NSFOCUS ADS Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NSFOCUS ADS
Installation Guide
Version: V4.5R90F01 (2018-07-31)
© 2018 NSFOCUS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADS and is the answer not in the manual?

Questions and answers

Related Manuals for NSFOCUS ADS

Summary of Contents for NSFOCUS ADS

  • Page 1 NSFOCUS ADS Installation Guide Version: V4.5R90F01 (2018-07-31) © 2018 NSFOCUS...
  • Page 2 ■ Copyright © 2018 NSFOCUS Technologies, Inc. All rights reserved. Unless otherwise stated, NSFOCUS Technologies, Inc. holds the copyright for the content of this document, including but not limited to the layout, figures, photos, methods, and procedures, which are protected under the intellectual property and copyright laws.

  • Page 3: Table Of Contents

    Conventions ................................2 Customer Support..............................2 1 Overview ............................3 1.1 Appearance ............................... 3 1.1.1 ADS NX3-2000 Series and NX5-4000/6000 Series ................3 1.1.2 ADS NX5-8000 Series ..........................4 1.1.3 ADS NX3-200E/600E/800E ........................5 1.1.4 ADS NX5-10000 Series .......................... 6 1.2 Power Supply ..............................
  • Page 4 5.1 System Update ............................... 30 5.2 Common Troubleshooting ..........................31 5.2.1 Web Login Failure ..........................31 5.2.2 ADS Access Failure ..........................31 5.2.3 License Import Failure .......................... 31 5.2.4 MAC Address Learning Failure ......................32 5.2.5 Ping Failure or Excessive Packets Drop ....................32 A Default Parameters ........................
  • Page 5 Figure 1-5 Front panel of ADS NX3-200E/600E/800E ..................6 Figure 1-6 Rear panel of ADS NX3-200E/600E/800E ..................6 Figure 1-7 Front panel of ADS NX5-10000 with the HTCA-SFPP16TX4 interface ..........7 Figure 1-8 Front panel of ADS NX5-10000 with the HTCA-CXP2SFPP20 interface .......... 8 Figure 1-1 Front panel of ADS NX5-10000 with the HTCA-QSFP28x6QSFP4SFPP16 interface .......
  • Page 6 Table 1-9 Meanings of the system LED in different states .................. 14 Table 1-10 Meanings of interface LEDs in different states .................. 14 Table 1-11 Hardware specifications of ADS NX3-2000 series and NX5-4000/6000 series ........ 15 Table 1-12 Hardware specifications of ADS NX5-8000 ..................16 Table 1-13 Hardware specifications of ADS NX3-200E/600E/800E ..............

  • Page 7: Preface

    This document provides guidance for you in use of the products. Descriptions in this guide may slightly differ from actual products due to version upgrade or other reasons. Unless otherwise indicated, figures and texts in this manual use ADS NX5-4020 as an example.

  • Page 8: Conventions

    Describes methods maintaining devices common troubleshooting. A Default Parameters Describes default parameters about ADS devices. Conventions Convention Description Keywords, names of screen elements like buttons, drop-down lists or fields, and Bold font user-entered text appear in bold font. Document titles, new or emphasized terms, and arguments for which you supply Italic font values are in italic font.

  • Page 9: Overview

    NSFOCUS ADS Installation Guide Overview The ADS system is an integrated hardware device. This chapter gives a brief account of ADS devices. Appearance This section details the appearance, including front and rear panels, of ADS devices. The interface model or quantity of actual products may slightly vary with the batch or model.

  • Page 10: Ads Nx5-8000 Series

    Figure 1-2 Rear panel of ADS NX5-4020 ① ② ③ Ground connector Power switch Power LED ④ Power port 1.1.2 ADS NX5-8000 Series Figure 1-3 Figure 1-4 show the front and rear panels of ADS NX5-8000 respectively. Copyright © NSFOCUS V4.5R90F01 (2018-07-31)

  • Page 11: Ads Nx3-200E/600E/800E

    ③ Switch of power supply 2 ④ Switch of power supply 1 ⑤ Ventilation holes ⑥ Ground connector 1.1.3 ADS NX3-200E/600E/800E Figure 1-5 Figure 1-6 show the front and rear panels of ADS NX3-200E/600E/800E respectively. Copyright © NSFOCUS V4.5R90F01 (2018-07-31)

  • Page 12: Ads Nx5-10000 Series

    ③ Power port 1.1.4 ADS NX5-10000 Series 1.1.4.1 Front Panel The front panel of ADS NX5-10000 varies with the type of the following interfaces used: HTCA-SFPP16TX4, HTCA-CXP2SFPP20, and HTCA-QSFP28x6QSFP4SFPP16. HTCA-SFPP16TX4 Interface The HTCA-SFPP16TX4 interface supports only1000M and 10G switch boards.

