NSFOCUS ADS 2010 Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NSFOCUS ADS
Installation Guide
Version: V4.5R90F00 (2017-12-01)
© 2017 NSFOCUS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADS 2010 and is the answer not in the manual?

Questions and answers

Related Manuals for NSFOCUS ADS 2010

Summary of Contents for NSFOCUS ADS 2010

  • Page 1 NSFOCUS ADS Installation Guide Version: V4.5R90F00 (2017-12-01) © 2017 NSFOCUS...
  • Page 2 ■ Copyright © 2017 NSFOCUS Technologies, Inc. All rights reserved. Unless otherwise stated, NSFOCUS Technologies, Inc. holds the copyright for the content of this document, including but not limited to the layout, figures, photos, methods, and procedures, which are protected under the intellectual property and copyright laws.

  • Page 3: Table Of Contents

    NSFOCUS ADS Installation Guide Contents Preface ..............................1 Scope ..................................1 Audience ................................1 Organization ................................2 Conventions ................................2 Customer Support..............................2 1 Overview ............................4 1.1 Appearance ............................... 4 1.1.1 ADS NX3-2000 Series and NX5-4000/6000 Series ................4 1.1.2 ADS NX5-8000 Series ..........................
  • Page 4 NSFOCUS ADS Installation Guide 5.1 System Update ............................... 28 5.2 Common Troubleshooting ..........................29 5.2.1 Web Login Failure ..........................29 5.2.2 ADS Access Failure ..........................29 5.2.3 License Import Failure .......................... 29 5.2.4 MAC Address Learning Failure ......................30 5.2.5 Ping Failure or Excessive Packets Drop ....................30 A Default Parameters ........................
  • Page 5 NSFOCUS ADS Installation Guide Figures Figure 1-1 Appearance of ADS NX5-4020 ......................5 Figure 1-2 Front panel of ADS NX5-4020 ......................5 Figure 1-3 Rear panel of ADS NX5-4020 ......................6 Figure 1-4 Front panel of ADS NX5-8000 ......................6 Figure 1-5 Rear panel of ADS NX5-8000 ......................
  • Page 6 NSFOCUS ADS Installation Guide Tables Table 1-1 AC power LEDs ............................. 8 Table 1-2 DC power LEDs ............................. 9 Table 1-3 Power LED ............................10 Table 1-4 Status LED ............................10 Table 1-5 System LED ............................10 Table 1-6 Interface LED ............................10 Table 1-7 Hardware specifications of ADS NX3-2000 series and NX5-4000/6000 series ........

  • Page 7: Preface

    Preface Scope This document describes the basic information and detailed installation procedure about NSFOCUS ADS NX3 2000 series (NX3-2020/2020E/2010), NX3-200E/600E/800E, NX5 4000 series (NX5-4020/4020E), NX5 6000 series (NX5-6025/6025E), and NX5 8000 series (NX5-8000). This document provides guidance for you in use of the products. Descriptions in this guide may slightly differ from actual products due to version upgrade or other reasons.

  • Page 8: Organization

    NSFOCUS ADS Installation Guide  Network security  Linux and Windows operating systems  TCP/IP protocols Organization Chapter Description 1 Overview Describes hardware configuration and system architecture of ADS devices. 2 Preparations Describes preparations before installing ADS devices. 3 Installation Procedure Describes methods for installing ADS devices.
  • Page 9 NSFOCUS ADS Installation Guide Contacts:  USA: +1-844-673-6287 or +1-844-NSFOCUS  UK: +44 808 164 0673 or +44 808 164 0NSF  Australia: +61 2 8599 0673 or +61 2 8599 0NSF  Netherlands: +31 85 208 2673 or +31 85 208 2NSF ...

  • Page 10: Overview

    NSFOCUS ADS Installation Guide Overview The ADS system is an integrated hardware device. This chapter gives a brief account of ADS devices. Appearance This section details the appearance, including front and rear panels, of ADS devices. The interface model or quantity of actual products may slightly vary with the batch or model.

  • Page 11: Figure 1-1 Appearance Of Ads Nx5-4020

    NSFOCUS ADS Installation Guide Figure 1-1 Appearance of ADS NX5-4020 Front Panel Figure 1-2 Front panel of ADS NX5-4020 ① Management interface ② Hot standby port ③ RJ45 console port ④ USB interface ⑤ Reset button ⑥ Power LED ⑦ Status LED ⑧...

