- Page 1 NSFOCUS ADS M Installation Guide Version: V4.5R90F02 (2020-02-28) © 2020 NSFOCUS...
- Page 2 ■ Copyright © 2020 NSFOCUS Technologies, Inc. All rights reserved. Unless otherwise stated, NSFOCUS Technologies, Inc. holds the copyright for the content of this document, including but not limited to the layout, figures, photos, methods, and procedures, which are protected under the intellectual property and copyright laws.
-
Page 3: Table Of Contents
NSFOCUS ADS M Installation Guide Contents Preface ..............................1 Scope ..................................1 Audience ................................1 Organization ................................1 Conventions ................................2 Customer Support..............................2 1 Overview ............................3 1.1 Introduction ..............................3 1.2 Product Appearance............................3 1.2.1 ADS NX3-M1600E ..........................3 1.2.2 ADS-M NX3-HD2700 .......................... - Page 4 NSFOCUS ADS M Installation Guide A.2 Default Account of the Web Administrator ....................21 A.3 Default Account of the Console Administrator ..................... 21 A.4 Communication Parameters of the Console Port ................... 21 Copyright © NSFOCUS V4.5R90F02 (2020-02-28)
- Page 5 Figure 1-4 Rear panel of ADS-M NX3-HD2700 ....................5 Figure 3-1 Installation flowchart .......................... 10 Figure 3-2 DC power supply module of ADS M ....................11 Figure 3-3 DC power supply plug of ADS M ...................... 12 Figure 3-4 Installing rack-mount ears ........................13 Figure 4-1 Main menu of the console ........................
- Page 6 NSFOCUS ADS M Installation Guide Tables Table 1-1 Hardware specifications of ADS NX3-M1600E ..................6 Table 1-2 Power LED ............................. 6 Table 1-3 Status LED ............................. 7 Table 1-4 Link/Act LED ............................7 Copyright © NSFOCUS V4.5R90F02 (2020-02-28)
-
Page 7: Preface
Scope This document describes the basic information and detailed installation procedure of ADS NX3-1600E and ADS-M NX3-HD2700 ("ADS M" for short). This document is provided for reference only. It may slightly differ from the actual product due to version upgrade or other reasons. -
Page 8: Conventions
NSFOCUS ADS M Installation Guide Conventions Convention Description Keywords, names of screen elements like buttons, drop-down lists or fields, and Bold font user-entered text appear in bold font. Document titles, new or emphasized terms, and arguments for which you supply Italic font values are in italic font. -
Page 9: Overview
NSFOCUS ADS M Installation Guide Overview Introduction As an integrated device, ADS NX3-M1600E and ADS-M NX3-HD2700, in standard configuration, apply to 1000M network environments, but can be expanded to support the 10G capability. That is to say, ADS NX3-M1600E can be expanded to become a high-end product. -
Page 10: 1.2.2 Ads-M Nx3-Hd2700
NSFOCUS ADS M Installation Guide ⑤ ⑥ ⑦ ⑧ Reset LED Power LED Status LED System LED ⑨ ⑩ Working port: GE Working port: GE － － electrical (RJ45) optical (SFP) Rear Panel Figure 1-2 Rear panel of ADS NX3-M1600E ①... -
Page 11: Basic Information
NSFOCUS ADS M Installation Guide HDD caddy Rear Panel Figure 1-4 Rear panel of ADS-M NX3-HD2700 Ground connector Power switch Power port Power reset button Basic Information Table 1-1 describes basic information of ADS NX3-M1600E. Copyright © NSFOCUS V4.5R90F02 (2020-02-28) -
Page 12: Leds
NSFOCUS ADS M Installation Guide Table 1-1 Hardware specifications of ADS NX3-M1600E Interface 1 x serial port (RJ45) 2 x USB 2.0 port 2 x management port (RJ45) 4 x 1000M electrical port 4 x 1000M SFP optical port Weight 16.6 kg... -
Page 13: Table 1-3 Status Led
NSFOCUS ADS M Installation Guide Table 1-3 Status LED LED Status Description Blink The system is reading and writing data The system is idle. Link/Act LED Table 1-4 describes the Link/Act LED. Table 1-4 Link/Act LED LED Status Description Link On A link has been established. -
Page 14: Preparation
