Installation, Operation, and
Maintenance Instructions
3501

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Goulds Pumps 3501 and is the answer not in the manual?

Questions and answers

Related Manuals for ITT Goulds Pumps 3501

Summary of Contents for ITT Goulds Pumps 3501

  • Page 1 Installation, Operation, and Maintenance Instructions 3501...

  • Page 3: Table Of Contents

    Table of Contents Table of Contents 1 Safety.................................. 4 1.1 Important Safety Notice..........................4 1.2 Safety Warnings ............................4 1.3 Safety ................................ 5 1.4 General precautions ..........................5 1.5 Parts ................................8 2 General Information ............................9 2.1 Mixer description ............................9 2.2 Nameplate information ..........................
  • Page 4 Table of Contents 4.5.3 Operating under freezing conditions ..................... 27 4.6 Shutdown ..............................27 4.7 Final alignment ............................27 4.8 Interlocks ..............................28 5 Preventative Maintenance ..........................29 5.1 General comments ..........................29 5.2 Maintenance schedule ..........................29 5.3 Maintenance of bearings ......................... 29 5.3.1 Oil lubricated bearings ........................
  • Page 5 ITT - Goulds Pumps shall not be liable for physical injury, damage or delays caused by a failure to ob- serve the instructions for Installation, Operation, and Maintenance contained in this manual.

  • Page 6: Safety

    ITT Goulds pumps will provide safe, trouble-free service when properly installed, maintained, and operat- Safe installation, operation, and maintenance of ITT Goulds Pumps equipment are an essential end user responsibility. This Pump Safety Manual identifies specific safety risks that must be considered at all times during product life.

  • Page 7: Safety

    Trapped liquid can rapidly expand and result in a violent explosion and injury. ITT Goulds Pumps will not accept responsibility for physical injury, damage, or delays caused by a failure to observe the instructions for installation, operation, and maintenance contained in this Pump Safety Manual or the current IOM available at http://www.gouldspumps.com/literature.
  • Page 8 WARNING NEVER operate pump with discharge valve closed. WARNING NEVER operate pump with suction valve closed. WARNING DO NOT change service application without approval of an authorized ITT Goulds Pumps representative. WARNING Safety Apparel: • Insulated work gloves when handling hot bearings or using bearing heater •...
  • Page 9 1.4 General precautions When installing in a potentially explosive environment, please ensure that the motor is properly certified. WARNING Operating pump in reverse rotation may result in contact of metal parts, heat generation, and breach of containment. WARNING Lock out driver power to prevent accidental start-up and physical injury. WARNING The impeller clearance setting procedure must be followed.

  • Page 10: Parts

    1.5 Parts The use of genuine Goulds parts will provide the safest and most reliable operation of your pump. ITT Goulds Pumps ISO certifica- tion and quality control procedures ensure the parts are manufac- tured to the highest quality and safety levels.

  • Page 11: General Information

    2 General Information 2 General Information 2.1 Mixer description Casing - Casings are side suction, side discharge, back pull-out designs, utilizing a spacer coupling to allow for one craft maintenance. The alignment fit is protected from the pumpage with a confined gasket between the casing and the seal chamber cover.

  • Page 12: Receiving The Mixer

    2.3 Receiving the mixer Figure 1: Mixer casing tag - English Figure 2: Mixer casing tag - metric Figure 3: Bearing frame tag 2.3 Receiving the mixer Inspect the mixer as soon as it is received. Carefully check that everything is in good order. Make notes of damaged or missing items on the receipt and freight bill.

  • Page 13: Handling

    2.3 Receiving the mixer Long Term: (More than 6 months): Requires special precautions. Preservative treatment of bearings and machined surfaces will be re- quired. Rotate shaft several times every 3 months. Driver and coupling manufacturers should be contact- ed for long term storage procedures. NOTICE: For pumps or back pull-outs supplied with cartridge mechanical seals, the centering tabs must be in place and tightened, and the set screw collar loosened.
  • Page 14 2.3 Receiving the mixer Figure 5: Baseplate mounted Figure 6: Baseplate and driver 3501 Installation, Operation, and Maintenance Instructions...

  • Page 15: Installation

    3 Installation 3 Installation 3.1 Site / foundation A mixer should have adequate space for operation, maintenance, and inspection. Baseplate mounted mixers are normally grouted on a concrete foundation, which has been poured on a solid footing. The foundation must be able to absorb any vibration and to form a permanent, rigid support for the mixing unit.

