates status of the router's End of Net? switch. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...
  • Page 31 Baud Rate Set this to a baud rate that all other devices on the MS/TP network are set to. Select 9600, 19200, 38400, 57600, 76800, or 115200. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 32: Advanced Tabs

    Lists of Ipv6 ranges that can be used in whitelisting Whitelist Enable Custom Range Check to enable. Whitelist Address Ranges Click Add to enter information or Delete to remove existing information. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 33: Alarms Tab

    If a certificate is within this number of days of expiring, it will appear red in the Certificate Management table. A daily alarm will be triggered in the i-Vu® application when one of the router’s BACnet/SC certificates is in this state. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 34: Notification Class Tab

    To Time Process Identifier Change for third-party devices that use a BACnet Process Identifier other than 1. The i-Vu® application processes alarms for any 32-bit Process Identifier. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...
  • Page 35 The instance number of this BACnet device. Object Name An alpha-numeric string that is unique within the BACnet device. Description The description of this BACnet device. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 36: Controller Clock Tab

    To define third-party BACnet devices as Time Synchronization Recipients: Recipients Click Add. Select Recipient Type: Device ID Address Local Broadcaster Global Broadcaster Enter the Recipient Device information. Click Accept. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 37: Color Cache Tab

    Download log files Capture network communication on the BACnet/SC ports and then download the capture file for troubleshooting Access additional diagnostic tools with assistance from Carrier Controls System Support Logs • Retrieve all - Downloads all logs into a zip onto your computer •...

  • Page 38: Network Tab

    Set a password if required to authenticate on the proxy server. No Proxy For Set addresses that do not require passing through the proxy to communicate. These addresses are typically exempt from the proxy requirements. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 39: Troubleshooting

    Troubleshooting If you have problems mounting, wiring, or addressing the i-Vu® XT Router, contact Carrier Controls System Support. LEDs NET (Network Status) Tricolor LED Color Pattern Condition Message in Module Possible Solutions Status • Connect Ethernet Cable Ethernet connection problem No Ethernet Link •...
  • Page 40 (change of values) • Increase the time between COVs to reduce excessive COV traffic All enabled networks are functioning No errors No action required Green properly i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 41: To Get A Module Status Report

    • In the controller setup interface through the Service Port—Click and select Modstat from the drop-down list. See Appendix - Module Status field descriptions (page 43). i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 42: To Get A Device Log

    To get a Device Log If Carrier Controls System Support instructs you to get the router's Device Log containing diagnostic information for troubleshooting: Select the i-Vu® XT Router in the i-Vu® navigation tree. On the Properties page, click Device Log.
  • Page 43 Replace the router's cover. Replace the power connector. Turn on the router's power switch. 10 Verify that the LED on top of the router is on. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 44: To Take The I-Vu® Xt Router Out Of Service

    Confirm that there are no firewalls blocking access to the BACnet/SC Hub. If necessary, set up a Proxy on the Advanced tabs > Network tab to reach the BACnet/SC Hub. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...

  • Page 45: Compliance

    CAUTION Any modifications made to this device that are not approved by Carrier® will void the authority granted to the user by the FCC to operate this equipment.

  • Page 46: Appendix - Module Status Field Descriptions

    BACnet/SC Information BACnet/SC connection status as of when the Modstat was run. Also shows the web addresses used to access the primary and/or failover hubs. i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...
  • Page 47 BACnet routers are added or removed from the system. Core and Base board hardware Gives the following information about the router's boards: • Type and board numbers that are used internally by Carrier®. • The manufacture date and serial number. System status Gives the current status of the router's operation.

  • Page 48: Document Revision History

    Important changes to this document are listed below. Minor changes such as typographical or formatting errors are not listed. Date Topic Change description Code* 1/11/22 Specifications Updated EU Compliance X-PM-BM-E BACnet/SC Port tab Added note X-PM-LO-O * For internal use only i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022 Installation and Start-up Guide All rights reserved...
  • Page 50 Carrier ©2022 · Catalog No. 11-808-826-01 · 1/11/2022...
