Contents What is the XT-RB? ..............................1 Critical Product Announcement ......................... 2 Specifications ................................ 2 To mount the XT-RB ..............................5 Wiring for power ................................7 To wire for power ..............................7 Connecting to the router through the Service Port ....................8 Connecting to the router through the Gig-E Port .....................
Page 4
Contents CE and UKCA Compliance ..........................47 Industry Canada Compliance ........................... 47 BACnet Compliance............................47 Appendix - Module Status field descriptions ......................48 Document revision history ............................51...
Page 7
Ethernet port at 10 or 100 Mbps for setting up the controller and troubleshooting through a local connection to a computer. USB port USB 2.0 host port for device recovery and connecting the Carrier® wireless service adapter. Microprocessor 32-bit ARM Cortex-A8, 600MHz, processor with multi-level cache memory Memory 8 GBs eMMC Flash memory and 512 MB DDR3 DRAM (22 MB available to use).
The XT-RB is powered by a Class 2 power source. Take appropriate isolation measures when mounting it in a control panel where non-Class 2 circuits are present. • Carrier® controllers can share a power supply as long as you: • Maintain the same polarity.
Open your computer's wireless network display to view your available wireless networks. NOTE The XT-RB only supports the 5 GHz band and not the 2.4 GHz band. Connect to the wireless network using the network SSID and password that are printed on the Carrier® wireless service adapter.
The driver must be in <system_name>\drivers. The exact location of the system directory depends on where you have saved it. It is typically under i-Vu Prox.x\programdata\systems. • To verify that you have the driver's latest version, go to the Carrier® Partner Community website and compare the latest version to the XT-RB's driver in SiteBuilder. •...
Technical Support Tools Enable the toggle switch to view the Challenge key. Send the displayed Challenge key to the Carrier Controls System Support representative who will provide an Activation Key for you to enter. Additional tools will be displayed to help Carrier Controls System Support troubleshoot issues.
NOTE Capture files have a 25MB limit. If you need a larger capture, contact Carrier Controls System Support. Contact Carrier Controls System Support for assistance with using packet captures. Network Diagnostics Click Reset statistics to reset values to 0, which then resume accumulating.
NOTE Selecting this checkbox also disables Dead Controller Timeout alarms. Dead Controller Timeout After this period (minutes:seconds) of non-response from a peer Carrier® controller, the router sends an alarm to the server as defined by the Dead Controller Timeout alarm configuration.
See Appendix - Module Status field descriptions (page 48). To get a Device Log If Carrier Controls System Support instructs you to get the router's Device Log containing diagnostic information for troubleshooting: Select the XT-RB in the i-Vu® navigation tree.
CAUTION Any modifications made to this device that are not approved by Carrier® will void the authority granted to the user by the FCC to operate this equipment.
Page 53
Rx Error Count—All errors related to received packets such as CRC errors, FIFO errors, frame errors, length errors, missed errors, and overrun errors. Tx Error Count—All errors related to transmitted packets such as aborted errors, carrier errors, dropped errors, FIFO errors, heartbeat errors, and window errors. Dropped Packets—Packets dropped by the XT-RB.