  • Page 12: Ads Nx5-8000 Series

    NSFOCUS ADS Installation Guide Rear Panel Figure 1-3 Rear panel of ADS NX5-4020 ① Power switch ② Power ③ Power port port 1.1.2 ADS NX5-8000 Series Figure 1-4 Figure 1-5 show the front and rear panels of ADS NX5-8000, respectively.

  • Page 13: Ads Nx3-200E/600E/800E

    NSFOCUS ADS Installation Guide Figure 1-5 Rear panel of ADS NX5-8000 ① Power supply 1 ② Power supply 2 ③ Switch of power supply 2 ④ Switch of power supply 1 ⑤ Ventilation holes ⑥ Ground connector 1.1.3 ADS NX3-200E/600E/800E...

  • Page 14: Power Supply

    NSFOCUS ADS Installation Guide Figure 1-7 Rear panel of ADS NX3-200E/600E/800E ① Ground connector ② Power switch ③ Power port Power Supply ADS devices support both AC and DC inputs. Before delivery, ADS devices are configured with power modules. You can choose to use the AC or DC power module based on the equipment room environment.

  • Page 15: Leds

    NSFOCUS ADS Installation Guide  AC 1500V 1 minute (FG-LG, SG-LG)  AC 500V 1 minute (FG-SG) Specifications of the DC Power Supply For ADS NX3-2020/2020E/2010, ADS NX5-4020/4020E, and ADS NX5-6025/6025E, the DC power supply specifications are as follows: Voltage range: –40 to –60 V DC ...

  • Page 16: Table 1-3 Power Led

    NSFOCUS ADS Installation Guide Table 1-3 Power LED Description Indicates the power is normal. Indicates the power is off or abnormal. Status LED Table 1-4 describes functions of the status LED. Table 1-4 Status LED Description Green Indicates that the system is in normal state.

  • Page 17: System Information

    NSFOCUS ADS Installation Guide System Information Table 1-7 lists hardware specifications of ADS NX3-2020/2020E/2010, ADS NX5- 4020/4020E, and ADS NX5-6025/6025E. Table 1-7 Hardware specifications of ADS NX3-2000 series and NX5-4000/6000 series Interface  1 x RJ-45 console port  1 x RJ-45 GE electrical port (management interface) ...

  • Page 18: Table 1-8 Hardware Specifications Of Ads Nx5-8000

    NSFOCUS ADS Installation Guide Table 1-8 Hardware specifications of ADS NX5-8000 Interface  2 x management interface (M and H1)  1 x RJ-45 console port  2 x USB port  4 x 10 GE SFP interface (for the 10 Gigabit card) ...

  • Page 19: Table 1-9 Hardware Specifications Of Ads Nx3-200E/600E/800E

    NSFOCUS ADS Installation Guide Table 1-9 Hardware specifications of ADS NX3-200E/600E/800E Interface  1 x RJ-45 console port  1 x RJ-45 GE electrical management port  6 x GE electrical port Weight 7 kg Height 44 mm Depth 390 mm...

  • Page 20: Preparations

    NSFOCUS ADS Installation Guide Preparations Prepare the following before installing ADS devices:  Accessories supplied with the device Before installation, make sure that the following items are included in the accessory box delivered with the device: − Straight-through cable (green): used for network connections.
  • Page 21 NSFOCUS ADS Installation Guide − ESD wrist strap  Environment − Good ventilation and heat elimination system on the installation site. − Temperature: 0–45° C. − Relative humidity: 10%–95% (non-condensing).  ESD precaution The device and floor are well grounded.

  • Page 22: Installation Procedure

    NSFOCUS ADS Installation Guide Installation Procedure Installation Flowchart Figure 3-1 Installation flowchart Copyright © NSFOCUS V4.5R90F00 (2017-12-01)

  • Page 23: Connecting Power Cable

    NSFOCUS ADS Installation Guide Connecting Power Cable ADS devices support both the AC power supply and DC power supply. For detailed descriptions of power supply, see section 1.2 Power Supply. The following sections describe how to connect the power supplies.

  • Page 24: Network Connection

    NSFOCUS ADS Installation Guide Network Connection Connect the ADS device to the network according to the actual network structure. Pay attention to the following:  Use straight-through cables to connect the switch to the communication interface of the device. ...