  • Page 16: Alignment And Alignment Procedure

    3.3 Alignment and alignment procedure Hand tighten bolts. Figure 9: Shims or wedges - side view Figure 10: Shims or wedges - top view 3.3 Alignment and alignment procedure WARNING: Before beginning any alignment procedure, make sure driver power is locked out. The points at which alignment is checked and adjusted are: •...

  • Page 17: Alignment Checks

    3.4 Set up 3.3.1 Alignment checks Initial Alignment (Cold Alignment) • Before Grouting Baseplate - To ensure alignment can be obtained • After Grouting Baseplate - To ensure no changes have occurred during grouting process • After Connecting Piping - To ensure pipe strains haven’t altered alignment. If changes have occur- red, alter piping to remove pipe strains on mixer flanges Final Alignment (Hot Alignment) After First Run - To obtain correct alignment when both mixer and driver are at operating temperature.

  • Page 18: Measurement

    3.5 Measurement Check setting of indicators by rotating coupling half X to ensure indicators stay in contact with cou- pling half Y but do not bottom out. Adjust indicators accordingly. 3.5 Measurement To ensure accuracy of indicator readings, always rotate both coupling halves together so indicators contact the same point on coupling half Y.

  • Page 19: Parallel Alignment

    3.5 Measurement Negative Reading - The coupling halves are further apart on the right side than the left. Correct by either sliding the shaft end of the driver to the left or the other end to the right. Positive Reading - The coupling halves are closer together on the right side than the left. Correct by either sliding the shaft end of the driver to the right or the other end to the left, shown below.

  • Page 20: Complete Alignment

    3.5 Measurement NOTICE: Equal amounts of shims must be added to or removed from each driver foot. Otherwise the vertical angular alignment will be affected. Repeat steps 1 through 3 until indicator P reads within .05 mm (.002 in.) or less when hot, or per Table 2: Cold Setting of Parallel Vertical Alignment on page 15 when cold.

  • Page 21: Grout Baseplate

    3.6 Grout baseplate Make corrections as outlined previously. Recheck both vertical and horizontal readings to ensure adjustment of one did not disturb the other. Correct as necessary. NOTICE: With experience, the installer will understand the interaction between angular and parallel and will make corrections appropriately.

  • Page 22: Alignment Check

    3.7 Piping Figure 17: Allow grout to set at least 48 hours. Tighten foundation bolts. 3.6.1 Alignment check Re-check alignment before continuing, using methods previously described. 3.7 Piping 3.7.1 General WARNING: Never draw piping into place by forcing at the flanged connections of the mixer. This may im- pose dangerous strains on the unit and cause misalignment between mixer and driver.

  • Page 23: Inlet Piping

    3.8 Piping instructions 3.7.2 Inlet piping Properly installed inlet piping is a necessity for trouble-free mixer operation. Inlet piping should be flush- ed before connection to the mixer. Use of elbows close to the mixer inlet flange should be avoided. There should be a minimum of two (2) pipe diameters of straight pipe between the elbow and inlet.

  • Page 24: Gas Mixing

    3.9 Spring mounted baseplates 3.8.2 Gas mixing Pipe • Gas addition should always be added in the chemical addition point of the chemical injection pipe supplied with the mixer. • If flow velocity is higher than 9 ft/s, special 8° increasers are required after the mixer. •...
  • Page 25 3.9 Spring mounted baseplates Figure 18: Spring mounted baseplate NOTICE: The foundation pads are supplied by the customer. They are to be 16-20 micro-inch surface finish 316 stainless steel plate. Level the baseplate while making final height adjustments. Adjust the baseplate height by loosening the top jam nut and adjusting nut.

  • Page 26: Operation

    4 Operation 4 Operation 4.1 Preparation for start-up 4.2 Check rotation CAUTION: Serious damage may result if mixer is run in the wrong rotation. Lock out power to driver. WARNING: Lock out driver power to prevent accidental start-up and physical injury. Make sure coupling hubs are securely fastened to shafts.

  • Page 27: Check Rotor Axial Clearance

    4.3 Couple mixer and driver Figure 19: Coupling guard installation WARNING: Never operate a mixer without a correctly installed coupling guard. Personal injury will occur if mixer is run without coupling guard. 4.3.1 Check rotor axial clearance The mixer efficiency is maintained when the proper rotor clearance is set. The rotor has been centered in the casing at the factory but could change due to piping attachment.

