NSFOCUS ADS NX3-800E Installation Manual

Security products
Hide thumbs Also See for ADS NX3-800E:
Table of Contents

Advertisement

Quick Links

NSFOCUS Security Products
Hardware Installation Guide
Version: V1.0R01F00 (2021-05-18)
Confidentiality: Restricted
© 2021 NSFOCUS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADS NX3-800E and is the answer not in the manual?

Questions and answers

Related Manuals for NSFOCUS ADS NX3-800E

Summary of Contents for NSFOCUS ADS NX3-800E

  • Page 1 NSFOCUS Security Products Hardware Installation Guide Version: V1.0R01F00 (2021-05-18) Confidentiality: Restricted © 2021 NSFOCUS...
  • Page 2 ■ Copyright © 2021 NSFOCUS Technologies, Inc. All rights reserved. Unless otherwise stated, NSFOCUS Technologies, Inc. holds the copyright for the content of this document, including but not limited to the layout, figures, photos, methods, and procedures, which are protected under the intellectual property and copyright laws.

  • Page 3: Table Of Contents

    NSFOCUS Security Products Hardware Installation Guide Contents Preface ..............................1 Scope ..................................1 Disclaimer ................................1 Audience ................................1 Organization ................................2 Conventions ................................2 Customer Support..............................2 1 Hardware Information ......................... 4 1.1 Hardware Appearance ............................4 1.1.1 ADS ................................. 4 1.1.2 ADS M ..............................
  • Page 4 NSFOCUS Security Products Hardware Installation Guide 1.2.12 WAF ..............................89 1.2.13 WVSS ..............................91 1.3 Power Supply System............................. 93 1.4 LEDs ................................94 1.4.1 Common LEDs ............................. 94 1.4.2 LEDs on ADS ............................95 2 Installation Preparations ......................97 2.1 Accessories ..............................97 2.1.1 Accessories of 1U Devices ........................

  • Page 5: Preface

    NSFOCUS Security Products Hardware Installation Guide Preface Scope This document presents the hardware information and installation and maintenance methods of NSFOCUS security devices. This document is provided for reference only. Slight differences may exist between various security devices. Disclaimer This document is provided for reference only. It is intended for general guidance, without covering all usage scenarios.

  • Page 6: Organization

    NSFOCUS Security Products Hardware Installation Guide Organization Chapter Description 1 Hardware Information Describes the appearances and hardware parameters of security devices. 2 Installation Preparations Describes preparations to be made before installing a security device. 3 Installation Methods Describes how to install a security device.
  • Page 7 NSFOCUS Security Products Hardware Installation Guide UK: +44 808 164 0673 or +44 808 164 0NSF ⚫ Australia: +61 2 8599 0673 or +61 2 8599 0NSF ⚫ Netherlands: +31 85 208 2673 or +31 85 208 2NSF ⚫ Brazil: +55 13 4042 1673 or +55 13 4042 1NSF ⚫...