  • Page 13: Figure 1-7 Front Panel Of Ads Nx5-10000 With The Htca-Sfpp16Tx4 Interface

    NSFOCUS ADS Installation Guide Figure 1-7 Front panel of ADS NX5-10000 with the HTCA-SFPP16TX4 interface ① Working interface: ② ③ Working interface: 10G Working interface: 10G electrical ④ ⑤ ⑥ MGT: IPMI CONSOLE: RJ45 USB port ⑦ ⑧ ⑨ PWR: power LED...

  • Page 14: Figure 1-8 Front Panel Of Ads Nx5-10000 With The Htca-Cxp2Sfpp20 Interface

    NSFOCUS ADS Installation Guide Figure 1-8 Front panel of ADS NX5-10000 with the HTCA-CXP2SFPP20 interface ① Working interface: 100G ② ③ Working interface: 10G Working interface: 10G ④ ⑤ ⑥ MGT: IPMI CONSOLE: RJ45 USB port ⑦ ⑧ ⑨ PWR: power LED...

  • Page 15: Figure 1-1 Front Panel Of Ads Nx5-10000 With The Htca-Qsfp28X6Qsfp4Sfpp16 Interface

    NSFOCUS ADS Installation Guide Figure 1-1 Front panel of ADS NX5-10000 with the HTCA-QSFP28x6QSFP4SFPP16 interface ① ② ③ Working interface: 100G Working interface: 40G Working interface: 10G ④ ⑤ ⑥ Working interface: 10G MGT: IPMI CONSOLE: RJ45 ⑦ ⑧ ⑨...

  • Page 16: Power Supply

    If necessary, connect the ADS device to two independent power supplies to implement 1+1 power redundancy. In this case, even if one of the power modules fails, the ADS device still operates properly. The power switch and socket reside at the rear of the chassis, as shown in Figure 1-4.

  • Page 17: Table 1-1 Recommended Power Supply Configuration

    The OK LED being off although the device is started indicates that the power is overloaded or fails. The OK indicator is available for the AC power supply on ADS NX3- 2020/2020E/2010, NX5-4020/4020E, and NX5-6025/6025E, but unavailable for the AC power supply on ADS NX3-200E/600E/800E, NX5-8000, and NX-10000.

  • Page 18: Leds

    Rated voltage range: –36 to –72 V DC   Maximum output power: 500 W ADS NX5-10000 supports up to five power supply modules. Specifications of a single DC power supply module are as follows: Rated voltage range: –39 to –76 V DC ...

  • Page 19: Table 1-4 Meanings Of The Power Led In Different States

    Indicates that the engine works improperly. Status LED (STAT) Table 1-6 describes STAT LEDs in different states. These LEDs are available only on ADS NX5-10000. There are six STAT LEDs, each of which indicates the engine status of one service card.

  • Page 20: System Information

    NSFOCUS ADS Installation Guide Status LED (ACTN) Table 1-8 describes ACTN LEDs in different states. These LEDs are available only on ADS NX5-10000. There are six ACTN LEDs, each of which indicates the IPMI connection status of one service card.

  • Page 21: Table 1-11 Hardware Specifications Of Ads Nx3-2000 Series And Nx5-4000/6000 Series

    NSFOCUS ADS Installation Guide Table 1-11 Hardware specifications of ADS NX3-2000 series and NX5-4000/6000 series Interface  1 x RJ45 console port  1 x RJ45 GE electrical port (management interface)  1 x Hot standby port of the management interface ...

  • Page 22: Table 1-12 Hardware Specifications Of Ads Nx5-8000

    NSFOCUS ADS Installation Guide Table 1-12 Hardware specifications of ADS NX5-8000 Interface  2 x management interface (M and H1)  1 x RJ45 console port  2 x USB port  4 x 10 GE SFP interface (for the 10 Gigabit card) ...

  • Page 23: Table 1-13 Hardware Specifications Of Ads Nx3-200E/600E/800E

    NSFOCUS ADS Installation Guide Table 1-13 Hardware specifications of ADS NX3-200E/600E/800E Interface  1 x RJ45 console port  1 x RJ45 GE electrical management port  6 x GE electrical port Weight 7 kg Height 44 mm Depth 390 mm...

  • Page 24: Preparations

    Accessories supplied may vary with the product model. For the specific items, refer to the packing list. Besides the stuff in the accessory box, prepare the following: IP address: IP address reserved for ADS devices. You are advised to reserve both an − IPv4 address and an IPv6 address for an ADS device.
  • Page 25 NSFOCUS ADS Installation Guide − ESD wrist strap  Environment − Good ventilation and heat elimination system on the installation site. − Temperature: 0–45° C. − Relative humidity: 10%–95% (non-condensing).  ESD precaution The device and floor are well grounded.

