NSFOCUS ADS

Installation Guide

Version: V4.5R89F00 (2016-03-05)

Table of Contents

Need help?

Do you have a question about the ADS NX3 2000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for NSFOCUS ADS NX3 2000 Series

Page 2 ■ Copyright © 2016 NSFOCUS Technologies, Inc. All rights reserved. Unless otherwise stated, NSFOCUS Technologies, Inc. holds the copyright for the content of this document, including but not limited to the layout, figures, photos, methods, and procedures, which are protected under the intellectual property and copyright laws.
Page 3: Table Of Contents
NSFOCUS ADS Installation Guide Contents Preface ..............................1 Scope ..................................1 Audience ................................1 Organization ................................2 Conventions ................................2 Customer Support..............................2 1 Overview ............................4 1.1 Appearance ............................... 4 1.1.1 ADS NX3-2000 Series and NX5-4000/6000 Series ................4 1.1.2 ADS NX5-8000 Series ..........................
Page 4 NSFOCUS ADS Installation Guide 5.2 Common Troubleshooting ..........................28 5.2.1 Web Login Failure ..........................28 5.2.2 Device Access Failure ........................... 28 5.2.3 Verification Image Display Failure ....................... 28 5.2.4 License Import Failure .......................... 29 5.2.5 MAC Address Learning Failure ......................29 5.2.6 Ping Failure or Excessive Packets Drop ....................
Page 5 NSFOCUS ADS Installation Guide Figures Figure 1-1 Appearance of ADS NX5-4020 ......................5 Figure 1-2 Front panel of ADS NX5-4020 ......................5 Figure 1-3 Rear panel of ADS NX5-4020 ......................6 Figure 1-4 Front panel of ADS NX5-8000 ......................6 Figure 1-5 Rear panel of ADS NX5-8000 ......................
Page 6 NSFOCUS ADS Installation Guide Tables Table 1-1 AC power LEDs ............................. 8 Table 1-2 DC power LEDs ............................. 9 Table 1-3 Power LED ............................10 Table 1-4 Status LED ............................10 Table 1-5 System LED ............................10 Table 1-6 Interface LED ............................10 Table 1-7 Hardware specifications of ADS NX5-6025/NX5-4020/NX3-2020/NX3-2010 ........
Page 7: Preface
Scope This document describes the basic information and detailed installation procedure about NSFOCUS ADS NX3 2000 series (ADS NX3-2020 and ADS NX3-2010), NX3-200E, NX3-600E, NX5 4000 series (ADS NX5-4020), NX5 6000 series (ADS NX5-6025), and ADS NX5 8000 series (ADS NX5-8000).
Page 8: Organization
Indicates a situation in which you might perform an action that could result in bodily injury. Indicates selection of menu options. A > B Customer Support To obtain materials about network security, visit NSFOCUS website at: http://www.nsfocus.com/en/index.html Copyright © NSFOCUS V4.5R89F00 (2016-03-05)
Page 9 NSFOCUS ADS Installation Guide To obtain professional service information and business information about NSFOCUS network security, contact us at: Global Support 24/7 service hotline: +86-13321167330 +86-400-818-6868 Email: global_support@nsfocus.com NSFOCUS US Tel: +1 408-907-6638 Email: info-us@nsfocus.com NSFOCUS Japan Tel: +81-3-6206-8156 Email: info-jp@nsfocus.com...
Page 10: Overview
NSFOCUS ADS Installation Guide Overview The ADS system is an integrated hardware device. This chapter gives a brief account of them. Appearance This section details the appearance, including front and rear panels, of ADS devices. The interface model or quantity of real products may slightly vary with the batch or model.
Page 11: Figure 1-1 Appearance Of Ads Nx5-4020
NSFOCUS ADS Installation Guide Figure 1-1 Appearance of ADS NX5-4020 Front Panel Figure 1-2 Front panel of ADS NX5-4020 ① Management interface ② Hot standby port ③ RJ45 console port ④ USB interface ⑤ Reset button ⑥ Power LED ⑦ Status LED ⑧...
Page 12: Ads Nx5-8000 Series