  • Page 28: Shaft Sealing

    4.4 Starting mixer Figure 20: Constant level oiler Grease Lubrication: Mixers are shipped with grease installed. Prolonged Shutdown: If the mixer is put into operation after prolonged shut-down, flush out the bearings and bearing frame with a light oil or kerosene to remove contaminants. During flushing, rotate shaft slow- ly.

  • Page 29: Operation

    4.5 Operation 4.5 Operation 4.5.1 General considerations Driver may overload if the fluid specific gravity (density) is greater than originally assumed or the rated flow rate is exceeded. Always operate the mixer at or near the rated conditions to prevent damage resulting from cavitation or recirculation.

  • Page 30: Interlocks

    4.8 Interlocks Check alignment while unit is still hot per alignment procedure outlined earlier. 4.8 Interlocks Mixer interlocks are additions to the feed pumping system interlocks and alarms and vary mill by mill. Typically, they depend upon what instruments are available. The following are the basic guidelines for interlocks.

  • Page 31: Preventative Maintenance

    5 Preventative Maintenance 5 Preventative Maintenance 5.1 General comments A routine maintenance program can extend the life of your mixer. Well maintained equipment will last lon- ger and require fewer repairs. You should keep maintenance records, this will help pinpoint potential causes of problems.
  • Page 32 5.3 Maintenance of bearings Figure 21: Oil lubricated bearings Change the oil after 200 hours for new bearings, thereafter every 2000 operating hours or 3 months (whichever comes first). Change more often if oil becomes contaminated with dirt or water. Oil change volumes are per Table below.

  • Page 33: Grease Lubricated Bearings

    5.3 Maintenance of bearings Mobil Mobil DTE 26 300 SSU @ 38°C (100°F) Gulf Gulf Harmony 68 Phillips Mangus Oil Grade 315 Phillips MM motor oil SAE 20-20W Phillips HDS motor oil SAE 20-20W If the constant level oiler option is supplied, it was adjusted before leaving the factory (Refer to Opera- tions Section for details).
  • Page 34 5.3 Maintenance of bearings Figure 22: Grease lubricated bearings Fill both grease cavities through fittings with recommended grease until fresh grease comes out of the relief holes (408C). Ensure frame seals (332A, 333B) are seated in bearing housing and, if not, press in place with drains located at the bottom.

  • Page 35: Maintenance Of Shaft Seals

    5.4 Maintenance of shaft seals Acceptable Greases: Exxon Unirex N3 SKF LGHT3 NOTICE: If these greases are used, disassemble the bearing housing, degrease the bearings and hous- ing prior to greasing. 5.4 Maintenance of shaft seals 5.4.1 Mechanical seals Separate seal manufacturer's drawings are included with the mixer data package. Seals are installed and adjusted at the factory.

  • Page 36: Dial Indicator Method

    5.6 Dial indicator method casing and the seal chamber is approximately 5 mm (0.200 in). The rotor should be centered in the cas- ing. 5.6 Dial indicator method Remove coupling guard. Set indicator so that the button contacts either the shaft end or the face of the coupling. Figure 23: Dial indicator method Loosen jam nuts (423B) on jack bolts (370D) and back bolts out about two turns.

  • Page 37: Mixer Washdown

    5.8 Mixer washdown With a set of feeler gauges, measure and record the gap between the bearing housing (134A) and the bearing frame (228). Figure 24: Feeler gauge method Back locking bolts (370C) off a couple of turns. Thread jack bolts (371A) in until they contact the bearing frame (228) evenly. Tighten the jack bolts evenly (about one flat at a time), backing the bearing housing (134A) away from the bearing frame until the rotating assembly contacts the seal chamber cover (184).
  • Page 38 5.8 Mixer washdown Table 7: Troubleshooting Problem Probable Cause Remedy Bearings run hot. Improper alignment. Re-align mixer and driver. Improper lubrication. Check lubricant for suitability and level. Lube cooling. Check cooling system. Mixer is noisy or vibrates. Improper mixer/driver alignment. Align shafts.