  • Page 26: Installation Procedure

    NSFOCUS ADS Installation Guide Installation Procedure Installation Flowchart Figure 3-1 Installation flowchart Copyright © NSFOCUS V4.5R90F01 (2018-07-31)

  • Page 27: Connecting The Power Cable

    Step 3 Plug the other end of the power cable into the power socket of the power mains. Step 4 Turn the power switch to 1 (or pull the power switch of each board to the left for ADS NX5- 10000) to turn on the power module.

  • Page 28: Network Connection

    NSFOCUS ADS Installation Guide Step 4 Turn the power switch to 1 (or pull the power switch of each board to the left for ADS NX5- 10000) to turn on the power module. On ADS NX5-10000, the power switch, after being pulled left, will immediately flip back to the original position.

  • Page 29: System Deployment

    NSFOCUS ADS Installation Guide System Deployment Currently, the ADS device can be deployed in in-path mode or out-of-path mode based on different network environments. The following sections detail the two modes. ADS NX3-2020/2020E/2010/200E/600E/800E and NX5-4020/4020E/6025/6025E support both in-path and out-of-path modes, whereas ADS NX5-8000 and NX5-10000 support the out-of-path mode only.

  • Page 30: Figure 3-3 Out-Of-Path Deployment Of An Ads Device

    NSFOCUS ADS Installation Guide Figure 3-3 Out-of-path deployment of an ADS device Copyright © NSFOCUS V4.5R90F01 (2018-07-31)

  • Page 31: Initial Configuration

    To perform configurations on the console, you need to connect the device to a computer with a console port cable. The console port rate of ADS devices is 115200 bps. After login, you can perform configurations by selecting menus. For details, see section 4.2 Network...

  • Page 32: Network Configuration On The Console

    Connect the ADS device and the computer by using a console cable. To log in to the console user interface of ADS, follow these steps: Step 1 Use terminal software to connect to the console user interface of ADS via the console port. For serial communication parameters, see appendix A Default Parameters.

  • Page 33: Figure 4-1 Security Alert Page

    NSFOCUS ADS Installation Guide As the ADS device supports both IPv4 and IPv6 protocols, you can type an IPv4 address (for example, https://192.168.1.1) or IPv6 address (for example, https://[2001::107]). After you type the IP address, a security alert page appears as shown in Figure 4-1.

  • Page 34: Figure 4-3 Setting The Time Zone And System Time

    NSFOCUS ADS Installation Guide Figure 4-3 Setting the time zone and system time Step 6 Click Next. The page for changing the initial password appears. The new password must be a string that is no less than 8 characters and at least contains two of the following character types: English letters, digits, and special characters.

  • Page 35: Importing A License

    NSFOCUS ADS Installation Guide Importing a License After logging in to an ADS device, you must import a license before using it. To import a license, perform the following steps: Step 1 Choose System > Others > License Info. Figure 4-5 shows the initial license page.

  • Page 36: System Maintenance

    NSFOCUS ADS Installation Guide System Maintenance System Update Timely system updating will improve the anti-attack capability. The system procedure is as follows: Step 1 Choose System > Others > System Upgrade to open the system upgrade page, as shown in Figure 5-1.

  • Page 37: Common Troubleshooting

    Failure to access the web-based manager after ADS is installed. Troubleshooting Check whether the network connection between the client and the management interface of ADS is blocked by a firewall. If so, make sure that port 443 of the ADS device is accessible. 5.2.2 ADS Access Failure Symptom ADS is not accessible though its threshold is not reached yet.

  • Page 38: Mac Address Learning Failure

    Once a new license is imported, you are barred from importing old licenses. To use such old ones, you need to apply for them again. 5.2.4 MAC Address Learning Failure Symptom When connected with a router, neither the router nor ADS can learn the MAC of the other. Troubleshooting Check the following: ...

  • Page 39: A Default Parameters

    NSFOCUS ADS Installation Guide Default Parameters A.1 Default Management Interface Settings IP Address 192.168.1.100 Subnet Mask 255.255.255.0 Gateway 192.168.1.1 A.2 Default Web Administrator Account User Name admin Password nsfocus A.3 Default Console Administrator Account User Name admin Password nsfocus A.4 Default CLI Administrator Account...
  • Page 40 NSFOCUS ADS Installation Guide A.6 Default IPMI Parameters (for ADS NX5-10000 only) Management IP Address of the 192.168.0.100 Chassis Subnet Mask 255.255.255.0 Management IP Address of 192.168.0.101 Service Board 1 Subnet Mask 255.255.255.0 Management IP Address of 192.168.0.102 Service Board 2 Subnet Mask 255.255.255.0...