  • Page 8: Hardware Information

    Hardware Appearance This section describes the appearance of each hardware device in alphabetical order of device name acronyms. 1.1.1 ADS This section describes the front panels and rear panels of NSFOCUS Anti-DDoS System (ADS). 1.1.1.1 ADS NX3-800E (1U) Figure 1-1...
  • Page 9 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-1 Front panel of ADS NX3-800E ① ② RST: reset LED STA: status LED ③ ④ PWR: power LED SYS: system LED ⑤ ⑥ RJ45 console port M: management port ⑦...
  • Page 10 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-3 Front panel of ADS NX3-HD1000 ① ② PWR: power LED SYS: system LED ③ ④ HDD: hard disk LED Bypass LED of working ports 5 and 6 ⑤ ⑥ Bypass LED of working ports 3 and 4 Bypass LED of working ports 1 and 2 ⑦...
  • Page 11 NSFOCUS Security Products Hardware Installation Guide 1.1.1.3 ADS NX3-HD2500/NX5-HD4500 (1U) ADS NX3-HD2500 and NX5-HD4500 use the same hardware platform and have similar appearances and hardware parameters. The following uses ADS NX3-HD2500 as an example to show the appearance of the two models.
  • Page 12 NSFOCUS Security Products Hardware Installation Guide 1.1.1.4 ADS NX3-2000E/NX5-4000E/6000E (2U) ADS NX3-2000E, NX5-4000E, and ADS NX5-6000E use the same hardware platform, and have similar appearances and hardware parameters. The following uses ADS NX5-4000E as an example to show the appearance of these models.
  • Page 13 NSFOCUS Security Products Hardware Installation Guide ① ② Ground connector Power switch ③ ④ Mute button: As the device supports two Power connectors power supplies, if only one power supply is configured, a sound alert will be generated. To clear the alert, press the mute button.
  • Page 14 NSFOCUS Security Products Hardware Installation Guide Rear Panel Figure 1-10 Rear panel of ADS NX5-HD6500 ① Ground connector ② Heat dissipation holes ③ Power switch ④ Power supplies Mute button: As the device supports two ⑤ power supplies, if only one power supply is －...
  • Page 15 NSFOCUS Security Products Hardware Installation Guide USB ports ⑤ ⑥ IPMI port M: management port ⑦ ⑧ H1: management port ⑨ ⑩ Working/Expansion ports Empty slot (not for use) － ⑪ HDD caddy Rear Panel Figure 1-12 Rear panel of ADS NX5-8500 ①...
  • Page 16 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-13 Front panel of ADS NX5-8000 ① Power switch ② RST: reset LED PWR: power LED STA: status LED ③ ④ SYS: system LED IPMI port ⑤ ⑥ ⑦ M: management port ⑧...
  • Page 17 NSFOCUS Security Products Hardware Installation Guide 1.1.1.8 ADS NX5-HFA2000 (1U) Figure 1-15 Figure 1-16 show the front panel and rear panel of ADS NX5-HFA2000 respectively. Front Panel Figure 1-15 Front panel of ADS NX5-HFA2000 PWR: power LED SYS: system LED ①...
  • Page 18 NSFOCUS Security Products Hardware Installation Guide ⚫ HTCA-SFPP16TX4 Supports configuration of up to four 1000M electrical ports and 16 10G optical ports. ⚫ HTCA-CXP2SFPP20 Supports configuration of up to two 100G optical ports and 20 10G optical ports. ⚫ HTCA-QSFP28x6QSFP4SFPP16 Supports configuration of up to six 100G optical ports, four 40G optical ports, and 16 10G optical ports.
  • Page 19 NSFOCUS Security Products Hardware Installation Guide Front Panel with the HTCA-CXP2SFPP20 Interface Figure 1-18 shows the front panel of ADS NX5-10000 with the HTCA-CXP2SFPP20 interface. Figure 1-18 Front panel with the HTCA-CXP2SFPP20 interface ① Working ports: 100G optical ② Working ports: 10G optical ③...
  • Page 20 NSFOCUS Security Products Hardware Installation Guide Figure 1-19 Front panel with the HTCA-QSFP28x6QSFP4SFPP16 interface ① Working ports: 100G optical ② Working ports: 40G optical ③ ④ Working ports: 10G optical Working ports: 10G optical ⑤ IPMI port ⑥ RJ45 console port ⑦...
  • Page 21 NSFOCUS Security Products Hardware Installation Guide Figure 1-20 Rear panel of ADS NX5-10000 ① Management port ② USB port Heat dissipation holes Power switch ③ ④ Power LED Power supplies power modules ⑤ ⑥ vary with the number of cards available) Ground connector ⑦...
  • Page 22 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-21 Front panel of ADS NX5-12000 ① Working ports: 100G optical ② Working ports: 40G optical ③ ④ Working ports: 10G optical Working ports: 10G optical IPMI port ⑤ ⑥ RJ45 console port ⑦...

  • Page 23: Ads M

    NSFOCUS Security Products Hardware Installation Guide Rear Panel Figure 1-22 Rear panel of ADS NX5-12000 ① Management port ② USB port Heat dissipation holes Power switch ③ ④ Power LED Power supply (AC power modules vary with ⑤ ⑥ the number of cards available) ⑦...
  • Page 24 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-23 Front panel of ADS M NX3-1600E ① ② M: management port H1: management port ③ ④ RJ45 console port USB port ⑤ ⑥ RST: reset LED PWR: power LED ⑦...
  • Page 25 NSFOCUS Security Products Hardware Installation Guide power supplies, if only one power supply is configured, a sound alert will be generated. To clear the alert, press the mute button. 1.1.2.2 ADS M NX3-HD2700 (2U) Figure 1-25 Figure 1-26 show the front panel and rear panel of ADS M NX3-HD2700 respectively.

  • Page 26: Bvs

    － configured, a sound alert will be generated. To clear the alert, press the mute button. 1.1.3 BVS This section describes the front panels and rear panels of NSFOCUS Benchmark Verification System (BVS). 1.1.3.1 BVS NX3-P (Portable) Figure 1-27 Figure 1-28 show the front panel and rear panel of BVS NX3-P respectively.
  • Page 27 NSFOCUS Security Products Hardware Installation Guide Rear Panel Figure 1-28 Rear panel of BVS NX3-P ① Power adapter port ② Power switch 1.1.3.2 BVS NX3-S (1U) Figure 1-29 Figure 1-30 show the front panel and rear panel of BVS NX3-S respectively.
  • Page 28 NSFOCUS Security Products Hardware Installation Guide Rear Panel Figure 1-30 Rear panel of BVS NX3-S ① ② Ground connector Power switch － ③ Power connector 1.1.3.3 BVS NX3-E (2U) Figure 1-31 Figure 1-32 show the front panel and rear panel of BVS NX3-E respectively.