Straight-through cable (green) Used for network connection Crossover cable (yellow) Used to connect a computer to the management port of ADS M so that you can log in to the web-based manager Power cable One or two power cables for each device ... -
Page 15: User-Provided Tools
NSFOCUS ADS M Installation Guide Directly connected to the management port of ADS M so that you can log in to the web- based manager of the device in HTTPS mode for management Terminal software Connected to the console port, such as HyperTerminal, that comes with the Windows operating system ... -
Page 16: Installation
NSFOCUS ADS M Installation Guide Installation Installation Procedure Figure 3-1 Installation flowchart Connecting to the Power Supply Copyright © NSFOCUS V4.5R90F02 (2020-02-28) -
Page 17: 3.2.1 Ac Power Supply
Figure 3-2. (The DC power supply module of ADS M has a plug and socket. The plug is included in the accessory box, and the socket is integrated in the chassis). Figure 3-2 DC power supply module of ADS M Step 3 Insert three leads of the -48V DC power supply into the three jacks on the plug respectively (ensure that leads match jacks). -
Page 18: Connecting To The Network
Step 5 For the dual power supply, repeat Step 3 and Step 4 to connect the other power cable. ----End Connecting to the Network Please connect the ADS M to the network according to the actual network structure. Pay attention to the following during the connection: ... -
Page 19: Rack-Mounting
For the rack mounting, you need to first install rack-mount ears, as shown in Figure 3-4. Then place the device on the rack and fasten it with screws. Figure 3-4 Installing rack-mount ears Shutdown To shut down ADS M, switch the power switch to the OFF position. Copyright © NSFOCUS V4.5R90F02 (2020-02-28) -
Page 20: Basic Configuration
To perform configurations on the console, you need to connect the device to a computer with a serial cable. The console port rate of ADS M is 115200 bps. After login, you can perform configurations by selecting menus. For details, see section 4.2 Network Configuration on the... -
Page 21: Network Configuration On The Console
Enter to open the console management menu. Network Configuration on the Console After you successfully log in to the console of ADS M, the main menu is displayed, as shown Figure 4-1. Type a sequence number as prompted and press Enter to open a menu. -
Page 22: Login To The Web-Based Manager
Step 1 Verify that the client is connected to the Internet. Step 2 Open a browser (for example, Microsoft Internet Explorer) and connect to the management IP address of ADS M over HTTPS, for example, type https://192.168.1.100 in the address bar. A security alert dialog box appears. See Figure 4-2. -
Page 23: Figure 4-3 Login Page
NSFOCUS ADS M Installation Guide Figure 4-3 Login page Step 4 Type the initial user name and password, and click Login. The Change Password page appears, as shown in Figure 4-4. For the first login, you must the change password. -
Page 24: Figure 4-5 Selecting The Ui Language
NSFOCUS ADS M Installation Guide During the first login to ADS M that has just been upgraded to V4.5R89F03, you need to set the locality, system time zone, and system time, but do not need to change the initial password. -
Page 25: Network Configuration On The Web-Based Manager
For the first login, you must import a valid license before using the system. For details, see the NSFOCUS ADS M User Guide. Network Configuration on the Web-based Manager On the web-based manager, you can configure network parameters as required. - Page 26 NSFOCUS ADS M Installation Guide After the configuration is complete, the device is ready for use. For detailed usage, see the NSFOCUS ADS M User Guide. Copyright © NSFOCUS V4.5R90F02 (2020-02-28)
-
Page 27: A Default Parameters
NSFOCUS ADS M Installation Guide Default Parameters A.1 Default Parameters for the Communication Interface For ADS NX3-M1600E and ADS-M NX3-HD2700: Management Interface 192.168.1.100 Subnet Mask 255.255.255.0 Gateway 192.168.1.1 A.2 Default Account of the Web Administrator User Name admin Password nsfocus A.3 Default Account of the Console Administrator...