  • Page 39: Disassembly And Reassembly

    6 Disassembly and Reassembly 6 Disassembly and Reassembly 6.1 Required tools • Hoist and Strap • Socket Sizes (mm): 12, 14, 16, 19, 20 • Torque Wrench for reassembly Wrench Sizes (mm): 12, 16, 20 • Allen Wrenches (mm): 12, 14, 16, 19, 22 •...

  • Page 40: Disassembly

    6.3 Disassembly Figure 25: Coupling guard and coupling Either remove mixer coupling hub or move hub down shaft to bearing frame. If unit is oil lubricated, drain oil from bearing frame by removing bearing frame drain plug (408B). Replace plug after oil is drained. 6.3 Disassembly Place sling from hoist around bearing frame (228).

  • Page 41: Removal Of Rotor

    6.4 Removal of rotor 6.4 Removal of rotor Secure back pullout firmly to bench. Lock shaft (122) to prevent turning and remove rotor nut set screws (222S), rotor nut, and O-ring. Figure 27: Removal of rotor using pry bar Pry rotor (101) off shaft (182) using two bars opposite each other, placed between cover and rotor shroud.

  • Page 42: Removal Of Taperbore™ Plus Seal Chamber And Mechanical Seal

    6.5 Removal of Taperbore™ PLUS seal chamber and mechanical seal 6.5 Removal of Taperbore™ PLUS seal chamber and mechanical seal Re-engage mechanical seal setting clips. Figure 29: Mechanical seal setting clips Thread a 10 mm eye bolt into the tapped hole provided in the seal chamber (184) and sling to a hoist.

  • Page 43: Disassembly Of Bearing Frame

    6.6 Disassembly of bearing frame WARNING: Seal chambers are heavy. Use proper support to avoid personal injury. 6.6 Disassembly of bearing frame Secure bearing frame assembly firmly to a workbench. Remove coupling hub from shaft (122) by loosening set screw (if provided) and using a puller (Fig. 32).

  • Page 44: Inspections

    6.7 Inspections Figure 33: Thrust bearing housing Slide thrust bearing housing (134A) off thrust bearings (112) (Fig. 34). 10. Disengage thrust bearing lock washer (382) from locknut (136) and remove both from shaft (122) (Fig 35). Figure 34: Bearing pullers Remove bearings (112, 409) from shaft (122) using a suitable puller that only contacts inner races of bearings (Fig.

  • Page 45: Bearing Frame

    6.11 Bearing frame 6.11 Bearing frame Inspect frame and frame foot for cracks. Inspect for corrosion or pitting if frame has been exposed to the fluid. Inspect frame bearing bores per Table 7. Inspect labyrinth seal o-rings for cuts and cracks. Inspect shafts and sleeves for wear.
  • Page 46 6.12 Reassembly Item Part Name Group Construc- Goulds Part No. Thread Size Hex Torque Value tion Size See Notes1- Mixer (mm) lb-ft Nut, Impeller 316ss B02151A04 1203 M27 x 3.00 Titanium B04216A02 2156 M27 x 3.00 316ss B04168A 2229 M27 x 3.00 Titanium B04168A 2156 M27 x 3.00 316ss...

  • Page 47: Reassembly Of Bearing Frame

    6.13 Reassembly of bearing frame Item Part Name Group Construc- Goulds Part No. Thread Size Hex Torque Value tion Size See Notes1- Mixer (mm) lb-ft 423B Nut, Hex – Adjusting A02089A12 2442 M12 x 1.75 L and XL A02089A16 2442 M16 x 2.00 469Z Hex Head Cap Screw A02818A111 2441 M12 x 1.75...
  • Page 48 6.13 Reassembly of bearing frame Figure 36: Spacing ring placement NOTICE: Care must be taken to keep inner race together with roller assembly during installation. Place thrust bearing retainer ring (253B) on shaft between bearing fits with small diameter facing coupling end.
  • Page 49 6.13 Reassembly of bearing frame Figure 37: Bearing frame preparation for oil or grease lubrication • Oil Lubrication - Ensure oil return is fully open (No plug) (Fig. 38 and 39). • Grease Lubrication - Ensure plug (370E) is in- stalled in radial end oil return (Fig. 39). Figure 38: Grease lubrication plug installation NOTICE: If changing lubrication from grease to oil, remove accumulated grease from oil return after plug...
  • Page 50 6.13 Reassembly of bearing frame Figure 39: Rotating element insertion into bearing frame 16. Carefully insert rotating element into bearing frame (228). 17. Orient bearing housing (134A) properly for desired lubrication: • Oil Lubrication: Orient bearing housing so the words top oil are on top (Fig. 41). •...
  • Page 51 6.13 Reassembly of bearing frame 19. Adjust housing (134A) so there is a gap of approximately 3 mm (1/8 in.) between housing and bear- ing frame (228). 20. Lubricate O-rings on labyrinth oil seals (332A and 333A). 21. Install thrust labyrinth oil seal (332A) into bore of thrust bearing housing (134A) until shoulder seats against housing.
  • Page 52 6.13 Reassembly of bearing frame Figure 42: Grease fittings installation into bearing frame • one on top at seal chamber end. • one on left side at coupling end Install two plugs (408C) into right side of bearing frame (228), based on viewing from coupling end.