NSFOCUS ADS Installation Guide Rear Panel Figure 1-3 Rear panel of ADS NX5-4020 ① Power switch ② Power supply 1 ③ Power supply 2 1.1.2 ADS NX5-8000 Series Figure 1-4 Figure 1-5 show the front and rear panels of ADS NX5-8000, respectively.
Page 13: Ads Nx3-200E/600E
NSFOCUS ADS Installation Guide Figure 1-5 Rear panel of ADS NX5-8000 ① Power supply 1 ② Power supply 2 ③ Switch of power supply 2 ④ Switch of power supply 1 ⑤ Ventilation holes ⑥ Ground connector 1.1.3 ADS NX3-200E/600E...
Page 14: Power Supply
NSFOCUS ADS Installation Guide Figure 1-7 Rear panel of ADS NX3-200E/600E ① Ground connector ② Power switch ③ Power port Power Supply The ADS devices support both AC and DC inputs. Before delivery, the ADS devices are configured with power modules. You can determine to use the AC or DC power module based on the equipment room environment.
Page 15: Leds
NSFOCUS ADS Installation Guide  AC 1500V 1 minute (FG-LG, SG-LG)  AC 500V 1 minute (FG-SG) Specifications of the DC Power Supply For ADS NX3-2020/2010, ADS NX5-4020, and ADS NX5-6025, the DC power supply specifications are as follows: Voltage range: –40 to 60 V DC ...
Page 16: Table 1-3 Power Led
NSFOCUS ADS Installation Guide Table 1-3 Power LED Description Indicates the power is normal. Indicates the power is off or abnormal. Status LED Table 1-4 describes functions of the status LED. Table 1-4 Status LED Description Green Indicates that the system is in normal state.
Page 17: System Information
1 x Hot standby port of the management interface  1–2 x 10 Gigabit Ethernet SFP interface (reserved for the 10 Gigabit card that you can purchase from NSFOCUS)  1–8 x Gigabit Ethernet optical port (selected by users as required) ...
Page 18: Table 1-8 Hardware Specifications Of Ads Nx5-8000
NSFOCUS ADS Installation Guide Table 1-8 Hardware specifications of ADS NX5-8000 Interface  2 x management interface (M and H1)  1 x RJ-45 console port  2 x USB port  4 x 10 Gigabit Ethernet SFP interface (for the 10 Gigabit card) ...
Page 19: Table 1-9 Hardware Specifications Of Ads Nx3-200E/600E
NSFOCUS ADS Installation Guide Table 1-9 Hardware specifications of ADS NX3-200E/600E Interface  1 x RJ-45 console port  1 x RJ-45 1GbE electrical management port  6 x 1GbE electrical port Weight 7 kg Height 44 mm (2U) Depth...
Page 20: Preparations
NSFOCUS ADS Installation Guide Preparations Prepare the following before installing ADS devices:  Accessories supplied with the device Before installation, verify the following items are included in the accessory box delivered with the device: − Straight-through cable: Used for network connections.
Page 21 NSFOCUS ADS Installation Guide − Instruments and meters, such as hub, terminal, and multimeter − Optional cables − Cabling rack − Anti-static wrist strap  Environment − The minimal acceptable space between the wall and the air inlet or air vent is 10 cm.
Page 23: Connecting Power Cable
NSFOCUS ADS Installation Guide Connecting Power Cable ADS devices support both the AC power supply and DC power supply. For detailed descriptions of power supply, see section 1.2 Power Supply. The following sections describe how to connect the power supplies.
Page 24: Network Connection
For details on default parameters of the ADS device, see appendix A Default Parameters. You can modify network settings at either the console management interface (see the NSFOCUS ADS User Guide) or web-based manager (see chapter 4 Initial Configuration). Device Shutdown You can turn the power switch to 0 to turn off the power supply.
Page 25: Out-Of-Path Deployment
NSFOCUS ADS Installation Guide Figure 3-2 In-path deployment of an ADS device 3.5.2 Out-of-Path Deployment To protect crucial businesses of Internet data center (IDC), Internet content provider (ICP), or carriers, ADS devices can be deployed in out-of-path mode, which employs the traffic diversion mechanism.
Page 26: Initial Configuration