  • Page 29: Espc

    To clear the alert, press the mute button. 1.1.4 ESPC This section describes the front panels and rear panels of NSFOCUS Enterprise Security Planning Customer (ESPC). 1.1.4.1 ESPC NX3-HD1000D/HD2000D/HD2200-BM (1U) ESPC NX3-HD1000D, NX3-HD2000D, and NX3-HD2200-BM use the same hardware platform and have similar appearances and hardware parameters.
  • Page 30 NSFOCUS Security Products Hardware Installation Guide USB port M: management port ⑤ ⑥ Standby management port ⑦ ⑧ Working/Expansion ports Rear Panel Figure 1-34 Rear panel of ESPC NX3-HD2200-BM Ground connector Heat dissipation holes ① ② ③ Power switch ④...

  • Page 31: Nids

    To clear the alert, press the mute button. 1.1.5 NIDS This section describes the front panels and rear panels of NSFOCUS Network Intrusion Detection System (NIDS). 1.1.5.1 NIDS NX3-CH1330/NX3-CH1350/NX3-HD1200C/NX3-HD1300C/...
  • Page 32 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-37 Front panel of NIDS NX3-CH1330 ① ② RST: reset LED STA: status LED ③ ④ PWR: power LED SYS: system LED ⑤ ⑥ RJ45 console port M: management port ⑦...
  • Page 33 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-39 Front panel of NIDS NX3-HD4200 ① ② PWR: power LED SYS: system LED ③ ④ RJ45 console port STA: status LED ⑤ USB port ⑥ M: management port Standby management port ⑦...
  • Page 34 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-41 Front panel of NIDS NX3-CH3330 ① ② RST: reset LED STA: status LED ③ ④ PWR: power LED SYS: system LED ⑤ ⑥ RJ45 console port M: management port ⑦...
  • Page 35 NSFOCUS Security Products Hardware Installation Guide 1.1.5.4 NIDS NX5-CH6330/CH6350 (2U) NIDS NX5-CH6330 and NX5-CH6350 use the same hardware platform and have similar appearances and hardware parameters. The following uses NIDS NX5-CH6330 as an example to show the appearance of the two models.
  • Page 36 NSFOCUS Security Products Hardware Installation Guide Rear Panel Figure 1-44 Rear panel of NIDS NX5-CH6330 ① ② Power connector Power switch ③ ④ Mute button: As the device supports two Ground connector power supplies, if only one power supply is configured, a sound alert will be generated.
  • Page 37 NSFOCUS Security Products Hardware Installation Guide RJ45 console port ③ ④ STA: status LED USB port M: management port ⑤ ⑥ ⑦ H1: standby management port ⑧ Working/Expansion ports ⑨ ⑩ Monitor HDD caddy Rear Panel Figure 1-46 Rear panel of NIDS NX3-HD4220 ①...
  • Page 38 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-47 Front panel of the interface board of NIDS NX5-HD12000 ① ② VGA port of the monitor Working ports: optical ③ ④ Network port LED USB port ⑤ ⑥ RST port ATN LED ⑦...
  • Page 39 NSFOCUS Security Products Hardware Installation Guide Rear Panel Figure 1-49 Rear panel of NIDS NX5-HD12000 ① ② Power supplies Power connectors 1.1.5.7 NIDS NX3-HFC/NX5-HFD (1U) NIDS NX3-HFC and NX5-HFD use the same hardware platform and have similar appearances and hardware parameters. The following uses NIDS NX3-HFC as an example to show the appearance of the two models.

