Features

SW8/12 VGA Ars switcher features include:
• 8 or 12 video inputs with 15-pin HD connectors
• 8 or 12 3.5 mm stereo mini jacks for audio
• Two 15-pin HD output connectors for video
• Two captive screw output connectors for audio
• Compatible with VGA-QXGA and HDTV component video signals
• 350 MHz (-3 dB) RGB video bandwidth
• Automatically detects which inputs have an active signal and reports this
information through the RS-232 port
• Balanced / unbalanced audio outputs
• Variable / fixed audio outputs
• Autoswitching capabilities
• Executive mode (front panel lockout)
• Multiple control options — front panel, autoswitch, RS-232, IR via IR 102
• VSW I AAP compatibility
• Internal international power supply
• Multiple mounting options — rack, under desk, through desk, tabletop
SW8/12 VGA Ars • Introduction 1-3