  • Page 53: Reassembly Of Taperbore™ Plus Seal Chamber And Mechanical Seal

    6.14 Reassembly of taperbore™ plus seal chamber and mechanical seal Slide finned tube through the hole on right side of frame. Install reducer bushing on right side of frame . Thread a second tube fitting (with straight bore) into reducer bushing. Center tube in frame and tighten ferrule nuts on tube fittings.

  • Page 54: Installation Of Casing Foot And Alignment Pin

    6.16 Installation of casing foot and alignment pin Figure 45: Shaft key installation Fit sleeve O-ring (412F) into groove on shaft sleeve (126). Apply a liberal coating of an anti-galling compound (Loctite Nickel Anti-seize) to mixer rotor (101) bore and shaft (122). Slide mixer rotor (101) onto shaft (122).

  • Page 55: Installation Of Back Pull-Out Assembly

    6.17 Installation of back pull-out assembly Figure 46: Transverse stationary vane Align holes in casing foot (131) with tapped holes on appropriate casing (100) foot bosses. These are normally the holes facing the baseplate. Install hex cap screws (370F) and tighten to torque value in Table 10: Model 3501 Fastener Infor- mation on page For 8"...
  • Page 56 6.17 Installation of back pull-out assembly Figure 47: Placement of sling hoist On a flat surface (baseplate or sturdy workbench), install back pull-out assembly into casing (100). Ensure casing foot (131), if supplied, and frame foot (241) are flat on the surface. Hand tighten four equally spaced casing bolts (370A).
  • Page 57 6.17 Installation of back pull-out assembly Figure 48: Coupling guard installation 18. Reconnect all auxiliary piping. NOTICE: For pumps supplied with cartridge mechanical seals, be sure the set screws in the seal locking ring have been tightened and the centering clips removed prior to startup. Failure to take these steps could result in damage to the mechanical seal or shaft sleeve.

  • Page 58: Spare Parts

    7 Spare Parts 7 Spare Parts 7.1 Recommended spare parts To ensure against possible long and costly downtime period, especially on critical services, it is advisable to have spare parts on hand. 7.1.1 Most desirable spare parts • Back Pull-out assembly, this is a group of assembled parts which includes all parts except the cas- ing.

  • Page 59: 3501 Mixer Cross Sectional And Parts List With Materials Of Construction

    7.2 3501 Mixer cross sectional and parts list with materials of construction 7.2 3501 Mixer cross sectional and parts list with materials of construction Mixer Cross Sectional Table 11: 3501 Mixer parts list with materials of construction Item No. Qty Per Part Name Material Mixer...

  • Page 60: How To Order

    7.3 How to order Item No. Qty Per Part Name Material Mixer 316SS Titanium Nut, Impeller 316SS Titanium Window, Sight Glass Glass 332A Seal, Labyrinth - Thrust Bronze/Viton Bronze/Viton 333A Seal, Labyrinth - Radial Bronze/Viton Bronze/Viton Gasket, Casing Non-Asbestos Non-Asbestos Stud, Gland 304SS 304SS...
  • Page 61 7.4 Emergency service Call 1-800-446-8537 Visit our Web site at http://www.gouldspumps.com 3501 Installation, Operation, and Maintenance Instructions...
  • Page 62 Visit our website for the latest version of this document and more information: www.gouldspumps.com ITT - Goulds Pumps 240 Fall Street Seneca Falls, NY 13148 Form IOM.3501.en-us.2022-03 ©2022 ITT Corporation The original instruction is in English. All non-English instructions are translations of the original instruction.