  • Page 40: Nips

    ② Power switch Power connectors ③ ④ 1.1.6 NIPS This section describes the front panels and rear panels of NSFOCUS Network Intrusion Prevention System (NIPS). 1.1.6.1 NIPS NX3-CH1330/NX3-CH1350/NX3-HD1200C/NX3-HD1300C/ NX3-HD1600 (1U) NIPS NX3-CH1330, NX3-CH1350, NX3-HD1200C, NX3-HD1300C, and NX3-HD1600 use the same hardware platform and have similar appearances and hardware parameters. The following uses NIPS NX3-CH1330 as an example to show the appearance of these models.
  • Page 41 NSFOCUS Security Products Hardware Installation Guide Figure 1-52 Figure 1-53 show the front panel and rear panel of NIPS NX3-CH1330 respectively. Front Panel Figure 1-52 Front panel of NIPS NX3-CH1330 ① ② RST: reset LED STA: status LED ③ ④...
  • Page 42 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-54 Front panel of NIPS NX3-HD4200 ① ② PWR: power LED SYS: system LED ③ ④ RJ45 console port STA: status LED ⑤ USB port ⑥ Management port Standby management port ⑦...
  • Page 43 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-56 Front panel of NIPS NX3-CH3330 ① ② RST: reset LED STA: status LED ③ ④ PWR: power LED SYS: system LED ⑤ ⑥ RJ45 console port M: management port ⑦...
  • Page 44 NSFOCUS Security Products Hardware Installation Guide 1.1.6.4 NIPS NX5-CH6330/CH6350 (2U) NIPS NX5-CH6330 and NX5-CH6350 use the same hardware platform and have similar appearances and hardware parameters. The following uses NIPS NX5-CH6330 as an example to show the appearance of the two models.
  • Page 45 NSFOCUS Security Products Hardware Installation Guide Rear Panel Figure 1-59 Rear panel of NIPS NX5-CH6330 ① ② Power connectors Power switch ③ ④ Mute button: As the device supports two Ground connector power supplies, if only one power supply is configured, a sound alert will be generated.
  • Page 46 NSFOCUS Security Products Hardware Installation Guide USB port M: management port ⑮ ⑯ H1: standby management port ⑰ ⑱ Working/Expansion ports ⑲ ⑳ Monitor HDD caddy Rear Panel Figure 1-61 Rear panel of NIPS NX3-HD4220 Ground connector Heat dissipation holes ⑥...
  • Page 47 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-62 Front panel of the interface board of NIPS NX5-HD12000 ① ② VGA port of the monitor Working ports: optical ③ ④ Network port LED USB port ⑤ ⑥ RST port ATN LED ⑦...
  • Page 48 NSFOCUS Security Products Hardware Installation Guide Rear Panel Figure 1-64 Rear panel of NIPS NX5-HD12000 ① ② Power supplies Power connectors 1.1.6.7 NIPS NX3-HFC/NX5-HFD (1U) NIPS NX3-HFC and NX5-HFD use the same hardware platform and have similar appearances and hardware parameters. The following uses NIPS NX3-HFC as an example to show the appearance of the two models.

  • Page 49: Nta

    Power switch Power connectors ③ ④ 1.1.7 NTA This section describes the front panels and rear panels of NSFOCUS Network Traffic Analyzer (NTA). 1.1.7.1 NTA NX3-C1000E /1000E/2000E (2U) NTA NX3-C1000E, NX3-1000E, and NX3-2000E use the same hardware platform, and have similar appearances and hardware parameters.
  • Page 50 NSFOCUS Security Products Hardware Installation Guide Figure 1-67 Figure 1-68 show the front panel and rear panel of ADS NX3-2000E respectively. Front Panel Figure 1-67 Front panel of NTA NX3-2000E ① ② M: management port H1: management port ③ ④...
  • Page 51 NSFOCUS Security Products Hardware Installation Guide configured, a sound alert will be generated. To clear the alert, press the mute button. 1.1.7.2 NTA NX3-HD2100/HD2200 (2U) NTA NX3-HD2100 and NX3-HD2200 use the same hardware platform and have similar appearances and hardware parameters. The following uses NTA NX3-HD2100 as an example to show the appearance of the two models.

  • Page 52: Nta-D

    NSFOCUS Security Products Hardware Installation Guide Rear Panel Figure 1-70 Rear panel of NTA NX3-HD2100 ① ② Ground connector Heat dissipation holes ③ ④ Power switch Power supply 1 ⑤ ⑥ Mute button: As the device supports two Power supply 2 power supplies, if only one power supply is configured, a sound alert will be generated.
  • Page 53 NSFOCUS Security Products Hardware Installation Guide ① ② M: management port H1: management port ③ ④ RJ45 console port USB port ⑤ ⑥ RST: reset LED PWR: power LED ⑦ ⑧ STA: status LED SYS: system LED ⑨ ⑩ Working ports: electrical...
  • Page 54 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-73 Front panel of NTA-D NX3-HD3000 ① ② Monitor HDD caddy ③ ④ PWR: power LED SYS: system LED RJ45 console port ⑤ ⑥ STA: status LED USB port M: management port ⑦...

  • Page 55: Nta-Flb

    NSFOCUS Security Products Hardware Installation Guide 1.1.9 NTA-FLB This section describes the front panels and rear panels of NTA-FLB. 1.1.9.1 NTA-FLB NX3-F2000 (2U) Figure 1-75 Figure 1-76 show the front panel and rear panel of NTA-FLB NX3-F2000 respectively. Front Panel Figure 1-75 Front panel of NTA-FLB NX3-F2000 ①...
  • Page 56 NSFOCUS Security Products Hardware Installation Guide Rear Panel Figure 1-76 Rear panel of NTA-FLB NX3-F2000 ① ② Ground connector Heat dissipation holes ③ ④ Power switch Power supply 1 ⑤ ⑥ Mute button: As the device supports two Power supply 2 power supplies, if only one power supply is configured, a sound alert will be generated.