  • Page 25: Out-Of-Path Deployment

    NSFOCUS ADS Installation Guide Figure 3-2 In-path deployment of an ADS device 3.5.2 Out-of-Path Deployment To protect crucial businesses of Internet data centers (IDCs), Internet content providers (ICPs), or telecom carriers, ADS devices can be deployed in out-of-path mode, which employs the traffic diversion mechanism.

  • Page 26: Initial Configuration

    NSFOCUS ADS Installation Guide Initial Configuration The device can operate properly after you complete simple network configuration and import a valid certificate. Network configuration involves the following:  IP address  Subnet mask  Gateway  DNS Server Network configuration can be conducted on the console or the web-based manager. Both approaches require a computer and accessories (included in the accessory box).

  • Page 27: Figure 4-1 Location Information Dialog Box

    NSFOCUS ADS Installation Guide  Terminal software (such as the HyperTerminal software included in Microsoft Windows) that can establish communication to the ADS device via the console  Connect the ADS device and the computer by using a console cable.

  • Page 28: Figure 4-2 Connection Description Dialog Box

    NSFOCUS ADS Installation Guide Figure 4-2 Connection Description dialog box Step 3 In the Connection Description dialog box, type the connection name (ADS in this case), and click OK, as shown in Figure 4-2. Step 4 Select a port (COM1 in this example) that is connected to the computer through a serial cable.

  • Page 29: Network Configuration On The Console

    Figure 4-4 Configuring port attributes Step 6 Click OK and then press Enter. Then the login: prompt appears. Type the user name and password (admin and nsfocus respectively by default) of the console administrator. Figure 4-5 Prompt If the user name and password are correct, the administrator will successfully log in to the console.

  • Page 30: Login To Web-Based Manager

    NSFOCUS ADS Installation Guide Step 1 Configure the IP address. Since ADS devices support IPv4/IPv6 dual-stack, you can configure the IP address/subnet mask and IPv6 address/prefix length for the management interface.  IPv4 address: On the main menu, type 1 and press Enter to configure the IPv4 address, subnet mask and gateway address as prompted.

  • Page 31: Figure 4-7 Login Page

    NSFOCUS ADS Installation Guide Step 4 In the login page shown in Figure 4-7, select a language, type a correct user name and password, and click Login to log in to the web-based manager. Figure 4-7 Login page Step 5 On the page shown in Figure 4-8, set the user locality, system time zone, and system time.

  • Page 32: Importing A License

    NSFOCUS ADS Installation Guide Figure 4-9 Changing the initial password Step 7 After changing the initial password, click Finish to make the settings take effect. Then you successfully log in to the web-based manager. ----End  You are advised to use IE 8.0 through 10.0 or Chrome, with the resolution of 1024x768 or higher.

  • Page 33: Network Configuration On Web-Based Manager

    NSFOCUS ADS Installation Guide To get an ADS license file, please contact technical support personnel of NSFOCUS. Step 3 Click Submit to import the license file. Step 4 Click OK to continue the license import. The page after an import success is as shown in Figure 4-11.

  • Page 34: System Maintenance

    NSFOCUS ADS Installation Guide System Maintenance System Update Timely system updating will improve the anti-attack capability. The system procedure is as follows: Step 1 Choose System > Others > System Upgrade to open the system upgrade page, as shown in Figure 5-1.

  • Page 35: Common Troubleshooting

    NSFOCUS ADS Installation Guide If problems emerge after the update and version rollback is needed, the version can only be rolled back to the source version. For detailed rollback operations, please contact NSFOCUS technical support. ----End Common Troubleshooting 5.2.1 Web Login Failure Symptom Failure to access the web-based manager after ADS is installed.

  • Page 36: Mac Address Learning Failure

    If the connected interface is an electrical port, set the two ends to the same negotiation mode and speed.  If the problem persists, contact NSFOCUS technical support. 5.2.5 Ping Failure or Excessive Packets Drop Symptom ADS does not answer pinging or drops too many packets.

  • Page 37: A Default Parameters

    NSFOCUS ADS Installation Guide Default Parameters A.1 Default Management Interface Settings IP Address 192.168.1.100 Subnet Mask 255.255.255.0 Gateway 192.168.1.1 A.2 Default Web Administrator Account User Name admin Password nsfocus A.3 Default Console Administrator Account User Name admin Password nsfocus A.4 Default CLI Administrator Account...