NSFOCUS ADS Installation Guide Initial Configuration The device can operate properly after you complete simple network configuration and import a valid certificate. Network configuration involves the following:  IP address  Subnet mask  Gateway  DNS Server Network configuration can be conducted on the console or the web-based manager. Both approaches require a computer and accessories (included in the accessory box).
Page 27: Figure 4-1 Location Information Dialog Box
NSFOCUS ADS Installation Guide  Terminal software (such as the HyperTerminal software included in Microsoft Windows) that can establish communication to the ADS device via the console  Connect the ADS device and the computer by using a console cable.
Page 28: Figure 4-2 Connection Description Dialog Box
NSFOCUS ADS Installation Guide Figure 4-2 Connection Description dialog box Step 3 In the Connection Description dialog box, type the connection name (ADS in this case), and click OK, as shown in Figure 4-2. Step 4 Select a port (COM1 in this example) that is connected to the computer through a serial cable.
Page 29: Network Configuration On The Console
Figure 4-4 Configuring port attributes Step 6 Click OK and then press Enter. Then the login: prompt appears. Type the user name and password (admin and nsfocus respectively by default) of the console administrator. Figure 4-5 Prompt If the user name and password are correct, the administrator will successfully log in to the console.
Page 30: Login To Web-Based Manager
NSFOCUS ADS Installation Guide Step 1 Configure the IP address. Since ADS devices support IPv4/IPv6 dual-stack, you can configure the IP address/subnet mask and IPv6 address/prefix length for the management interface.  IPv4 address: On the main menu, type 1 and press Enter to configure the IPv4 address, subnet mask and gateway address as prompted.
Page 31: Figure 4-7 Login Page
NSFOCUS ADS Installation Guide Step 4 In the login page shown in Figure 4-7, select a language, type a correct user name and password, and click Login to log in to the web-based manager. Figure 4-7 Login page After a successful login, the web-based manager appears, as shown in Figure 4-8.
Page 32: Network Configuration On Web-Based Manager
NSFOCUS ADS Installation Guide  During your first login, the system prompts a dialog box of changing the password. You can proceed only after successfully changing the password. The new password cannot be the same as the default password. ...
Page 33: System Maintenance
NSFOCUS ADS Installation Guide System Maintenance System Upgrade Timely system upgrade will increase the anti-attack capability. The system procedure is as follows: Step 1 Choose System > Others > System Upgrade to open the system upgrade page, as shown in...
Page 34: Common Troubleshooting
Figure 5-1. If problems emerge after upgrade and version rollback is needed, the version can only rolled back to the source version. For detailed rollback operations, please contact technical support personnel of NSFOCUS. ----End Common Troubleshooting 5.2.1 Web Login Failure Symptom Fail to access the web-based manager after the manager is installed.
Page 35: License Import Failure
Changing an optical module addressed the problem.  If the connected interface is an electrical port, set the two ends to the same negotiation mode and speed.  If the problem persists, contact NSFOCUS technical support engineers. Copyright © NSFOCUS V4.5R89F00 (2016-03-05)
Page 36: Ping Failure Or Excessive Packets Drop
NSFOCUS ADS Installation Guide 5.2.6 Ping Failure or Excessive Packets Drop Symptom The device does not answer pinging or too many packets are dropped. Troubleshooting Check the following from lower layers to high layers:  Check the working mode and current state of the NIC to determine whether connections are proper.
Page 37: A Default Parameters
NSFOCUS ADS Installation Guide Default Parameters A.1 Default Management Interface Settings IP Address 192.168.1.100 Subnet Mask 255.255.255.0 Gateway 192.168.1.1 A.2 Default Web Administrator Account User Name admin Password nsfocus A.3 Default Console Administrator Account User Name admin Password nsfocus A.4 Default CLI Administrator Account...