  • Page 57: Rsas

    To clear the alert, press the mute button. 1.1.10 RSAS This section describes the front panels and rear panels of NSFOCUS Remote Security Assessment System (RSAS). 1.1.10.1 RSAS NX3-P (Portable)
  • Page 58 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-79 Front panel of RSAS NX3-P ① ② STA: status LED PWR: power LED ③ ④ SYS: system LED RJ45 console port ⑤ ⑥ USB port M: management port － ⑦...
  • Page 59 NSFOCUS Security Products Hardware Installation Guide 1.1.10.2 RSAS NX3-A (Portable) Figure 1-81 Figure 1-82 show the front panel and rear panel of RSAS NX3-A respectively. Front Panel Figure 1-81 Front panel of RSAS NX3-A ① － Monitor Rear Panel Figure 1-82 Rear panel of RSAS NX3-A ①...
  • Page 60 NSFOCUS Security Products Hardware Installation Guide ⑦ ⑧ Working ports: electrical Power adapter port － ⑨ Power switch 1.1.10.3 RSAS NX3-X (1U) Figure 1-83 Figure 1-84 show the front panel and rear panel of BVS NX3-X respectively. Front Panel Figure 1-83 Front panel of RSAS NX3-X ①...
  • Page 61 NSFOCUS Security Products Hardware Installation Guide 1.1.10.4 RSAS NX3-S (1U) Figure 1-85 Figure 1-86 show the front panel and rear panel of RSAS NX3-S respectively. Front Panel Figure 1-85 Front panel of RSAS NX3-S ① ② RST: reset LED STA: status LED ③...
  • Page 62 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-87 Front panel of RSAS NX3-E ① ② RST: reset LED STA: status LED ③ ④ PWR: power LED SYS: system LED ⑤ ⑥ RJ45 console port M: management port ⑦...

  • Page 63: Tac (2U)

    NSFOCUS Security Products Hardware Installation Guide 1.1.11 TAC (2U) This section describes the front panels and rear panels of NSFOCUS Traffic Analysis Center (TAC). 1.1.11.1 TAC NX3-D600A/D1000A/D2000A/E600A/E1000A/E2000A (2U) TAC NX3-D600A, NX3-D1000A, NX3-D2000A, NX3-E600A, NX3-E1000A, and NX3- E2000A use the same hardware platform and have similar appearances and hardware parameters (TAC NX3-D600A has only one expansion slot, while the others have four).
  • Page 64 NSFOCUS Security Products Hardware Installation Guide Rear Panel Figure 1-90 Rear panel of TAC NX3-D1000A ① ② Power supply 1 Power supply 2 ③ ④ Switch of power supply 2 Switch of power supply 1 ⑤ ⑥ Heat dissipation holes Ground connector 1.1.11.2...

  • Page 65: Waf

    To clear the alert, press the mute button. 1.1.12 WAF This section describes the front panels and rear panels of NSFOCUS Web Application Firewall (WAF). 1.1.12.1 WAF NX3-HD300C/HD600D/HD800D (1U) WAF NX3-HD300C, NX3-HD600C, and NX3-HD800C use the same hardware platform and have similar appearances and hardware parameters.
  • Page 66 NSFOCUS Security Products Hardware Installation Guide ① ② SYS: system LED PWR: power LED ③ ④ STA: status LED RJ45 console port ⑤ ⑥ USB port M: management port － ⑦ Working ports: electrical Rear Panel Figure 1-94 Rear panel of WAF NX3-HD300C ①...
  • Page 67 NSFOCUS Security Products Hardware Installation Guide ⑤ ⑥ RJ45 console port M: management port ⑦ ⑧ USB port Working ports: electrical ⑨ － Working ports: electrical Rear Panel Figure 1-96 Rear panel of WAF NX3-P1000B ① ② Ground connector Power switch ③...
  • Page 68 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-97 Front panel of WAF NX5-CH7650 ① ② Power switch RST: reset LED ③ ④ PWR: power LED STA: status LED ⑤ ⑥ SYS: system LED M: management port ⑦ ⑧...
  • Page 69 NSFOCUS Security Products Hardware Installation Guide 1.1.12.4 WAF NX5-HD1600/HD1610/HD1620/HD1630 (2U) WAF NX5-HD1600, NX5-HD1610, NX5-HD1620, and NX5-HD1630 use the same hardware platform and have similar appearances and hardware parameters. The following uses WAF NX5-HD1600 as an example to show the appearance of these models.
  • Page 70 NSFOCUS Security Products Hardware Installation Guide ③ ④ Power switch Power supply 1 ⑤ ⑥ Power supply 2 Mute button: As the device supports two power supplies, if only one power supply is configured, a sound alert will be generated.
  • Page 71 NSFOCUS Security Products Hardware Installation Guide Rear Panel Figure 1-102 Rear panel of WAF NX3-P2000A ① ② Ground connector Heat dissipation holes ③ ④ Power switch Power supply 1 ⑤ ⑥ Mute button: As the device supports two Power supply 2 power supplies, if only one power supply is configured, a sound alert will be generated.
  • Page 72 NSFOCUS Security Products Hardware Installation Guide ① ② M: management port H1: management port ③ ④ RJ45 console port USB port ⑤ ⑥ RST: reset LED PWR: power LED ⑦ ⑧ STA: status LED SYS: system LED ⑨ ⑩ Working ports: electrical Working ports: optical ⑪...
  • Page 73 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-105 Front panel of WAF NX5-HF6000D ① ② PWR: power LED SYS: system LED ③ ④ STA: status LED RJ45 console port ⑤ ⑥ USB port M: management port ⑦ ⑧...

