INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
96-03996-00-01
Revision F
CONFIDENTIAL and
INOGEN ONE G3 OXYGEN CONCENTRATOR
Page 1 of 20
96-03996-00-01 revF
DCR-15-284
PROPRIETARY
TECHNICAL MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the One G3 and is the answer not in the manual?

Questions and answers

Related Manuals for Inogen One G3

Summary of Contents for Inogen One G3

  • Page 1 INOGEN ONE G3 OXYGEN CONCENTRATOR TECHNICAL MANUAL 96-03996-00-01 Revision F CONFIDENTIAL and INOGEN ONE G3 OXYGEN CONCENTRATOR Page 1 of 20 96-03996-00-01 revF DCR-15-284 PROPRIETARY TECHNICAL MANUAL...
  • Page 2 This Manual applies to the following Inogen, Inc. products:  Inogen One G3 Oxygen Concentrator, model # IO-300  Inogen One AC Power supply, model # BA-301  Battery, model # BA-300  Battery, model # BA-316 CONFIDENTIAL and INOGEN ONE G3 OXYGEN CONCENTRATOR...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INFORMATION FOR PROVIDERS OF THE INOGEN ONE G3 ................. 4 ......................... 4 1.1. AUTION AND ARNING TATEMENTS SETTING UP A PATIENT ON INOGEN ONE G3 ....................... 6 2.1............................6 ECOMMENDATIONS FOR ..............................6 2.2. S YSTEM OMPONENTS 2.3.

  • Page 4: Information For Providers Of The Inogen One G3

    Inogen One G3 and its accessories. Proper One G3, but will also protect the patient, prolong the life of the device, and help you avoid unnecessary service calls and complaints from users.
  • Page 5 This information is not required to operate or maintain the Inogen One G3. In many cases, warnings and cautions have been included in the Inogen One G3 User Manual. CONFIDENTIAL and...

  • Page 6: Setting Up A Patient On Inogen One G3

    DC Power Cord o Carry Bag o Cannula Patient Set-Up. To properly set up a patient on the Inogen One G3 System, you may need to provide: o Pulse Oximeter (for titration, not included) o Extra cannulas (not included)

  • Page 7: Using The Inogen One G3

    4. Plug into closest AC outlet 5. Turn on the Inogen One G3 by pressing the on/off button. 6. Set the Inogen One G3 to correct flow setting prescribed by the physician or clinician by pressing the + (increase flow) or (decrease flow) button.
  • Page 8 NOTE is more closely linked to flow setting than to breathing rate. In general, the Inogen One G3 delivers 14ml per bolus per flow setting at 15 breaths per minute (210ml/min per flow setting). The following table summarizes the bolus...

  • Page 9: Servicing The Inogen One G3

    3.1. Maintenance by the Provider 3.1.1. Authorized Repair Centers The Inogen One G3 is only intended to be repaired by authorized repair centers. If a repair is required, please contact Inogen to locate your nearest authorized repair center. If you would like to become an authorized repair center, please contact Inogen for access to certification training, service instructions, component part lists and the necessary repair equipment.
  • Page 10 This filter is intended to protect the user from small particles in the product gas flow. The Inogen One G3 includes a product filter, conveniently located behind the removable cannula nozzle fitting. Inogen suggests that this filter be replaced between patients.
  • Page 11 1. Use the Cannula Barb Tool (available from Inogen as RP-102) to access the product filter. The tool has two prongs which mate with two indentations located on the surface of the metal cannula barb fitting on the Inogen One G2. 2. Carefully remove the cannula fitting by unscrewing it in the counter-clockwise direction.
  • Page 12  Charging Status 3.1.8. Data Download To download data from the Inogen One G3, you will need a USB mass storage device. If one of the following drives cannot be obtained, the drive must be less than 2GB in capacity and have a native file format of FAT32. The capacity of the drive and the file system alone do not ensure compatibility with the Inogen One G3.

  • Page 13: Maintenance By The Patient

    3.2.2. Intake Filter Cleaning At the front of the Inogen One G3, ambient air passes through two gross particle screens that removes dust fragments. This particle screen must be cleaned on a weekly basis to ensure adequate air flow through the device.
  • Page 14 3.2.4. Battery Care and Maintenance The Inogen One G3 Lithium Ion Battery requires special care to ensure proper performance and long life. Use only Inogen One G3 Batteries with the Inogen One G3 Oxygen Concentrator. The Inogen One G3 Oxygen Concentrator adjusts its oxygen production rate to match the oxygen demand specified by the user flow setting.
  • Page 15 (extra charged battery or AC Power Supply). Storage Instruct patients to remove the battery from the Inogen One G3 when it is not in use to avoid inadvertent discharge. Leaving a battery attached to an idle Inogen One G3 for prolonged periods will result in battery damage that will severely shorten the expected life of the battery.

  • Page 16: Expected Service Requirements

    C), for any amount of time. They should avoid leaving batteries in automobiles, where these temperatures can be regularly exceeded. Storage of the Inogen One G3 battery in a cool, dry location will help to maximize the longevity of the battery.
  • Page 17 Degree of Protection Against Electrical Type BF Shock: Not intended for cardiac application Degree of Protection Against Ingress of Concentrator: IP 20 Water: w/carry bag: IP 22 CONFIDENTIAL and INOGEN ONE G3 OXYGEN CONCENTRATOR Page 17 of 20 96-03996-00-01 revF DCR-15-284 PROPRIETARY TECHNICAL MANUAL...

  • Page 18: Inogen One G3 Error Code Table

    Degree of Safety for Application in Not suitable for such applications Presence of Anesthetic Gases: 5. INOGEN ONE G3 ERROR CODE TABLE Error Code Explanation Possible Causes & Troubleshooting Number Instructions Low voltage on power supply Replace the power supply or remove...

  • Page 19: Error Recall

    All errors will be stored except when the unit is operating in special admin mode, no breath detect, battery low, and Error 1. 7. CONTACTS FOR MORE INFORMATION Inogen Website: Patient Issues: http://www.inogenone.com Corporate: http://www.inogen.net CONFIDENTIAL and INOGEN ONE G3 OXYGEN CONCENTRATOR Page 19 of 20 96-03996-00-01 revF DCR-15-284 PROPRIETARY TECHNICAL MANUAL...
  • Page 20 Inogen : 326 Bollay Dr Goleta, CA 93117 1-866-765-2800 clientservices@inogen.net CONFIDENTIAL and INOGEN ONE G3 OXYGEN CONCENTRATOR Page 20 of 20 96-03996-00-01 revF DCR-15-284 PROPRIETARY TECHNICAL MANUAL...