  • Page 74: Wvss

    Figure 1-108 Rear panel of WAF NX3-HF ① ② Heat dissipation holes Power switch － ③ Power connectors 1.1.13 WVSS This section describes the front panels and rear panels of NSFOCUS Web Vulnerability Scanning System (WVSS). Copyright © NSFOCUS V1.0R01F00 (Restricted)
  • Page 75 NSFOCUS Security Products Hardware Installation Guide 1.1.13.1 WVSS NX3-P (Portable) Figure 1-109 Figure 1-110 show the front panel and rear panel of WVSS NX3-P respectively. Front Panel Figure 1-109 Front panel of WVSS NX3-P ① ② STA: status LED PWR: power LED ③...
  • Page 76 NSFOCUS Security Products Hardware Installation Guide ① Power adapter port ② Power switch 1.1.13.2 WVSS NX3-X (1U) Figure 1-111 Figure 1-112 show the front panel and rear panel of WVSS NX3-X respectively. Front Panel Figure 1-111 Front panel of WVSS NX3-X ①...
  • Page 77 NSFOCUS Security Products Hardware Installation Guide 1.1.13.3 WVSS NX3-S (1U) Figure 1-113 Figure 1-114 show the front panel and rear panel of WVSS NX3-S respectively. Front Panel Figure 1-113 Front panel of WVSS NX3-S ① ② RST: reset LED STA: status LED ③...
  • Page 78 NSFOCUS Security Products Hardware Installation Guide Front Panel Figure 1-115 Front panel of WVSS NX3-E ① ② RST: reset LED STA: status LED ③ ④ PWR: power LED SYS: system LED ⑤ ⑥ RJ45 console port M: management port ⑦...

  • Page 79: Hardware Parameters

    NSFOCUS Security Products Hardware Installation Guide Hardware Parameters This section describes parameters of each hardware device in alphabetical order of device name acronyms. Hardware parameters may vary slightly with lots and models. 1.2.1 ADS Table 1-1 lists hardware parameters of ADS.
  • Page 80 NSFOCUS Security Products Hardware Installation Guide Input voltage range: –36 V to  +72 V 2. Output  Maximum output power: 300 ADS NX5-HFA2000 435*560*44 Redundant AC power supply 8.5 kg 1. Input  Input voltage range: 100–240  Input current: 2–5 A 2.

  • Page 81: Ads M

    NSFOCUS Security Products Hardware Installation Guide Redundant DC power supply 1. Input Input voltage range: –36 V to  +72 V 2. Output  Maximum output power: 300 ADS NX5-8000 626*443*88 Redundant AC power supply 16.5 kg 1. Input ...

  • Page 82: Bvs

    NSFOCUS Security Products Hardware Installation Guide Model Dimensions W*D*H Power Supply Weight (unit: mm) 2. Output  Maximum output power: 350 Redundant DC power supply 1. Input Input voltage range: –36 V to  +72 V 2. Output  Maximum output power: 400...

  • Page 83: Espc

    NSFOCUS Security Products Hardware Installation Guide Model Dimensions W*D*H Power Supply Weight (unit: mm) BVS NX3-S 430*390*44 Single AC power supply 6.7 kg 1. Input  Input voltage range: 110–240  Input current: 1.5–3 A 2. Output  Maximum output power: 250...

  • Page 84: Nids

    NSFOCUS Security Products Hardware Installation Guide Model Dimensions Power Supply Weight W*D*H (unit: mm)  Input voltage range: 100–240  Input current: 6–3 A 2. Output  Maximum output power: 250 ESPC NX3-HD3000D 435*560*88 Redundant AC power supply 20 kg ESPC NX3-HD5000D 1.
  • Page 85 NSFOCUS Security Products Hardware Installation Guide Model Dimensions W*D*H Power Supply Weight (unit: mm) Input voltage range: –36 V to  +72 V 2. Output  Maximum output power: 300 NIDS NX3-CH3330 575*432*88 Redundant AC power supply 12.6 kg 1. Input ...

  • Page 86: Nips

    NSFOCUS Security Products Hardware Installation Guide Model Dimensions W*D*H Power Supply Weight (unit: mm) NIDS NX5-HD6200  Maximum output power: 300 NIDS NX5-HD6300 Redundant DC power supply 1. Input Input voltage range: –36 V to  +72 V 2. Output ...
  • Page 87 NSFOCUS Security Products Hardware Installation Guide Model Dimensions W*D*H Power Supply Weight (unit: mm)  Maximum output power: 300 Redundant DC power supply 1. Input Input voltage range: –36 V to  +72 V 2. Output  Maximum output power: 300...

  • Page 88: Nta

    NSFOCUS Security Products Hardware Installation Guide Model Dimensions W*D*H Power Supply Weight (unit: mm) NIPS NX3-HD4220 435*560*88 Redundant AC power supply 16 kg NIPS NX3-HD4320 1. Input NIPS NX5-HD4500  Input voltage range: 100–240 NIPS NX5-HD4520 NIPS NX5-HD4700  Input current: 4.5–2 A NIPS NX5-HD4720 2.

  • Page 89: Nta-D

    NSFOCUS Security Products Hardware Installation Guide Model Dimensions W*D*H Power Supply Weight (unit: mm) Input voltage range: –36 V to  +72 V 2. Output  Maximum output power: 400 NTA NX3-HD2100 435*560*88 Redundant AC power supply 16 kg NTA NX3-HD2200 1.

  • Page 90: Nta-Flb

    NSFOCUS Security Products Hardware Installation Guide Model Dimensions W*D*H Power Supply Weight (unit: mm)  Maximum output power: 400 NTA-D NX3-HD3000 435*560*88 Redundant AC power supply 16 kg 1. Input  Input voltage range: 100–240  Input current: 4.5–2 A 2.

  • Page 91: Rsas

    NSFOCUS Security Products Hardware Installation Guide Model Dimensions W*D*H Power Supply Weight (unit: mm) NTA-FLB NX3-F2200 435*560*88 Redundant AC power supply 16 kg 1. Input  Input voltage range: 100–240  Input current: 4.5–2 A 2. Output  Maximum output power: 300 Redundant DC power supply 1.

  • Page 92: Tac

    NSFOCUS Security Products Hardware Installation Guide Model Dimensions W*D*H Power Supply Weight (unit: mm)  Input voltage range: 100–240  Input current: 0–5 A 2. Output  Maximum output power: 65 RSAS NX3-S 430*390*44 Single AC power supply 6.7 kg 1.

  • Page 93: Waf

    NSFOCUS Security Products Hardware Installation Guide Model Dimensions W*D*H Power Supply Weight (unit: mm) TAC NX3-E600A  Input current: 7–3 A TAC NX3-E1000A 2. Output TAC NX3-E2000A  Maximum output power: 450 Redundant DC power supply 1. Input Input voltage range: –36 V to ...
  • Page 94 NSFOCUS Security Products Hardware Installation Guide Model Dimensions W*D*H Power Supply Weight (unit: mm)  Maximum output power: 65 WAF NX3-P1000B 575*432*88 Redundant AC power supply 12.6 kg 1. Input  Input voltage range: 100–240  Input current: 8–5 A 2.

  • Page 95: Wvss

    NSFOCUS Security Products Hardware Installation Guide Model Dimensions W*D*H Power Supply Weight (unit: mm) Input voltage range: –36 V to  +72 V 2. Output  Maximum output power: 300 WAF NX3-P1000E 575*432*88 Redundant AC power supply 13.8 kg WAF NX3-P2000A 1.
  • Page 96 NSFOCUS Security Products Hardware Installation Guide Table 1-13 Hardware parameters of WVSS Model Dimensions W*D*H Power Supply Weight (unit: mm) WVSS NX3-P 271*175*44 Single AC power supply 2.35 kg 1. Input  Input voltage range: 100–240  Input current: 1.6 A 2.

  • Page 97: Power Supply System

    NSFOCUS Security Products Hardware Installation Guide Power Supply System This section describes the power supply system of portable and 1U, 2U, 4U, and 6U rack- mounted security devices. Portable Device This type of security device can only be powered with AC adapters.

  • Page 98: Leds

    NSFOCUS Security Products Hardware Installation Guide Number of Service Boards Recommended Power Supply Configuration 4 (3 active + 1 standby) 5 (4 active + 1 standby) 5 (4 active + 1 standby) LEDs This section describes common LEDs and LEDs on ADS.

  • Page 99: Leds On Ads

    NSFOCUS Security Products Hardware Installation Guide LED Type LED Status Meaning The HDD is idle. CMM status LED (A/S) CMM is activated. CMM is in the waiting state. Status LED (+) BIOS submission in progress. Green BIOS submission completed. 1.4.2 LEDs on ADS Table 1-16 describes LEDs on the front panel of ADS.
  • Page 100 The OK LED is available only for the AC power supply of ADS NX3-2020E, NX3-  HD2500, NX5-4020E, NX5-6025E, NX5-HD4500, NX5-HFA2000, NX5- HD6500, and NX3-HD1000. The OK LED is unavailable for the AC power supply of ADS NX3-800E, NX5-  8000, and NX5-10000. ADS NX3-800E supports a single AC power supply only, with the ...

  • Page 101: Installation Preparations

    NSFOCUS Security Products Hardware Installation Guide Installation Preparations Before installing a security device, you need to check accessories and prepare the network environment, common tools, and equipment room environment. Accessories Before installation, check whether all accessories are included in the accessory kit delivered with the device.

  • Page 102: Accessories Of 2U Devices

    NSFOCUS Security Products Hardware Installation Guide Accessory Description  Rear mounting ear bolt: used with rear mounting ears.  Rack screws and nuts: fixes front and rear mounting ears onto rack rails. Figure 2-1 Accessories for mounting a device onto a 1U rack 2.1.2 Accessories of 2U Devices...

  • Page 103: Accessories Of 6U Devices

    NSFOCUS Security Products Hardware Installation Guide Accessory Description  Rubber pad: You can cut it into four smaller ones along the dotted line and attach them to the four corners of or marked places on the device to avoid abrasion.

  • Page 104: User-Provided Tools And Devices

    NSFOCUS Security Products Hardware Installation Guide Accessory Description  Mounting ear: fixes the front end of the chassis onto the rack.  Mounting ear bolt: used with front mounting ears.  Inner rack rail: adjusts the distance between the device and the rack.

  • Page 105: Installation Methods

    NSFOCUS Security Products Hardware Installation Guide Installation Methods Installation Procedure Figure 3-1 shows the installation procedure. Figure 3-1 Installation flow chart Mounting a Device onto the Rack The appearances and numbers of rackmount accessories for 1U and 2U devices are shown in...

  • Page 106: Device

    NSFOCUS Security Products Hardware Installation Guide 3.2.1 1U Device To mount a 1U device onto the rack, follow these steps: Step 1 Install front mounting ears. Fix front mounting ears (①) with bolts (②) on the left and right sides of the device in the front (three bolts for each ear, that is, six in all).

  • Page 107: Device

    NSFOCUS Security Products Hardware Installation Guide Step 3 Mount the device onto the rack. Install four nuts (④) at the front end of the cabinet (two nuts on either side). Place the device on the rails already installed on the cabinet and fix it with four screws (⑤) (two on either side).
  • Page 108 NSFOCUS Security Products Hardware Installation Guide Figure 3-5 Installing front mounting ears Step 2 Install rack rails. Install four nuts (④) at the rear end of the cabinet (two nuts on either side). Take rack rails (③) out of the accessory kit and fix them onto the cabinet with four screws (⑤) (two on either side).

  • Page 109: Connecting The Power Cable

    NSFOCUS Security Products Hardware Installation Guide Figure 3-7 Mounting the device onto the rack ----End Connecting the Power Cable Security devices support both AC and DC power supplies. 3.3.1 Connecting the AC Power Cable To connect the AC power cable, follow these steps: Step 1 Make sure that the device is properly grounded.
  • Page 110 NSFOCUS Security Products Hardware Installation Guide 3.3.2.1 Positronic Connector For a Positronic connector, the procedure is as follows: Step 1 Make sure that the power switch of the device is in the OFF position. Step 2 Take out the power plug from the packing case.

  • Page 111: Connecting The Network Cable

    NSFOCUS Security Products Hardware Installation Guide Figure 3-9 Binding post terminals Step 3 Insert lead wires of the –48 V DC power supply of the equipment room into two jacks of the DC power supply socket of the device. Ensure that lead wires are inserted into proper jacks. The positive (+) is connected to the cathode with the black wire and the negative (–) to the anode with the red wire.

  • Page 112: A Troubleshooting

    In this case, examine the device by finding out whether the network cable and power cable are loose. Then check the power LED (PWR), status LED (STA), and network card LED. If nothing abnormal is found, contact NSFOCUS technical support for help.
  • Page 113 If the network is resumed, the fault is probably caused by incorrect device configurations. Step 4 If the problem persists or a device or interface failure is confirmed, contact NSFOCUS technical support for help.

  • Page 114: B Notes Concerning Product Disposal

    NSFOCUS Security Products Hardware Installation Guide Notes Concerning Product Disposal To protect the environment, you have the following responsibilities when disposing of products whose lifecycle has expired: Deliver them to a qualified recycling station after separating them from household waste.
